Kingston Technology SSDNow M-series Manuale utente

Installation Guide

SSDNow

Find the language and latest documentation for your Kingston® SSDNow here.

SSDNow Installation Guide

Simplied Chinese . . . . .

Traditional Chinese . . . .

Hindi..................

Arabic.................

. . . . . . . . . . . . For instructions in English

. . . . . . . . . . . . . . . . . . Para instrucciones en español

. . . . . . . . . Für Anleitungen in Deutsch

. . . . . . . . . . . . . . . . . . Pour des instructions en français

. . . . . . . . . . . . . . . . . . Per le istruzioni in italiano

............Por as instruções em português

. . . . . . . . . . . . . . . . . . Voor instructies in het Nederlands

. . . . . . . . . . . . . . . . . . Instrukcje w jezyku polskim

. . . . . . . . . . . . . . . . . . Для инструкции на русском

. . . . . . . . . . . . . . . . . . Turkce talimatlar icin

. . . . . . . . . . . . . . . . . . Korean

. . . . . . . . . . . . . . . . . . Japanese

. . . . . . . . . . . . . . . . . . Thai

SSDNow

For Notebooks

Document No. 4808066-001.A02 SSDNow Notebook Installation Guide

07-16-2009

Installation Guide

Your purchase of the SSDNow with Accessory Kit will allow you to enjoy the benefits of

increased system performance and reliability. All hardware and software necessary to

replace your Notebook PC's internal hard drive with the SSDNow Solid State Drive

(SSD) is included. The Acronis®True Image HD software*, an imaging program that

copies the contents of one computer hard disk and loads those contents to another system

drive, will take you through the cloning process. This software allows you to move your

Operating System and your personal data from your current system hard drive to your

new SSD. Once the Acronis®True Image HD cloning process is complete and the data is

successfully transferred to your SSD, your hard drive can then be used as a secondary

drive for data storage.

*The software provided in this kit does not support imaging/cloning of RAID or Spanned disk arrays.

There are tools and features included in the Acronis software that are not applicable to this product bundle.

This manual provides instructions for the Cloning feature only. Please refer to the Acronis “Help” menu,

located within the software application, for instructions on the use of any other software features.

SSDNow

For Notebooks

This device complies with Part 15 FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference. (2) This device must

accept any interference received, including interference that may cause undesired

operations.

This Equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio

communications.

However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to try and

correct the interference by one or more of the following:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit, different from that to which the

receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

SSDNow

For Notebooks

TABLE OF CONTENTS

Kit Includes:................................................................................................................4

Tools Needed: .............................................................................................................4

System Requirements ..................................................................................................5

Handling Precautions ..................................................................................................6

Hardware Installation ..................................................................................................6

Setup and Use Acronis®True Image HD.....................................................................8

SSDNow

For Notebooks

Kit Includes:

●external drive enclosure (2-piece unit consisting of a top and bottom panel)

●USB cable (1)

●cloning software CD (1)

●SSDNow (1)

Tools Needed:

●Phillips head screw driver

●Computer system manual (optional)

SSDNow

For Notebooks

System Requirements

Operating System: Windows Vista® (SP1), Windows XP®(SP3) and Windows 2000®

(SP4)

Pentium processor or higher

128MB RAM

CD-ROM or DVD drive for bootable media creation

ATTENTION: PLEASE READ BEFORE BEGINNING INSTALLATION.

●If the SSD provided in this kit is larger in capacity than the hard drive currently in

your system, please proceed to Handling Precautions.

●If the SSD provided in this kit is smaller in capacity than the hard drive currently in

your system, please confirm that the used capacity on the system hard drive is not

larger than the capacity of your new SSD. To determine the Used space on your hard

drive, do the following:

1) Boot your computer to your desktop.

2) Double click on My Computer (Computer in Vista) located on your desktop or

via the Start Menu.

