1
AB15132C
21 IN., 80 V LITHIUM-ION CORDLESS MOWER
ITEM #0632477
MODEL #KM2180B-06
Français p. 23
Español p. 45
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST,
Monday - Friday.
ATTACH YOUR RECEIPT HERE
Serial Number Purchase Date
KOBALT® and the K Design® are registered
trademarks of LF, LLC. All Rights Reserved.
kobalttools.com
2
TABLE OF CONTENTS
PRODUCT SPECIFICATIONS
Package Contents.................................................................................................................
Hardware Contents................................................................................................................
Safety Information.................................................................................................................
Preparation ...........................................................................................................................
Assembly Instructions ..........................................................................................................
Operating Instructions ..........................................................................................................
Care and Maintenance .........................................................................................................
Troubleshooting.....................................................................................................................
Warranty................................................................................................................................
Replacement Parts List ........................................................................................................
2
3
4
7
12
13
16
18
20
21
22
SPECIFICATIONS
Battery type 80 V Lithium-ion
Charge time 30 minutes, for 80 V 144 Wh battery
No-load speed 2,800 RPM
Height adjustments 1 9/16 in. (min) 3 3/4 in. (max)
Functions 3-in-1: Mulch, side discharge or rear bag
Unit weight (without battery) 58 lbs.
kobalttools.com
3
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Lawn mower 1
B Mulching plug 1
C Side discharge chute 1
D Grass catcher bag 1
E Charger 1
F Battery 80 V 2ah 2
C
B
E
F
D
A
kobalttools.com
4
HARDWARE CONTENTS (not shown actual size)
Handle knob
Qty. 2
Handle bolt
Qty. 2
BBAA
kobalttools.com
5
SYMBOLS DESIGNATION / EXPLANATION
V Volts
A Amperes
Hz Hertz
W/Hrs. Watts/Hours
Precautions that involve your safety.
To reduce the risk of injury, user must read and understand user’s
manual before using this product.
Always wear eye protection with side shields marked to comply
with ANSI Z87.1.
Do not expose machine to rain or wet conditions.
Pay attention that bystanders are not injured through foreign
objects thrown from the mower.
Keep all bystanders (especially children and pets) at least 100 ft.
away from the work area.
Keep hands and feet away from blade and cutting area.
Do not operate on inclines greater than 15°. Mow across the face
of slopes, never up and down.
Beware of electric shock hazard.
Wait for all components of machine to have completely stopped
before touching them.
The charger is intended for indoor use only.
SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn their meaning.
Proper interpretation of these symbols will allow you to operate the product better and safer.
kobalttools.com
6
SYMBOLS
SYMBOL SIGNAL MEANING
DANGER Indicates an imminently hazardous situation, which, if not avoided, will
result in death or serious injury.
WARNING Indicates a potentially hazardous situation, which, if not avoided, could
result in death or serious injury.
CAUTION Indicates a potentially hazardous situation, which, if not avoided, may result
in minor or moderate injury.
CAUTION (Without Safety Alert Symbol) Indicates a situation that may result in
property damage.
The following signal words and meanings are intended to explain the levels of risk associated with
this product.
Save these Instructions
Waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist. Check with your local authority or retailer for recycling advice.
The battery contains material which is hazardous to you and the environment. It must be
removed and disposed of separately at a facility that accepts lithium-ion batteries.
ENVIRONMENTAL PROTECTION
kobalttools.com
7
SAFETY INFORMATION
WARNING
DANGER
This symbol indicates important safety instructions. If these instructions are not followed, it could
endanger the personal safety and/or property of the operator and others. Read and understand all
instructions in this manual before attempting to operate the mower. Failure to comply with these
instructions may result in personal injury.
Basic safety precautions should always be followed when using electric lawn mowers, in order to
Use of this mower should be restricted to individuals who have read and understood and will
follow the warnings and instructions that are printed in this manual and on the mower.
This mower was built to be operated according to the rules for safe operation that are contained in
this manual. As with any type of power equipment, carelessness or error on the part of the operator
can result in serious injury. This mower is capable of amputating body parts and throwing objects.
Failure to observe the following safety rules could result in serious injury or death.
