KODA LM030164 Manuale utente
PACKAGE CONTAINS:
3 x LED Power Failure Night Light
2 3 4
LED POWER FAILURE NIGHT LIGHT (3-pack)
ITM. / ART. 2323014
Model / Model / Model: LM030164
• Disconnect the product from the power supply before servicing, when cleaning, and similar actions.
• Do not insert any foreign objects into this product.
• Store the product indoors when not in use.
• Do not clean this product with a water spray or the like. Always refer to the cleaning instruction prior to cleaning.
• For indoor and dry location use only.
• For input voltage, input power, input current and applicable light source, please refer to the label.
• Make sure that the light is completely plugged into the socket.
• Do not expose this product to rain or moisture. Do not place object filled with liquids or or near this unit.
• Do not expose this product to high temperatures, keep away from open flame.
• Do not place objects filled with chemicals on or near this unit. Do not place unit in area which is high in dust or dirt.
• Inspect the product before using for any visual damage or deflects. Do not use if the product has been damage.
• Do not modify or change the materials and parts by yourself.
• Use the product with care and avoid dropping or any sudden impacts which may result in undesirable operation.
• Avoid injury due to fall off, install securly.
• This is not a toy and is not intended for use by children.
• For use by adults or with adult supervision.
• To prevent electric shock, match the wide blade of the plug to the wide slot of the wall outlet, then fully insert the
plug into the outlet.
• Do not use with extension cords.
CAUTION: Risk of Electric Shock and Fire Hazard. OPERATION INSTRUCTIONS :
1. Flashlight 2. Nightlight 3. On/Off 4. PIR Sensor
5. Motion Sensor Switch 6. Folded Plug
1. Handheld Flashlight (unplug)
1x 2x
OFF
ON
OFF
ON
Nightlight
Press the On/Off button once to turn on the nightlight.
Flashlight
Press the operation button twice to turn on the flashlight. Press the operation button
once more to turn off the light.
NOTE: Each time you remove the light from the wall outlet, the nightlight will
automatically illuminate to be used as a handheld light.
OFF
ON
1
3
2
4
5
OFF
ON
6
1
2
3
4
5
6
5
2. Automated Lighting (plug to socket)
ON
Motion Sensor On
No Motion Detected Motion Detected
ON
LOW HIGH
Daylight
Off
Dusk to Dawn
Turn the Motion Sensor switch to “ON’. The nightlight will remain on at low brightness while the surrounding is
dark. When motion is detected, the nightlight will change to full brightness.
The nightlight will return to low brightness when no motion is detected around 30 seconds.The light will turn off
automatically when the sensor detects light from the surrounding area.
Motion Sensor Off
OFF Dusk to Dawn Daylight
OFF
LOW Off
The nightlight will automatically turn on when the sensor no longer detects sufficient light. The light will then
automatically shut off in daylight.
3. Power Outage Activation
Power On Power Out
LOW HIGH
Should a power outage occur while the light is docked on the wall outlet, the nightlight will automatically activate
in High Lumen for safe visibility, regardless of whether or not dimmer mode is activated and day or night.
MAINTENANCE:
• Regular and consistent use of the device helps in preparing a long battery lifespan.
• Fully charge the battery then unplug and store the light when not in use for an extended period of time
CLEANING INSTRUCTIONS:
When cleaning, make sure you have unplugged the light and allow it to cool to room temperature. Do not open the
retaining clips when cleaning. The light can be cleaned with a feather duster or a soft damp cloth.
You should only plug in the light after it has been completely dried.
@KodaBuiltOfficial
IMPORTANT INFORMATION. PLEASE READ CAREFULLY AND RETAIN FOR FUTURE REFERENCE
1-866-294-9244, Monday to Friday, 8am to 5pm Pacific Time
2975 Red Hill Ave., Suite 100, Costa Mesa, CA 92626, USA
For assistance with assembly, installation, parts or customer service, please contact us:
info@kodabuilt.com
IMPORTANT SAFETY INSTRUCTIONS
DANGER
- To reduce the risk of electric shock: Always unplug this product from the electrical outlet before cleaning.
WARNING: To reduce the risk of fire, electric shock, or injury to persons:
WARNING – When using the flashlight feature, additional precautions should be followed, including the following:
• To reduce the risk of injury and injuries to others, use the product as intended, any other use of the product may
result in undesirable performance.
• Do not touch or hold the flashlight by the lens or the top of the flashlight. To reduce the risk of injury, only handle the
flashlight by the base.
• Only use the attachments recommended or sold by KODA.
• To prevent fire or shock hazard, do not expose this unit to rain or moisture. Do not place objects filled with liquids on
or near this unit.
• To reduce the risk of electrical shock, do not use near or in water.
• WARNING: To reduce the risk of injury, do not stare directly into the flashlight when it is on. Serious eye injury could occur.
• Do not operate any product with a damaged plug, or after the product malfunctions, or is dropped or damaged in any
manner. Return product to the nearest authorized service facility for examination, repair, or electrical or mechanical
adjustment.
• Keep out of reach of children.
PRODUCT SPECIFICATIONS:
1. Operating Voltage: 110 Vac, 60 Hz
2. Wattage: 0.49 W
3. Light Output: 30 lm (Flashlight), 30 lm (Nightlight)
4. Rechargeable Battery Capacity: 250 mAh
5 6 7
OFF
ON
OFF
ON
This product is ETL/cETL Listed
13.9 cm / 5.4 in / 5.4 po
4.2 cm / 1.7 in / 1.7 po
3.3 cm / 1.3 in / 1.3 po
Warranty:
This Koda product carries a 5-year warranty against defects in workmanship and materials
subject to the conditions and additional warranty information available at:
www.kodabuilt.com/warranty
DISCLAIMER OF WARRANTIES, INCLUDING WARRANTY OF MERCHANTABILITY AND WARRANTY
OF FITNESS FOR PARTICULAR PURPOSE: EXCEPT AS SPECIFICALLY SET FORTH HEREIN, NO
WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, IS MADE AS TO THE LED POWER
FAILURE NIGHT LIGHT. KODA AND/OR ITS AFFILIATES EXPRESSLY DISCLAIMS, WITHOUT
LIMITATION, ANY STATUTORY WARRANTIES AND ALL IMPLIED WARRANTIES, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
LED POWER FAILURE NIGHT LIGHT
Model: LM030164
Responsible Party:
Koda
Address: 2975 Red Hill Ave., Ste. 100, Costa Mesa, CA 92626, USA
Tel: 1-866-294-9244
FCC Compliance Statement:
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications or
change to this equipment. Such modifications or change could void the user’s authority to operate the
equipment.This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
