Key Digital FatCAT Rx KD-4AUVRX Manuale utente

KD-4AUVRX & KD-4PUV are multi-channel video hubs that allow for the

transmission or reception of Color or Black & White single-channel video signals

up to 4,000 feet (KD-4AUVRX) or 2,600 feet (KD-4PUV) with standard, unshielded

CAT5 cabling.

KD-4PUV

Four Channel Passive Video

Transceiver

KD-4AUVRX

Four Channel Active Video

Receiver

4 Channel Security Hubs

Operating Instructions

Page 2

Please read all instructions to insure safe operation of the product.

Table of Contents

KD-4AUVRX

About KD-4AUVRX ................................................2

Installation and Operation............................................2

Video Connections ..............................................2

Power Connections .............................................2

Uses with Active Transmitters ......................................3

Uses with Passive Transceivers & Multi-Channel Receivers / Transceivers .....3

Distance Adjustment Settings ........................................3

Mechanical / Technical Speciﬁcations ..................................5

KD-4PUV

About KD-4PUV ..................................................2

Installation and Operation............................................2

Video Connections ..............................................2

Uses with Passive Multi-Channel Receivers ..........................3

Uses with Active Receivers & Active Multi-Channel Receivers . . . . . . . . . . . . . . 3

Distance Adjustment Settings ........................................3

Mechanical / Technical Speciﬁcations ..................................5

Key Digital

Security Products Compatibility Chart .........................4

Important Product Warnings .........................................6

Safety Instructions .................................................6

How to Contact Key Digital ..........................................7

Warranty ........................................................8

Page 1

Quick Setup Guide

Step 1: Begin with all input/output devices turned off with power cables removed

Step 2: Connect video source, CAT5/6/7 cabling, and Power into Active or Passive

Transmitter Baluns

Step 3: Insert twisted pair wires into “UTP In” Phoenix Connector or “UTP In”

CAT5/6/7 RJ45 connector as instructed on chassis above RJ45 input.

See “Video Connections” section.

Step 4: Connect video display and/or DVR to “Video Out” of KD-4AUVRX

Receiver Hub

Step 5: Secure + and – power wires into Phoenix Connector “Power” inputs

Step 6: Make appropriate settings to “Distance Adjustment” dip switches. See

“Distance Adjustment Table” section

Step 7: Power on all input/output devices

CAT5/6/7

Video

4,000’

CAT5/6/7

Video

4,000’

CAT5/6/7

Video

CAT5/6/7

Video

CAT5/6/7

Video

CAT5/6/7

Video

Video Video

Video

Video Video

Video Video Video Video

CAT5/6/7

Video Video

Video

Video Video

Video

Monitor

DVR

Monitor

DVR DVR

Monitor Monitor

DVR

Monitor

DVR

Monitor

DVR DVR

Monitor Monitor

DVR

CAT5/6/7

KD-AUVTX

KD-4AUVRX

KD-AUVTX KD-AUVTX KD-AUVTX

KD-4AUVRX

KD-4PUV

Security Cam Security Cam Security Cam Security Cam

KD-4AUVRX

Four Channel Active Video

Receiver

Page 2

About KD-4AUVRX

➔Receives real-time Color or Black & White video

➔KD-AUVTX Extends video up to 4,000 ft using a standard CAT cable when used

with an Active Transmitter (Key Digital Model KD-AUVTX).

➔KD-4AUVRX extends video up to 2,600 ft when used with a Passive Transmitter

Balun (Key Digital Models KD-PVB and KD-4PUV)

➔Manual Distance Adjustment switches for optimum picture quality at any length

run up to 4,000 ft.

➔Built-in interference rejection enables wire bundling with other low-voltage lines

➔Built-in surge protection, ground loop isolation, gain and loss control, and video

detection

➔Compatible with CAT5/CAT5e/CAT6/CAT7 cabling

➔Works with generic power supplies, from DC/AC 9V to 12 V (not included)

Installation and Operation

Before permanently securing the unit for ﬁnal installation of

cabling behind walls or ceilings, test for proper operation of the

unit and the cables in your system.

