N5182BX07 Frequency Extender

9 kHz to 7.2 GHz

Keysight N5182BX07 User's Guide

Description

Figure 1

N5182BX07

Description

The Keysight N5182BX07 Frequency Extender is an accessory for the MXG

(N5182B) or EXG (N5172B) that extends the frequency range of vector signals

to cover 9 kHz to 7.2 GHz. The N5182BX07 is especially well suited for

802.11ax measurements, due to its excellent phase noise and EVM.

The Keysight N5182BX07 has the following key features:

— Frequency range of operation: 9 kHz to 7.2 GHz.

— Bandwidth: 160 MHz.

— 802.11ax EVM at 7.2 GHz, 160 MHz BW: <-47 dB (0.45%) for output up to

+5 dBm.

— Max output power: +18 dBm (EVM will degrade as power increases above

+5 dBm).

— Total height: 3U (MXG is 2U and frequency extender is 1U).

— Seamless integration with MXG/EXG, including control from the front panel

or automation using SCPI via LAN, GPIB, or USB.

— Single RF output for full frequency coverage, with bypass mode for

frequencies < 5.9 GHz.

— Available as an upgrade for an existing N5182B or N5172B with power sensor

calibration at the customer site.

N5182BX07 Frequency Extender with MXG Vector Signal Generator

Keysight N5182BX07 User's Guide

N5182BX07

Description

Verifying the Shipment

To verify the contents shipped with your product, refer to the “Box Content

List” included with the shipment.

Inspect the shipping container. If the container or packing material is

damaged, it should be kept until the contents of the shipment have been

checked mechanically and electrically. If there is physical damage refer to

“Contacting Keysight” on page 40. Keep the damaged shipping materials (if

any) for inspection by the carrier and an Keysight Technologies

representative.

Equipment

Only Keysight approved accessories shall be used.

N5182BX07 Frequency Extender, with

•USB cable (Type A to Type C)

•10 MHz cable (BNC)

•RF cable, (N-type)

•Power cord

N5182B MXG-B or N5172B EXG-B, with

•Option 506: Frequency range from 9 kHz to 6 GHz

•Option FRQ: Frequency Extender Connectivity

•Licenses for playing 802.11ax waveforms

•Firmware B.01.85 or later

•Power cord

Other Required Equipment, Sold Separately

Keysight N5182BX07 User's Guide

N5182BX07

General Performance

This instrument has an auto-ranging line voltage input. Be sure

the supply voltage is within the specified range and voltage

fluctuations do not exceed 10% of the nominal supply voltage.

Power Requirements

— 100/120V VAC, 220/240 VAC (50/60 Hz)

— N5182BX07 maximum power is 160 W

Environmental Tests

The N5182BX07 complies with all applicable safety and regulatory

requirements for the intended location of use.

— Operating Environment (for indoor use only)

— Operating Temperature 0 to 55 °C

—Storage Temperature :−40 to +70 °C

— Operating and Storage Altitude: 0 to 3,000 meters (~ 9,842 feet)

— Maximum Relative Humidity (non-condensing): 95% RH up to 40 °C,

decreasing linearly to 50% RH at 55 °C. From 40 °C to 55 °C, the

maximum % Relative Humidity follows the line of constant dew point.

Environmental Tests in the User Guide are for reference only.

Samples of this product are being type-tested in accordance with

the Keysight Environmental Test Manual and this testing is expected

to be completed by January 31, 2020. These tests will verify the

product is robust against the environmental stresses of storage,

transportation, and end-use. Those stresses include, but are not

limited to, temperature, humidity, shock, vibration, altitude, and

power line conditions. Test methods are aligned with IEC 60068-2

and levels are similar to MIL-PRF-28800F Class 3.

Keysight N5182BX07 User's Guide

N5182BX07

General Performance

Dimensions and Space Requirements

Table 1Dimensions

Width

Length

Height

Standard installation of the N5182BX07 includes configuration and

installation on a customer-provided lab bench or table top of adequate

size and strength.

426 mm (16.8")

Size, including RF connectors and feet

485 mm (19.1")

59 mm (2.3")

Width

Length

Height

426 mm (16.8")

465 mm (18.3")

44 mm (1.75")

Size, excluding RF connectors and feet

≤ 6.2 kg (13.7 lb)

Weight

Keysight N5182BX07 User's Guide

Specifications

N5182BX07

Specifications

The N5182BX07 Frequency Extender extends any N5182B MXG or N5172B

EXG with Option 506 to cover the 802.11ax bands from 2.4 to 7.2 GHz with

exceptional error vector magnitude (EVM) accuracy.

For frequencies of 5.9 – 7.2 GHz, the N5182BX07 optimizes EVM by

holding the MXG or EXG within a narrow frequency and amplitude range,

and then adjusting output amplitude with a mechanical attenuator with

1 dB steps. This provides excellent EVM over a wide range of amplitude

levels. The attenuator is rated for 2 million cycles. A mechanical switch

rated at 5 million cycles is used to switch between the 9 kHz to <5.9 GHz

band and the 5.9 - 7.2 GHz band. To maximize the life of the attenuator

and the switch in automated tests across both frequency and amplitude,

the optimal test order is as follows:

•First measure all frequency and amplitudes below 5.9 GHz

•Next measure all frequency and amplitudes of 5.9 – 7.2 GHz with

amplitude as the outer loop and frequency as the inner loop. In other

words, measure all frequencies for a given power level, then switch

power level.

General Specifications

Remote Programming Interfaces

MXG or EXG can be controlled through GPIB, LAN, or USB.

N5182BX07 is controlled by MXG or EXG using one USB port.

ISO Compliant

Recommended Calibration Cycle

12 months.

This instrument is manufactured in an ISO9001 registered facility

in concurrence with Keysight Technologies' commitment to quality.

List and sweep features are not supported when using the N5182BX07.

Keysight N5182BX07 User's Guide

Indice

Altri manuali Keysight Technologies Estensione

Keysight Technologies

Keysight Technologies V3050A Manuale utente

Manuali Estensione popolari di altre marche

SY HDBT-60T Manuale utente

Appsys ProAudio

Appsys ProAudio ADX-16 Manuale utente

Atlona

Atlona RS232 Manuale utente

IDK

IDK OPF-TH1000-A Manuale utente

Enable-IT

Enable-IT 824WP Manuale utente

Worx

Worx Landroid RadioLink WA0864 Scheda tecnica

TP-Link

TP-Link TL-WA730RE Manuale utente

Camplex

Camplex CMX-HDMI-SFPL Manuale utente

SC&T

SC&T HE03-4K Manuale utente

Marmitek

Marmitek MegaView70 Manuale utente

Samsung

Samsung SCS-26UC4 Manuale utente

Foxun

Foxun SX-GES24 Manuale utente

MuxLab

MuxLab 500771 Manuale utente

foxunhd

foxunhd SX-AEX01 Manuale utente

TERK Technologies

TERK Technologies LFIRX2 Manuale utente

Devolo

Devolo Audio Extender Manuale

Edimax

Edimax EW-7438RPn V2 Manuale utente

Shinybow USA

Shinybow USA SB-6335T5 Manuale utente
