SSDNow

For Desktops

Document No. 4808065-001.A02 SSDNow Desktop Installation Guide

07-16-2009

Installation Guide

Your purchase of the SSDNow with Accessory Kit will allow you to enjoy the benefits of

increased system performance and reliability. All hardware and software necessary to

replace your Desktop PC's internal hard drive with the SSDNow Solid State Drive (SSD)

is included. The Acronis®True Image HD software*, an imaging program that copies the

contents of one computer hard disk and loads those contents to another system drive, will

take you through the cloning process. This software allows you to move your Operating

System and your personal data from your current system hard drive to your new SSD.

Once the Acronis®True Image HD cloning process is complete and the data is

successfully transferred to your SSD, your hard drive can then be used as a secondary

drive for data storage.

*The software provided in this kit does not support imaging/cloning of RAID or Spanned disk arrays.

There are tools and features included in the Acronis software that are not applicable to this product bundle.

This manual provides instructions for the Cloning feature only. Please refer to the Acronis “Help” menu,

located within the software application, for instructions on the use of any other software features.

SSDNow

For Desktops

This device complies with Part 15 FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference. (2) This device must

accept any interference received, including interference that may cause undesired

operations.

This Equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio

communications.

However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to try and

correct the interference by one or more of the following:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit, different from that to which the

receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

SSDNow

For Desktops

TABLE OF CONTENTS

Kit Includes:....................................................................................................................4

Tools Needed: .............................................................................................................4

System Requirements ..................................................................................................5

Handling Precautions ......................................................................................................6

Hardware Installation ..................................................................................................6

Setup and Use Acronis®True Image HD.....................................................................7

Set “Hard Drive Boot Priority”.................................................................................. 12

SSDNow

For Desktops

Kit Includes:

2.5” to 3.5” Mounting Kit

Brackets

6/32” pan head

screws X 4

M3 flat head

screws X 4

SATA power adapter

SATA data cable

cloning software CD

SSDNow

Tools Needed:

●Phillips head screw driver

●Computer system manual (optional)

SSDNow

For Desktops

System Requirements

Operating System: Windows Vista® (SP1), Windows XP®(SP3) and Windows

2000®(SP4)

Pentium processor or higher

128MB RAM

CD-ROM or DVD drive for bootable media creation

Available SATA Connector

Available 3.5 inch drive bay

ATTENTION: PLEASE READ BEFORE BEGINNING INSTALLATION.

●If the SSD provided in this kit is larger in capacity than the hard drive

currently in your system, proceed to Handling Precautions.

●If the SSD provided in this kit is smaller in capacity than the hard drive

currently in your system, please confirm that the used capacity on the system hard

drive is not larger than the capacity of your new SSD. Perform the following steps

to determine the Used Space on the system hard drive:

1) Boot your computer to your desktop.

2) Double click on My Computer (Computer in Vista) located on your desktop or

via the Start Menu.

3) Single right-click on the C: drive and select Properties. The Properties

window for the C: drive will appear (Figure 1):

Figure 1: (C :) drive Properties

If the used capacity is greater than the capacity of the SSD, it is required that you move

some of your data such as pictures, movies, music, etc. off of the drive to an alternative

data source (e.g., external hard drive or USB drive) until the Used space is no more than

SSDNow

For Desktops

85% of your new SSD capacity. This will help to ensure that the imaging process is

successful. The following chart may be useful as a guide:

SSD capacity

Adjusted HDD Used Space

32GB

27GB or less

40GB

34GB or less

64GB

54GB or less

80GB

66GB or less

128GB

109GB or less

160GB

136GB or less

256GB

218GB or less

512GB

423GB or less

Adjusted HDD Used space = SSD capacity X 85%

After the cloning process has been successfully completed, these files can be moved back

to their original location on the hard drive.

Handling Precautions

To prevent damage from static electricity, observe the following precautions:

●Allow the drive to remain in the anti-static container until you are ready to install the

SSD.

●Wear a wrist strap and connect the ground strap to the computer case to minimize

static electricity.

●Use care in handling the drive. Do not touch the connectors.

Hardware Installation

1. Turn off the power to your computer and disconnect the power source.

2. Remove the system chassis cover according to the system manufacturer’s

instructions.

3. Attach the 2.5” to 3.5” mounting brackets (provided) to the SSD by aligning the

mounting screw holes on the brackets with those on the SSD and inserting the M3

flat head screws provided.

4. Locate an available 3.5 inch drive bay inside your computer and install the SSD

using the 6/32” pan head screws (provided).

Note: Your system may require proprietary chassis screws, rails or a bracket

system to be used with its drive bay(s). If this is the case, please attach that

hardware to the 2.5” to 3.5” mounting bracket for compatibility with your

computer chassis. Refer to your system manufacturer’s documentation for

instructions.

SSDNow

For Desktops

5. Attach one end of the SATA data cable (provided) to the SATA interface

connector on your computer’s motherboard or SATA host adapter. Below is an

example of what a motherboard SATA connector might look like:

Figure 2: Desktop PC motherboard with 4 SATA connectors.

The number of connectors on each system will vary.