3) Single right-click on the C: drive and select Properties. The Properties window

for the C: drive will appear (Figure 1):

Figure 1: (C :) drive Properties

If the used capacity is greater than the capacity of the SSD, it is required that you move

some of your data such as pictures, movies, music, etc. off of the drive to an alternative

data source (e.g., external hard drive or USB drive) until the Used space is no more than

SSDNow

For Notebooks

85% of your new SSD capacity. This will help to ensure that the imaging process is

successful. The following chart may be useful as a guide:

SSD capacity

Adjusted HDD Used Space

32GB

27GB or less

40GB

34GB or less

64GB

54GB or less

80GB

66GB or less

128GB

109GB or less

160GB

136GB or less

256GB

218GB or less

512GB

423GB or less

Adjusted HDD Used space = SSD capacity X 85%

After the cloning process has been successfully completed, these files can be moved back

to their original location on the hard drive.

Handling Precautions

To prevent damage from static electricity, observe the following precautions:

●Allow the drive to remain in the anti-static container until you are ready to install the

SSD.

●Wear a wrist strap and connect the ground strap to the computer case to minimize

static electricity.

●Use care in handling the drive. Do not touch the connectors.

Hardware Installation

Note: Do not install the SSD in the external drive enclosure.

1. Transfer your Hard Drive to the External Drive Enclosure:

1) Turn off the power to your computer, disconnect the power source and

remove the battery pack from your notebook.

2) Remove the system hard drive from your notebook and disassemble the

system drive bracket. (The system drive bracket will be used later to install the

SSD in your notebook.) Refer to your system manufacturer’s documentation

for further instructions.

SSDNow

For Notebooks

3) To open the external drive enclosure, press down on the release button

(Figure 2a) and slide the two panels apart (Figure 2b).

Figure 2a: Press the release button.

Figure 2b: Slide panels apart.

The external drive enclosure consists of a top panel which is affixed to the

22PIN SATA connector (Figure 3a) and a bottom panel (Figure 3b).

Figure 3a: top panel

Figure 3b: bottom panel

4) To assemble the system hard drive together with the external drive enclosure,

align the pins of the system hard drive to the 22PIN SATA connector and

push them together until the drive is securely in place (Figure 4).

Figure 4: Secure hard drive to 22PIN SATA

connector.

SATA connector

Release button

SSDNow

For Notebooks

5) Align the top and bottom panels of the enclosure and slide them together until

they snap into place (Figure 5).

Figure 5: Snap panels in place.

2. Install the SSD in your Notebook and attach the External Drive Enclosure:

1) Assemble the SSD with the system drive bracket and insert the drive into the

drive bay of your notebook. Refer to your system manufacturer’s

documentation for instructions.

2) Using the USB cable provided, attach the system hard drive (installed in the

provided external drive enclosure) to your notebook via any USB port.

3) You are now ready to copy your data from the system hard drive to the SSD

using the cloning software CD provided.

Setup and Use Acronis®True Image HD

IMPORTANT: ** It is strongly recommended that you uninstall any Trial versions

of Acronis software prior to installing full versions.

1. Insert the Acronis True Image HD software CD into the system CD-ROM drive.

2. Restart the system.

3. The Acronis True Image HD CD is a bootable disk and will boot to the Acronis

True Image HD screen.

Note: If the system does not boot to the Acronis True Image HD screen and

instead boots to Windows or fails to boot at all, perform the following:

1) Restart the computer. While the system is restarting, run the system

setup program (BIOS). The system BIOS can be activated by pressing

a special key such as ESC, F1, F12 or DELETE. (Consult your

computer system’s documentation for the correct key.)

SSDNow

For Notebooks

2) While in the system BIOS, change the boot order so that CD-ROM is

the first boot device.

3) Save the settings and exit BIOS. (For more detailed instructions on

configuring the BIOS, consult your computer system’s

documentation.)

4) Restart the computer. When the computer restarts, it should now boot

to the Acronis True Image HD page.

4. Select the Acronis True Image HD icon from the Acronis True Image HD screen

(Figure 6).

Note: It may take a few minutes for the next screen to come into view.

Figure 6: Acronis True Image HD