Video Connections

➔KD-4AUVRX features two input options for video reception; a RJ45 port labeled

“UTP In” and a Phoenix Connector labeled “UTP In”. It is recommended that only

one of the two options be utilized as the CAT5/6/7 input.

»Phoenix Connector: Secure twisted pair wires into “Video

+” and “Video -” of Phoenix Connector block by loosening

screws, inserting twisted pairs, and tightening screws until

connection is secured. If using shielded CAT cabling, you

may insert shield into Pin 3 of Phoenix Connector.

»RJ45: Terminate the incoming CAT5/6/7 twisted pair wires

into your RJ45 connector in the following fashion:

Page 3

Pin Assignment for KD-4AUVRX

Pin# 1 2 3 4 5 6 7 8

Description Pair 1

Pair 1

Pair 2

Pair 3

Pair 2

Pair 4

Power Connections

➔Secure + and – power wires into “Power” inputs (Pin 1 and Pin 2) of Phoenix

Connector in the same fashion as securing Video connections. Positive (+) and

Negative (-) polarity can be inserted into any of the two “Power” inputs. Insert

Ground wire into Pin 3 if desired.

Uses with Active Transmitters

➔KD-4AUVRX units can be coupled with Key Digital’s KD-AUVTX Active Video

Transmitter as part of a multi-camera CCTV system. Using the KD-4AUVRX with

the KD-AUVTX Active Hub will provide quality video up to 4,000 ft.

Uses with Passive Transceivers & Passive Multi-Channel Transceivers

➔KD-AUVRX units can be coupled with a passive Transmitter/Transceiver (Key

Digital model KD-PVB) or a passive Multi-Channel Transmitter/Transceiver (Key

Digital model KD-4PUV) in your application. Coupling a Passive Transmitter/

Transceiver with the KD-AUVRX Active Receiver Balun will provide quality video

up to 2,600 ft.

Page 4

Distance Adjustment Settings

Dip Switch Conﬁgurations:

Configuration Distance

1111 1’-150’

0111 150’ – 800’

0100 800’ – 1300’

0010 1300’ – 2000’

1110 2000’ – 4000’

➔Adjustments should be set identically on Transmit (KD-AUVTX) and Receiver

(KD-4AUVRX) unit.

➔All distances listed above correspond to the pairing of active Transmit Balun

(KD-AUVTX) and Active Receive Balun (KD-4AUVRX).

CAT5/6/7

Video

4,000’

CAT5/6/7

Video

4,000’

CAT5/6/7

Video

CAT5/6/7

Video

CAT5/6/7

Video

CAT5/6/7

Video

Video Video

Video

Video Video

Video Video Video Video

CAT5/6/7

Video Video

Video

Video Video

Video

Monitor

DVR

Monitor

DVR DVR

Monitor Monitor

DVR

Monitor

DVR

Monitor

DVR DVR

Monitor Monitor

DVR

CAT5/6/7

KD-AUVTX

KD-4AUVRX

KD-AUVTX KD-AUVTX KD-AUVTX

KD-4AUVRX

KD-4PUV

Security Cam Security Cam Security Cam Security Cam

Page 5

Mechanical / Technical Speciﬁcations

Input 4 twisted pair from CAT5 line In on Phoenix type

stripping and cramping connector or 1 CAT5 on

RJ45 Connector

Output 2BNC connector for Composite Video 1Vpp with

75Ωat display side or Audio SPDIF or any other

format of video, audio, RS-232 or IR signaling.

Max. Signal Input /

Output Level:

Composite: 1.2Vpp on 75Ωterminated at display, DC

coupling or Line Audio or TTL +5V for digital RS-232,

IR signaling

Surge Protection Renewable solid state surge protection.