Note: SATA connectors are keyed to ensure correct orientation.

6. Attach the other end of the SATA interface cable to the SSD.

7. Attach the power cable or power adapter (provided) to the SSD.

8. You are now ready to copy your data from the system hard drive to the SSD using

the cloning software CD provided.

Setup and Use Acronis®True Image HD

IMPORTANT: ** It is strongly recommended that you uninstall any Trial versions

of Acronis software prior to installing full versions.

1. Insert the Acronis True Image HD software CD into the system CD-ROM drive.

2. Restart the system.

3. The Acronis True Image HD CD is a bootable disk and will boot to the Acronis

True Image HD screen.

Note: If the system does not boot to the Acronis True Image HD screen and

instead boots to Windows, perform the following:

1) Restart the computer. While the system is restarting, run the system

setup program (BIOS). The BIOS can be activated by pressing a

special key such as ESC, F1, F12 or DELETE. (Refer to your system

manufacturer’s documentation for the correct key.)

2) While in the system BIOS, change the boot order so that CD-

ROM/DVD is the first boot device.

3) Save the settings and exit BIOS. (For more detailed instructions on

configuring the BIOS, consult your system manufacturer’s

documentation.)

4) Restart the computer. When the computer restarts, it should now boot

to the Acronis True Image HD page.

SATA connector

SSDNow

For Desktops

4. Select the Acronis True Image HD icon from the Acronis True Image HD screen

(Figure 3).

Note: It may take a few minutes for the next screen to come into view.

Figure 3: Acronis True Image HD

SSDNow

For Desktops

5. Select Clone Disk from the Pick a Task screen (Figure 4).

Figure 4: Pick a Task

6. The Welcome to the Disk Clone Wizard! screen will appear and the wizard will

guide you through the cloning process (Figure 5). Click Next to continue.

Figure 5: Disk Clone Wizard

Note: If you receive an error message stating "This program is designed to work

with two or more drives," check all connections to both the hard drive and the

SSD. Ensure that the SATA data and power cables are connected to the drives

and motherboard. If all connections are in place, it is possible that your system

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Kingston Technology Magazzinaggio

Kingston Technology

Kingston Technology SSDNow M-series Manuale utente

Kingston Technology

Kingston Technology Ironkey D300 Manuale utente

Kingston Technology

Kingston Technology IRONKEY D300SM Manuale utente

Kingston Technology

Kingston Technology DataTraveler SE9 Manuale utente

Kingston Technology

Kingston Technology IronKey Vault Privacy 80 Manuale utente

Kingston Technology

Kingston Technology IRONKEY D500SM Manuale utente

Kingston Technology

Kingston Technology IRONKEY S1000B Manuale utente

Kingston Technology

Kingston Technology DataTraveler 410 (DT410) Manuale utente

Kingston Technology

Kingston Technology HyperX Manuale utente

Kingston Technology

Kingston Technology DataTraveler 2000 Manuale utente

Kingston Technology

Kingston Technology DT111 Manuale utente

Kingston Technology

Kingston Technology DataTraveler 4000 Manuale utente

Kingston Technology

Kingston Technology imation S250 Manuale utente

Kingston Technology

Kingston Technology Wi-Drive Manuale utente

Kingston Technology

Kingston Technology IronKey 1000B Manuale utente

Kingston Technology

Kingston Technology Vault Privacy-Managed Manuale utente

Kingston Technology

Kingston Technology SDXC Manuale utente

Kingston Technology

Kingston Technology DataTraveler 4000 Manuale utente

Kingston Technology

Kingston Technology MyTraveler Manuale utente

Kingston Technology

Kingston Technology Wi-Drive 16GB Manuale utente

Kingston Technology

Kingston Technology IRONKEY Vault Privacy 50 Manuale utente

Kingston Technology

Kingston Technology DataTraveler 4000 Manuale utente

Kingston Technology

Kingston Technology IRONKEY D500S Manuale utente

Kingston Technology

Kingston Technology DataTraveler Manuale utente

Manuali Magazzinaggio popolari di altre marche

QNAP

QNAP TS 32PXU Series Manuale utente

LaCie

LaCie RUGGED RAID Manuale utente

Freecom

Freecom CLS DOCK Manuale utente

PNY

PNY Attache P-FD64MBATT3 Manuale utente

HP StorageWorks MSL2024 Manuale utente

OLT

OLT 6x6 Maximizer Manuale utente

Transcend

Transcend JetFlash 160 Manuale utente

LaCie

LaCie RUGGED MINI Manuale utente

Thunderbolt

Thunderbolt 600 Manuale utente

Panasonic

Panasonic LB-DH8 series Manuale

Intel

Intel RAID High Availability Manuale utente

LaCie

LaCie 12big Thunderbolt 3 Manuale utente

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuale utente

Panasonic

Panasonic LKM-F931-1 Manuale utente

Tabernus

Tabernus Enterprise Erase E2400 Manuale utente

Rocstor

Rocstor COMMANDER 3F series Manuale utente

HP P9000 Manuale utente

Western Digital

Western Digital Ultrastar Data60 Manuale utente