General safety rules
Read all instructions carefully
kobalttools.com
8
• To avoid serious personal injury, do not attempt to use this product until you have read this
owner’s manual thoroughly and understand it completely. If you do not understand the warnings and
instructions in this Owner’s Manual, do not use this product. Call 1-888-356-2258 for assistance.
The operation of any power tool can result in foreign objects being thrown into your eyes,
which can result in severe eye damage. Before beginning power tool operation, always wear
safety goggles or safety glasses with side shields and, when needed, a full face shield. We
recommend a wide vision safety mask for use over eyeglasses or standard safety glasses
with side shields. Always use eye protection which is marked to comply with ANSI Z87.1.
SAFETY INFORMATION
WARNING
WARNING (Proposition 65)
Some dust created by power sanding, sawing, grinding, drilling and other construction activities
contains chemicals known to the state of California to cause cancer, birth defects or other
reproductive harm. Some examples of these chemicals are:
• Lead from lead-based paints,
• Crystalline silica from bricks and cement and other masonry products, and
• Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work. To reduce
your exposure to these chemicals: work in a well ventilated area, and work with approved safety
• Become familiar with all controls and their proper operation. Know how to stop the mower and how
to disengage the power in an emergency.
• In order to avoid contact with the blade or injury caused by a thrown object, stay in the operating
zone behind the handles and keep children and bystanders at least 50 ft. (15 m) away from the
mower while it is in operation. Stop the motor immediately if someone enters the mowing area.
• Thoroughly inspect the area where the mower is to be used. Remove all stones, sticks, wires,
bones, toys, and other objects that could be tripped over or thrown by the blade. Thrown objects can
cause serious personal injury.
• Plan your mowing pattern in such a way as to avoid discharging material toward roads, sidewalks,
bystanders, etc. Do not discharge material against a wall or obstruction. Doing so may cause the
discharged material to ricochet back toward the operator.
• Always wear proper eye protection that complies with ANSI Z87.1 in order to protect your eyes,
while operating or performing any adjustment or repair. Thrown objects that ricochet can cause
serious eye injury.
• Always wear a face mask or a dust mask when operating the mower in a dusty environment.
• Dress properly. Do not wear loose clothing or jewelry that can get caught in moving parts. The
wearing of protective gloves and safety footwear is recommended.
• Many injuries occur as a result of the mower being pulled over the operator’s foot during a fall
caused by slipping or tripping. Do not operate this mower in bare feet or while wearing sandals or
lightweight (e.g., canvas) shoes. Do not hold on to the mower if you are falling. Release the handle
immediately.
SAFETY INFORMATION
Carefully read all instructions on the mower and in the manual before attempting to assemble and
operate the mower. Keep this manual in a safe place for future reference and consult it regularly.
kobalttools.com
9
• Never pull the mower back toward you while you are walking. If you must back the mower away from
steps:
• Step back from the mower in order to fully extend your arms.
• Be sure that you are well balanced.
• Pull the mower back slowly.
• Do not use the mower for any job except that for which it is intended. Do not force the mower.
• Stay Alert: Do not operate the mower when you are tired. Pay attention to what you are doing. Use
common sense.
• Do not put hands or feet near rotating parts or under the cutting deck. Contact with the blade can
amputate hands and feet.
• Do not attempt to adjust the wheels or the cutting height while the motor is running.
• Avoid dangerous environments. Do not operate the mower in the rain or in wet or damp grass.
!"
• Stop the blade when crossing gravel driveways, walkways, or roads.
• If the mower starts to vibrate excessively, stop the motor and remove the battery. Check for the
cause immediately. Vibration is generally a warning of trouble.
• Stop the motor and wait until the blade comes to a complete stop before removing the grass catcher
or unclogging the chute. The cutting blade will continue to rotate for a few seconds after the motor
is shut off. Do not place any part of your body in the blade area until you are sure that the blade has
stopped rotating.
• Never operate mower without a proper trail shield, chute cover, grass catcher, switch control, or
other safety device in place and in working order. Do not operate the mower with damaged safety
devices. Doing so can result in injury.
• Store idle lawn mower indoors. When not in use, remove the battery and then store the lawn mower
in an indoor, dry location that can be locked-up. Keep mower out of the reach of children.
• Maintain lawn mower. Keep blade edges sharp for best and safest performance.