Bandwidth DC to 6 MHz

Video Format NTSC, PAL, SECAM

Impedance BNC side 75Ωunbalanced,

UTP side 100Ωbalanced

Humidity 0% to 95% non condensing

Distance 4000 feet Active Tx with Active Rx Coupling,

2000 feet Passive Tx with Active Rx coupling

Equalization and Gain

Adjustments

Passive impedance matching and ﬁxed equalization.

Manual adjustment by dip switches for CAT5 cable

length measurement up to 4000 ft

Video S/N Ratio: 58 dB RMS un-weighted;

65 dB RMS @5MHz weighted

Ground Isolation Ground connection available for STP or Ground

loop removal

Power Source: DC/AC 9-12V

Dimensions: WxDxH: 7.5”x3.3”x 1.75” excluding BNC

Weight: 2 lb

Operating Temperature -14F to +120F

Accessories: None

Page 6

Quick Setup Guide

Step 1: Begin with all input/output devices turned off with power cables removed.

Step 2: Connect video source and CAT5/6/7 cabling to Transmitter/Receiver Baluns

Step 3: Insert twisted pair wires into “UTP In” Phoenix Connector or “UTP In”

CAT5/6/7 RJ45 connector as instructed on chassis above RJ45 input.

See “Video Connections” section.

Step 4: Connect video source, display and/or DVR to “Video Out” of KD-4PUV

Transceiver Hub

Step 5: Power on all input/output devices.

KD-4PUV

Four Channel Passive Video

Transceiver

CAT5/6/7

Video

1,300’

CAT5/6/7

Video

1,300’

CAT5/6/7

Video

CAT5/6/7

Video

CAT5/6/7

Video

CAT5/6/7

Video

Video Video

Video Video Video Video

CAT5/6/7

Video

Video Video Video

Monitor Monitor Monitor Monitor

CAT5/6/7

KD-4PUV

KD-PVB KD-PVB KD-PVB KD-PVB

Security Cam Security Cam Security Cam Security Cam

Page 7

About KD-4PUV

➔Transmits or Receives real-time Color or Black & White video

➔Extends Black & White video up to 2,600 ft using a standard CAT cable when

used with an Active Receiver (Key Digital models KD-AUVRX or KD-4AUVRX).

➔Extends Black & White video up to 1,300 ft using a standard CAT cable when

paired with a Passive Transmitter Balun (Key Digital models KD-PVB or KD-4PUV).

➔Built-in interference rejection enables wire bundling with other low-voltage lines

➔Compatible with CAT5/CAT5e/CAT6/CAT7 cabling

Installation and Operation

Before permanently securing the unit for ﬁnal installation of

cabling behind walls or ceilings, test for proper operation of the

unit and the cables in your system.

Video Connections

➔KD-4PUV features two options for video reception; a RJ45 port labeled “UTP In”

and a Phoenix Connector labeled “UTP In”. It is recommended that only one of the

two options be utilized as the CAT5/6/7.

»Phoenix Connector: Secure twisted pair wires into “Video

+” and “Video -” of Phoenix Connector block by loosening

screws, inserting twisted pairs, and tightening screws until

connection is secured. If using shielded CAT cabling, you

may insert shield into Pin 3 of Phoenix Connector.

»RJ45: Terminate the incoming CAT5/6/7 twisted pair wires

into your RJ45 connector in the following fashion:

Pin Assignment for KD-4AUVRX

Pin# 1 2 3 4 5 6 7 8

Description Pair 1

Pair 1

Pair 2

Pair 3

Pair 2

Pair 4

Page 8

Uses with Passive Multi-Channel Receivers

➔KD-4PUV units can be paired with additional KD-4PUV 4-Channel Passive Video

Receiver Hubs as part of a multi-camera CCTV system. Using the KD-4PUV with

the KD-4PUV Passive Hub will provide equivalent distances as when coupled with

other Key Digital Passive Transceiver Baluns; 1,300 feet.

