KODAK INDUSTREX M100 Film gives you outstanding sharp-
ness—in fact, we’ve set the standard in this industry. The
film’s excellent sensitivity and low speed make it the perfect
choice for critical inspections of a wide range of materials. You’ll
have confidence that you’ll find what you’re looking for—whether
it’s a pipe weld, an aerospace engine, or a sculpture that you’re
imaging.
The Basics
M100 Film is an ASTM E 1815 Class I film that oers very fine
grain with extremely high contrast and definition. And it’s versa-
tile—you can use it with direct x-rays or with lead foil screens.
Recommended Uses
KODAK INDUSTREX M100 Film is available in a wide range of
sizes and packaging formats, and it’s designed for applications
such as:
WHEN CLARITY IS CRITICAL.
Get the T-Grain Emulsion Advantages
KODAK INDUSTREX Films with T-GRAIN
Emulsion oer a brand new, state-of-the-art
technology that’s specifically designed for
industrial radiographic testing applications.
What does that mean for you?
Outstanding Image Quality
With a cool, clean image tone and low noise,
you get a sharp, clear image every time.
Convenient Processing Flexibility
The films work well in standard process
cycles—but they’re just as eective in longer
or shorter process cycles.
Superb Durability
The films are static resistant, more heat
resistant than conventional systems,
incredibly sturdy, and you’ll get fewer
artifacts from handling.
Industrex M100
Film
• Aircraft inspection
• Aero-engines
• Assemblies
• Electrical
components
• Castings
• Composites,
fibre-reinforced
• Forensics
• Munitions,
bomb disposal
• Nuclear
applications
• Paintings,
sculptures
• Pipelines
• Welded
fabrication
Processing Options
M100 Film can be processed manually or automatically in a range
of processing cycles.
KODAK INDUSTREX M100 Film
Exposure:
220 kV Direct X-rays with lead screens
Processing:
KODAK INDUSTREX Processor
KODAK INDUSTREX Chemicals
Densitometry:
Diuse Visual
Notice: Observe precautionary information on product labels and Material Safety Data Sheets. Develop with rack
and tank, using properly replenished solutions.
1Contrast calculated between net densities of 1.5 and 3.5.
For More Information
To learn more about KODAK INDUSTREX M100 Film and other
Carestream Health NDT products and solutions, contact a
Carestream Health representative at 877-865-6325 ext 714 or
visit www.carestreamhealth.com/go/ndt.
KODAK INDUSTREX
Processors/Cycles
M43IC—8 min 79°F (26°C)
M43IC—5 min 86°F (30°C)
Base + Fog
0.19
0.19
Contrast1
5.4
5.25
Developer
KODAK INDUSTREX
Single Part Developer
Replenisher
Temperature
68˚F (20˚C)
72˚F (22˚C)
75˚F (24˚C)
79˚F (26˚C)
Agitation
Intermittent
(5 seconds,
every 30 seconds)
Recommended
Time (Mintes)
5
4
3
2
Carestream Health, Inc. Rochester, N.Y. 14608
© Carestream Health, Inc. 2007. Kodak and the
Kodak trade dress are trademarks of Kodak used
under license.
CAT 137 5617
Exposure:
220 kV Direct X-rays with lead screens
Processing:
Manual; KODAK INDUSTREX Single Part
Developer Replenisher
Densitometry:
Diuse Visual
Automatic Processing
See Carestream Health publication TI-2621, Processing
KODAK INDUSTREX Films, for additional information on
automatic processing.
Manual Processing
See Carestream Health publication TI-2643, Guide to Manual Pro-
cessing of KODAK INDUSTREX Films, for additional information on
manual processing.
Develop with rack and tank, using properly replenished solutions.
Film Characteristics (Sensitometric)
ISO/EN exposure conditions: 200/220 kV, lead screens; KODAK INDUSTREX Single Part Developer
Replenisher and KODAK INDUSTREX LO Fixer and Replenisher.
Exclusive manufacturer of Kodak INDUSTREX Products