• If lawn mower strikes a foreign objects follow these steps:
• Stop lawn mower, release the switch.
• Remove the battery.
• Inspect for damage.
• Repair any damage before restarting and operating the lawn mower.
• Remove battery before servicing, cleaning or removing material from lawn mower.
Child safety
Tragic accidents can occur if the operator is not aware of the presence of children.
• Keep children out of the mowing area and under the watchful care of a responsible adult.
• Do not allow children under the age of 14 to operate this mower. Children who are 14 years of age
and older must read and understand the operating instructions and safety rules in this manual, and
must be trained and supervised by a parent.
• Stay alert and turn the mower off if a child or any other person enters the mowing area.
• Look behind and down for small children before and while moving backwards.
• Use extreme care when approaching blind corners, doorways, shrubs, trees, or other objects that
may obscure your view of a child who may run into the path of the mower.
SAFETY INFORMATION
kobalttools.com
10
SAFETY INFORMATION
• Battery tools do not have to be plugged into an electrical outlet; therefore, they are always in
operating condition. Be aware of possible hazards when not using your battery tool or when
$
personal injury.
%&
and possibly injury.
• Do not crush, drop or damage battery pack. Do not use a battery pack or charger that has been
dropped or received a sharp blow. A damaged battery is subject to explosion. Properly dispose of a
dropped or damaged battery immediately.
• Batteries can explode in the presence of a source of ignition, such as a pilot light. To reduce the
"'
&*&
charge battery in a damp or wet location. Following this rule will reduce the risk of electric shock.
• For best results, your battery should be charged in a location where the temperature is more than
45°F but less than 104°F. To reduce the risk of serious personal injury, do not store outside or in
vehicles.
• Under extreme usage or temperature conditions, battery leakage may occur. If liquid comes in
*
them with clean water for at least 10 minutes, then seek immediate medical attention. Following this
rule will reduce the risk of serious personal injury.
• When battery pack is not in use, keep it away from other metal objects like: paper clips, coins, keys,
nails, screws, or other small metal objects that can make a connection from one terminal to another.
+
• Always remove battery from your tool when you are assembling parts, making adjustments,
cleaning, or when not in use. Removing the battery pack will prevent accidental starting that could
cause serious personal injury.
• Always remove battery before storing the device. When battery becomes fully charged, unplug the
charger from the power supply and remove the battery pack from the charger.
• Keep battery pack dry, clean, and free from oil and grease. Always use a clean cloth when cleaning.
<=
Battery and Charger
Battery safety rules
Use only 80 V Kobalt approved replacement batteries, other batteries may cause injury or damage to
the mower.
CAUTION
• Charge the mower battery in a dry area that is protected from the weather. Do not expose the
charger to rain. Do not charge the battery in a wet location. Operate the battery charger in
temperatures between 45° and 104°F. In order to reduce the risk of electric shock, use only the
charger that is provided by the manufacturer to charge the battery.
Charger safety rules
WARNING
When transporting or servicing unit, always remove the battery.
Indice
Altri manuali Kobalt Taglia erba
Kobalt
Kobalt KM-1640 Manuale utente
Kobalt
Kobalt KSPM 1040B-03 Manuale utente
Kobalt
Kobalt 0708633 Manuale utente
Kobalt
Kobalt KLMS 2524A-03 Manuale utente
Kobalt
Kobalt KM-1640 Manuale utente
Kobalt
Kobalt KM1940-06 Manuale utente
Kobalt
Kobalt KMP 2040-06 Manuale utente
Kobalt
Kobalt KMP 5040-06 Manuale utente
Kobalt
Kobalt KLMS 1024B-03 Manuale utente
Kobalt
Kobalt KMP 4240D-06 Manuale utente
Manuali Taglia erba popolari di altre marche
TALEN TOOLS
TALEN TOOLS AVR HGM30 Manuale utente
DEWEZE
DEWEZE ATM-725 Manuale operativo
Weed Eater
Weed Eater 180083 Manuale utente
Husqvarna
Husqvarna Poulan Pro PP185A42 Manuale utente
Better Outdoor Products
Better Outdoor Products Quick Series Manuale utente
Cub Cadet
Cub Cadet 23HP Z-Force 60 Manuale operativo
