Operating instruction
Price computing scale
KERN RXB
Version 1.2
11/2010
GB
RXB-BA-e-1012
RXB-BA-e-1012
2
GB KERN RXB
Version 1.2 11/2010
Operating instruction
Price computing scale
Table of Contents
1Technical data__________________________________________________ 4
2Declaration of conformity ________________________________________ 6
3Appliance overview _____________________________________________ 7
3.1 Overview of display _______________________________________________ 9
3.1.1 Display weight _______________________________________________________ 10
3.1.2 Display basic price ____________________________________________________ 10
3.1.3 Display sale price _____________________________________________________ 10
3.2 Keyboard overview_______________________________________________ 11
4Basic Information (General)______________________________________ 12
4.1 Proper use______________________________________________________ 12
4.2 Improper Use ___________________________________________________ 12
4.3 Warranty _______________________________________________________ 12
4.4 Monitoring of Test Resources ______________________________________ 13
5Basic Safety Precautions________________________________________ 13
5.1 Pay attention to the instructions in the Operation Manual_______________ 13
5.2 Personnel training _______________________________________________ 13
6Transport and storage __________________________________________ 13
6.1 Testing upon acceptance _________________________________________ 13
6.2 Packaging ______________________________________________________ 13
7Unpacking, Setup and Commissioning ____________________________ 14
7.1 Installation Site, Location of Use ___________________________________ 14
7.2 Unpacking ______________________________________________________ 14
7.2.1 Setup ______________________________________________________________ 14
7.2.2 Scope of delivery _____________________________________________________ 15
7.3 Mains connection ________________________________________________ 15
7.4 Battery power supply _____________________________________________ 15
7.5 Initial Commissioning ____________________________________________ 15
7.6 Balance zero display _____________________________________________ 15
8Operation_____________________________________________________ 16
8.1 Weighing with price determination__________________________________ 16
8.1.1 Manual input of a basic price ____________________________________________ 16
8.1.2 FIX mode – Storing a basic price _________________________________________ 17
9Display background illumination _________________________________ 18
RXB-BA-e-1012 3
10 Function menu_______________________________________________ 19
10.1 Navigation in the menu ___________________________________________ 19
10.2 Menu overview __________________________________________________ 20
10.3 Adjustment _____________________________________________________ 20
11 Verification__________________________________________________ 22
11.1 Adjustment key and seals _________________________________________ 23
12 Service, maintenance, disposal_________________________________ 24
12.1 Cleaning _______________________________________________________ 24
12.2 Service, maintenance_____________________________________________ 24
12.3 Disposal________________________________________________________ 24
13 Instant help _________________________________________________ 25
RXB-BA-e-1012
4
1 Technical data
KERN RXB 3K1M RXB 3K1HM RXB 6K2M RXB 6K2HM
Readability (d) 1 g 1 g 2 g 2 g
Weighing range
(max) 3 kg 3 kg 6 kg 6 kg
Minimum load 20 g 20 g 40 g 40 g
Verification value 1 g 1 g 2 g 2 g
Verification class III III III III
Reproducibility 1 g 1 g 2 g 2 g
Linearity ± 2 g ± 2 g ± 4 g ± 4 g
Stabilization time 2 sec. 2 sec. 2 sec. 2 sec.
Recommended ad-
justing weight (not
supplied) 3 kg (M2) 3 kg (M2) 6 kg (M2) 6 kg (M2)
Net weight (kg) 4,4 4,8 4,4 4,8
300x330x110
without tripod 300x330x110
without tripod
Dimensions of the
housing (B x D x H) 300x330x110 300x330x540
with tripod
300x330x110 300x330x540
with tripod
Weighing plate,
stainless steel 300 x 225 mm
Warming up time
(operating tempera-
ture) 20 – 30 min
Weighing unit €/kg; €/100 g
Admitted ambient
temperature -10° C to 40° C
Humidity of air 15 % - 85 % (non-condensing)
Voltage 230 V (AC)
Without backlit display:
Service life c. 200 hours / loading time ca. 8 hrs.
Rechargeable battery With backlit display:
Operating time ca. 60h. / loading time ca. 8 hrs.
RXB-BA-e-1012 5
KERN RXB 15K5M RXB 15K5HM RXB 30K10M RXB
30K10HM
Readability (d) 5 g 5 g 10 g 10 g
Weighing range
(max) 15 kg 15 kg 30 kg 30 kg
Minimum load 100 g 100 g 200 g 200 g
Verification value 5 g 5 g 10 10
Verification class III III III III
Reproducibility 5 g 5 g 10 10
Linearity ± 10 g ± 10 g ± 20 ± 20
Stabilization time 2 sec. 2 sec. 2 sec. 2 sec.
