KD-HDMIWPRX
Operating Manual
HDMI CAT5 Wall Plate Extender
The KD-HDMIWPRX is a CAT5 to HDMI and PCM wall plate extender receiver
capable of cable runs to distances of 125 feet at 1080P and can be used with or
without the supplied power adapter. This device is intended for use with Key
Digital’s KD-HDMIXWPTX, KD-HDMIXCAT5* or KD-CAT5XCAT5.
*Note that when used with the KD-HDMIXCAT5, the PCM input port of the KD-HDMIWPRX has no active signal
2
Quick Setup Guide
•Connect power, and then connect the CAT5 source cables to the
correct input ports (‘Data’ and ‘Control’) on the KD-HDMIWPRX
•Connect the digital coaxial audio output, if used, to the receiving
device (A/V receiver, etc)
•Finally, connect the HDMI output of the KD-HDMIWPRX to the
display or receiving device
3
Table of Contents
Installation Instructions……………………………………………………………………4
Technical Specifications ………………………………………………………………….6
Troubleshooting…………………………………………………………………………...6
Product Warnings………………………………………………………………………….7
Warranty………………………………………………………………………………......7
Contact Information……………………………………………………………………….8
4
Fig. 1
Power Indicato
r
Stable output video
si
g
nal
p
resent
Valid Source/Synch DVD/TV
connection indicator
Power Jack
HDMI output
CAT5 input on back
PCM Out
p
ut
5
Instructions
The KD-HDMIWPRX can receive power from either the CAT5 ‘Control’ connection or
via the supplied power adapter. When using the CAT5 cable to deliver power to the unit,
performance is subject to the following factors:
Ability of the CAT5 cable to deliver the required power over distance
Quality of the CAT5 cable.
1. Find a safe and convenient location for the KD-HDMIWPRX unit.
Before permanently securing the unit or final installation of cabling behind walls or
ceilings, test for proper operation of the unit and the cables in your system.
2. Power
In order to insure the best possible performance from the KD-HDMIWPRX, we
recommend using only the original Key Digital power supply. If you are using
the supplied power adapter, plug it into the power input jack on the side of the
unit. You should see the “Power” LED illuminate. (see Fig. 1)
3. Connections
•Plug in the CAT5 source cables to their corresponding ‘Data’ and ‘Control’
input ports of the KD-HDMIWPRX. If you are not using the supplied power
adapter, the “Power” LED should illuminate upon plugging in the ‘Control’
input cable if your HDMI source and the KD-HDMIWPTX, KD-
HDMIXCAT5 or KD-CAT5XCAT5 are powered on.
•Plug in the HDMI cable for your display or receiving device to the “Output”
port on the KD-HDMIWPRX. At this point, if both your source (KD-
HDMIWPTX, KD-HDMIXCAT5 or KD-CAT5XCAT5) and destination
devices are powered on, you should see the green “Power” LED and the blue
“HPD” LED lit.
•Connect the PCM port, if used, the the PCM input of the A/V receiver or other
destination device.
When a stable signal is established between your source and destination, the red
“Equalizer Active” LED will light. If this red LED indicator is blinking or not
illuminated, try shortening HDMI or CAT5 cable lengths or lowering the resolution
of the video signal.
6
DVI applications for the KD-HDMIWPRX
The KD-HDMIWPRX can also be used to extend DVI video cable runs. For these
applications, use DVI to HDMI (Key Digital model number KD-MFHDMI) adapters to
feed the HDMI input of the KD-HDMIWPRX.
Mounting the KD-HDMIWPRX unit
Before permanently securing the unit or final installation of cabling behind walls or
ceilings, test for proper operation of the unit and the cables in your system.
The wall plate can be mounted in a standard electrical box.
1. Remove the white, plastic face plate on the KD-HDMIWPRX
2. Connect CAT5 cables to the appropriate CAT5 ports on the back of the KD-
HDMIWPRX.
3. Secure the KD-HDMIWPRX metal bracket to the electrical box using the
screws supplied with the electrical box.
4. Re-install the plastic face plate on the front of the KD-HDMIWPRX
5. Secure the metal cable tie bracket to the face plate using the supplied screw.
This bracket provides a method for securing HDMI cables to the wall plate
with a single cable tie.
Technical Specifications
Connectors: One HDMI output connector
Two CAT5 input connectors labeled “Data” and “Control”
7
Power: External AC-DC power supply included (5 Volt DC @ 1 Amp,
110-240 VAC, 50-60 Hz)
Mechanical: No Fan Noise
Weight < 1Lb
Molded white ABS plastic face plate
Metal HDMI cable clip (1)
Resolutions Supported: All resolution up to 1080p/60
Dimensions: HxWxL = 4.75in x 2in x 3.25in
Troubleshooting
Most issues with the KD-HDMIWPRX setup will involve resolution and distance
performance. If you experience problems (no image, video artifacts, picture dropout,
noise) here are a few things to try.
1. Use the shortest possible HDMI and CAT5 cables between devices.
2. Lower the output resolution of the image source.
3. Use the provided power supply for the KD-HDMIWPRX instead of relying on
the voltage in the HDMI cable to power the unit.
4. Use Key Digital HDMI cables.
Other possible problems can result from self-made CAT5 cables. Please verify that the
CAT5 terminators are properly crimped and that the pinout is one-to-one, that is, each pin
corresponds to the same pin on the send and receive ends.
Product Warnings:
8
1) Connect HDMI, PCM and CAT5 cables before providing power to the unit.
2) Test for proper operation before securing unit behind walls or in hard to
access spaces.
3) If installing the KD-HDMIWPRX into wall or mounting bracket into sheet-
rock, provide proper screw support with bolts or sheet-rock anchors.
1. Read and follow all instructions.
2. Heed all warnings.
3. Do not use this device near water.
4. Clean only with dry cloth.
5. Install in accordance with the
manufacturer’s instructions.
6. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
7. Only use attachments/accessories specified by the manufacturer.
8. Refer all servicing to qualified service personnel. Servicing is required when the
device has been damaged in any way including:
•Damage to the power supply or power plug
•Exposure to rain or moisture
9
Key Digital Contacts
Repairs and Warranty Service
To obtain a Returned Materials Authorization (RMA) number, please contact:
Phone: (914)-667-9700
email: [email protected]
Technical Support
Phone: (914)-667-9700
Email: tech@KeyDigital.com
Customer support
Phone: (914)-667-9700
Email: [email protected]