Uses with Active Receivers & Active Multi-Channel Receivers

➔KD-4PUV units can be used as a Transmitter and coupled with an Active Receiver

(Key Digital model KD-AUVRX) or an Active Multi-Channel Receiver (Key Digital

model KD-4AUVRX). Coupling a KD-4PUV 4-Channel Passive Transmitter with

the KD-AUVRX Active Receiver Balun or KD-4AUVRX Active 4-Channel Receiver

will provide quality video up to 2,600 ft.

Note: The usage of a KD-4PUV balun to receive video signals from an Active Transmitter

(Key Digital model KD-AUVTX) is not recommended. For best results in an active/passive

coupling, it is recommended that the KD-4PUV Passive Video Balun be used as the

Transmitter, while the KD-AUVRX or KD-4AUVRX Active Video Receiver Baluns be used as

the Receiver.

CAT5/6/7

Video

1,300’

CAT5/6/7

Video

1,300’

CAT5/6/7

Video

CAT5/6/7

Video

CAT5/6/7

Video

CAT5/6/7

Video

Video Video

Video Video Video Video

CAT5/6/7

Video

Video Video Video

Monitor Monitor Monitor Monitor

CAT5/6/7

KD-4PUV

KD-PVB KD-PVB KD-PVB KD-PVB

Security Cam Security Cam Security Cam Security Cam

Indice

Altri manuali Key Digital Interruttore

Key Digital

Key Digital KD-UFS42 Manuale utente

Key Digital

Key Digital KD-S2x1X Manuale utente

Key Digital

Key Digital KD-HDMI2X1 Manuale utente

Key Digital

Key Digital Champion KD-2X1CS Manuale utente

Key Digital

Key Digital KD-CSW2X1 Manuale utente

Key Digital

Key Digital KD-HDMI4X1 Manuale utente

Key Digital

Key Digital KD-XWPS Manuale utente

Key Digital

Key Digital Phantom KD-HDSW2X1 Manuale utente

Key Digital

Key Digital Champion KD-2X1 Manuale utente

Key Digital

Key Digital KD-S2x1X-2 Manuale utente

Key Digital

Key Digital KD-HDMI2X1 Manuale utente

Key Digital

Key Digital KD-Pro4x1X Manuale utente

Key Digital

Key Digital KD-HDMI2X8P Manuale utente

Key Digital

Key Digital KD-S2x1 Manuale utente

Key Digital

Key Digital Champion KD-2X1 Manuale utente

Key Digital

Key Digital Phantom KD-HD2x1ProK Manuale utente

Key Digital

Key Digital KD-HDMI2X1 Manuale utente

Key Digital

Key Digital KD-PS42 Manuale utente

Key Digital

Key Digital KD-IP1022ENC Manuale utente

Key Digital

Key Digital KD-CSW4X1 Manuale utente

Key Digital

Key Digital KD-CSW2X1 Manuale utente

Key Digital

Key Digital KD-IP1080Tx Manuale utente

Key Digital

Key Digital Black Bull KD-HDRV2X1 Manuale utente

Key Digital

Key Digital Champion SeriesKD-2x1CSK Manuale utente

Manuali Interruttore popolari di altre marche

URC

URC Total Control MFS-8 Manuale utente

Azbil

Azbil HPQ-D11 Manuale utente

Sony

Sony DFS-900M Manuale utente

SICK

SICK i17S Manuale utente

F&F

F&F SZR-277 Manuale utente

Shure

Shure UAMS/BK Manuale utente

Dräger

Dräger X-zone Switch Off Manuale utente

Asco

Asco Joucomatic 349 Series Manuale utente

BT Mini Hub Manuale utente

D-Link

D-Link DES-1226G Manuale utente

Johnson Controls

Johnson Controls FS80-C Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuale utente

MicroNet

MicroNet SP1200A Manuale utente

Ruijie

Ruijie RG-PF2920 Series Manuale di installazione e funzionamento

Altinex

Altinex DA1914SX Manuale utente

MiLAN

MiLAN MIL-SM2401M Manuale utente

RJM

RJM MASTERMIND PBC/6X Manuale utente

Atlas

Atlas MMK-KVM8 Manuale utente
