KitchenAid KBLS22KVSS00 Manuale utente

CABINET PARTS

For Model: KBLS22KVSS00

(Stainless Steel−LH)

10−08 Litho In U.S.A. (mat) (eeb) Part No. W10234664 Rev. A

REFRIGERATOR

CABINET PARTS

For Model: KBLS22KVSS00

(Stainless Steel−LH)

W10234664

Illus. Part

No. No. DESCRIPTION

1 Literature Parts

W10137649

Use & Care Guide

W10212714

Energy Guide

W10168777

Tech Sheet

2 Cabinet (Not A

Serviceable Part)

3 67001131 Plug, Button

4 67006662 Screw

12580304KVF

Roller Foot

Assembly

6 12627302 Grille, Clip

7 67006642 Pin, Center Hinge

8 67006611 Bolt, Adjusting

(Rear)

9 67006521 Screw

10 12456801 Bracket, Roller

11 67006380 Screw

12 67006473 Screw

13 67005064 Label, Fill Tube

14 67006303 Screw

15 Hinge, Center

12607104ED

Black

16 67003868 Foot Brake (2)

17 Cover, Corner

67003485 Black

12566606ED

Hinge, Top

W10208641

Bracket, Foot

20 67006473 Screw

21 67001012 Cover, Hinge

22 Grille Assembly

(Includes Clips)

67006954 Black

23 67001098 Cover, Fill Tube

25 67006425 Screw

27 67001097 Cover, Water Valve

12575101WD

Cover, Unit

29 12479901 Plate, Cover

30 67003796 Insulation, Sound

W10164397

Tube, Drain

W10157973

Clip, Drain Tube

33 M0286708 Nut, Speed

34 67005127 Roller

35 M1205302 Pin

36 67006737 Screw

37 B5759649 Gasket

REFRIGERATOR LINER PARTS

For Model: KBLS22KVSS00

(Stainless Steel−LH)

W10234664

REFRIGERATOR LINER PARTS

For Model: KBLS22KVSS00

(Stainless Steel−LH)

W10234664

Illus. Part

No. No. DESCRIPTION

1 Liner (Not A

Serviceable Part)

Y67003896

Bracket, Control

and Lights

W10212326

Overlay

W10185585

Module, Control

W10207861

Board, Control

6 C3680310 Switch, Light

7 67003897 Cover, Light

8 67003901 Housing, Light

9 A0282812 Bulb, Light (2)

Y12570701

Socket, Light (2)

11 67003900 Insert,

Damper Cover

12 67006602 Screw (2)

13 67003899 Cover, Damper

14 67006604 Insulation

W10127429

Control, Damper

(Includes Harness)

16 12002355 Thermistor

Following Parts Not Illustrated

67005644 Harness, Controls

(Refrigerator)

FREEZER LINER PARTS

For Model: KBLS22KVSS00

(Stainless Steel−LH)

W10234664

FREEZER LINER PARTS

For Model: KBLS22KVSS00

(Stainless Steel−LH)

W10234664

Illus. Part

No. No. DESCRIPTION

1 Liner (Not A

Seviceable Part)

2 67001291 Gasket, Foam

3 12002497 Gear (2)

(Includes RT & LT)

4 67003905 Cover, Light

5 67004261 Shaft

Y12570701

Socket, Light

8 67006473 Screw

9 A0282812 Bulb, Light

10 67001035 Housing, Light

11 67005872 Cover, Evaporator

12 67006425 Screw (7)

13 Bracket, Door

W10122147

Left

W10122148

Right

14 67003906 Housing, Lighting

15 10623002 Clip, Evap. Motor

16 67005653 Switch, Light

18 Cradle, Basket

W10187668

Left

W10187667

Right

W10120018

Slide, Drawer

20 67001776 Gasket, Bottom

21 Adapter, Slide

W10149390

Left

W10149391

Right

W10175909

Grille, Fz Air

W10167023

Shroud, Evap.Fan

24 2169142 Blade, Fan

(Evaporator)

W10150583

Grommet

W10199049

Motor, Evaporator

27 D7753903 Funnel, Drain

28 M0500703 Seal

29 B8381501 Gasket

30 12002355 Thermistor

31 67003924 Cover, Thermistor

32 67006406 Screw (6)

33 67006530 Screw

Following Parts Not Illustrated

67006095 Harness, Lights

(Freezer)

REFRIGERATOR DOOR PARTS

For Model: KBLS22KVSS00

(Stainless Steel−LH)

W10234664

REFRIGERATOR DOOR PARTS

For Model: KBLS22KVSS00

(Stainless Steel−LH)

W10234664

Illus. Part

No. No. DESCRIPTION

1 Door, Refrigerator

13023840SQ

Stainless

2 Plug, Vent

67004838 Black

3 67003819 Door, Dairy

(Includes #4)

4 67001279 Tray, Dairy

12849114SP

Bucket, Shelf (3)

(Medium)

W10046610

Nameplate

7 Gasket, Door

W10164035

Black

8 Handle, Door

W10119644

Stainless

9 67006113 Mount, Handle

10 Closure, Door

67003639 Black

12643911SP

Bucket, Shelf (1)

(Small)

12 Bushing, Door

67004978 Black

13 12690502 Retainer, Door

14 67006287 Screw

12567321SP

Gripper, Medium(4)

16 67006113 Mount, Handle

17 67005626 Caddy, Can

FREEZER DOOR PARTS

For Model: KBLS22KVSS00

(Stainless Steel−LH)

W10234664

FREEZER DOOR PARTS

For Model: KBLS22KVSS00

(Stainless Steel−LH)

W10234664

Illus. Part

No. No. DESCRIPTION

1 Door, Freezer

13092210SQ

Stainless

2 Handle, Door

W10119644

Stainless

3 67006113 Mount, Handle

4 Gasket, Door

W10164037

Black

5 67006901 Screw

6 Plug, Vent (2)

67004838 Black