Recommended ad-
justing weight (not
supplied) 15 kg (M2) 15 kg (M2) 30 kg (M2) 30 kg (M2)
Net weight (kg) 4,4 4,8 4,4 4,8
300x330x110
without tripod 300x330x110
without tripod
Dimensions of the
housing (B x D x H) 300x330x110 300x330x540
with tripod
300x330x110 300x330x540
with tripod
Weighing plate,
stainless steel 300 x 225 mm
Warming up time
(operating tempera-
ture) 20 – 30 min
Weighing unit €/kg; €/100 g
Admitted ambient
temperature -10° C to 40° C
Humidity of air 15 % - 85 % (non-condensing)
Voltage 230 V (AC)
Without backlit display:
Service life c. 200 hours / loading time ca. 8 hrs.
Rechargeable battery With backlit display:
Operating time ca. 60h. / loading time ca. 8 hrs.
RXB-BA-e-1012
6
2 Declaration of conformity
KERN & Sohn GmbH
D-72322 Balingen-Frommern
Postfach 4052
Tel: 0049-[0]7433- 9933-0
Fax: 0049-[0]7433-9933-149
Internet: www.kern-sohn.de
Declaration of conformity
EG-Konformitätserklärung EC-Declaration of -Conformity
EC- Déclaration de conformité EC-Declaración de Conformidad
EC-Dichiarazione di conformità EC-Conformiteitverklaring
EC- Declaração de conformidade EC- Prohlášení o shode
EC-Deklaracja zgodności EC-Заявление осоответствии
D Konformitäts-
erklärung
Wir erklären hiermit, dass das Produkt, auf das sich diese Erklärung bezieht,
mit den nachstehenden Normen übereinstimmt.
GB Declaration of
conformity
We hereby declare that the product to which this declaration refers conforms
with the following standards.
CZ Prohlášení o
shode
Tímto prohlašujeme, že výrobek, kterého se toto prohlášení týká, je v souladu
s níže uvedenými normami.
E Declaración de
conformidad
Manifestamos en la presente que el producto al que se refiere esta
declaración está de acuerdo con las normas siguientes
F Déclaration de
conformité
Nous déclarons avec cela responsabilité que le produit, auquel se rapporte la
présente déclaration, est conforme aux normes citées ci-après.
I Dichiarazione di
conformitá
Dichiariamo con ciò che il prodotto al quale la presente dichiarazione si riferi-
sce è conforme alle norme di seguito citate.
NL Conformiteit-
verklaring
Wij verklaren hiermede dat het product, waarop deze verklaring betrekking
heeft, met de hierna vermelde normen overeenstemt.
P Declaração de
conformidade
Declaramos por meio da presente que o produto no qual se refere esta
declaração, corresponde às normas seguintes.
PL Deklaracja
zgodności
Niniejszym oświadczamy, że produkt, którego niniejsze oświadczenie
dotyczy, jest zgodny z poniższymi normami.
RUS Заявление о
соответствии
Мы заявляем, что продукт, ккоторому относится данная декларация,
соответствует перечисленным ниже нормам.
Electronic Balance: KERN CXB/RXB/CXP
EU Directive Standards
2004/108/EC EN 61326-1:2006
EN 61000-3-2:2006
EN 61000-3-3:1995/A2:2005
2006/95/EC EN 61010-1:2001
Date: 12.07.2010 Signature:
KERN & Sohn GmbH
Management
KERN & Sohn GmbH, Ziegelei 1, D-72336 Balingen, Tel. +49-[0]7433/9933-0
RXB-BA-e-1012 7
3 Appliance overview
Models without vertical display:
Bubble level
Secondary display on customer side:
Battery compartment
Connection
network cable
ON/OFF
switch
RXB-BA-e-1012
8
Models with post-mounted display:
Bubble level
Post-mounted display,
backlit
,
revolvable
Battery compartment
Connection
network cable
ON/OFF switch
RXB-BA-e-1012 9
3.1 Overview of display
Operator display balance:
Weight Basic price
0.000 0.00
0.00
Loading status display Sales price
Secondary display on customer page:
Weight Basic price Sales price
RXB-BA-e-1012
10
Post-mounted display for models with tripod:
3.1.1 Display weight
Here, the weight of your goods is displayed.
The arrows next to the symbols show:
NET Net weight
aZeroing display
3.1.2 Display basic price
Here, enter your basic price in €/kg or €/100 g via keyboard. The basic price can be
switched to €/kg or €/100 g.
•Press -key, then 1 = basic price in €/kg
•Press -key, then 2 = basic price in €/100 g
The arrows next to the symbols show:
€/kg Basic price in €/kg
€/100 g Basic price in €/100 g
3.1.3 Display sale price
Here the sales price is displayed in Euro [€].
The arrows next to the symbols show:
FIX Stored basic price//FIX mode "on"
Weight
Basic price
Sales price
