Kodak KE60 - 35 Mm Camera Manuale utente
KodakKE60
ENGLISH/ESPAÑOL/FRANÇAIS
35 mm Camera
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollow-ingtwo
conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesiredoperation.
NOTE: Your model camera has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits provide reasonable protec-
tionagainstinterferenceinresidentialuse.Thecameragenerates,usesandcanradiateradio
frequencyenergy and, if not used in accordance with the instructions, may cause interference
toradio communications. There is no guarantee that interference will not occur. If this camera
does cause interference to radio or television reception, which can be determined by turning
the camera off and on, you may reduce the interference by the following:
— Reorient or relocate the receiving antenna.
— Increase the separation between the camera and the receiver.
— Consult the dealer or an experienced radio/television technician for help.
Changes or modifications not approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
This Class B digital apparatus meets all requirements of the Canadian
Interference-CausingEquipmentRegulations.
CameraIdentification
1
2
345
6
7
8
9
10 11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28 29 30 31
32
33
34
35
36
AUTO AUTO
37
38
1
NEED HELP WITH YOUR CAMERA?
Visit our Web sites at http://www.kodak.com (for US) or
http://www.kodak.ca (for Canada) or call:
Kodak (USA only) from 9:00 a.m. to 7:00 p.m. (Eastern time) Monday
through Friday at 1-800-242-2424.
Kodak (Canada only) from 8:00 a.m. to 5:00 p.m. (Eastern time) Monday
through Friday at 1-800-465-6325, ext. 36100; for the Toronto area,
call 416-766-8233, ext. 36100.
When you call, please have your camera available.
For warranty purposes, please keep your sales receipt as proof
of the date of purchase.
ENGLISH
ENGLISH
Kodak KE60 35 mm Camera
2
CONTENTS
CAMERA IDENTIFICATION................ 3
ATTACHING THE STRAP ................. 4
LOADING THE BATTERY ................. 5
Low-battery indicator ................... 6
Auto power off ............................. 6
Battery tips .................................. 7
ATTACHING THE LCD LABEL.......... 8
Using the LCD backlight .............. 8
LOADING THE FILM ......................... 9
TAKING PICTURES ......................... 12
Using the focus lock ................... 13
Tips for better pictures ................ 14
TAKING FLASH PICTURES ............ 15
Flash-to-subject distance ............ 16
Using the red-eye reduction........ 17
FLASH MODES ................................ 18
Flash off....................................... 18
Fill flash ....................................... 19
Nightview with flash ..................... 19
Nightview without flash ................ 20
Selecting the flash modes ........... 20
USING THE SELF-TIMER ................ 22
SPECIAL OPTION MODES .............. 23
Portrait mode ............................... 23
Infinity-focus mode ...................... 25
UNLOADING THE FILM .................... 26
Automatic rewind ......................... 26
Manual rewind ............................. 26
CARING FOR YOUR CAMERA ........ 27
TROUBLESHOOTING ...................... 28
SPECIFICATIONS ............................ 30
3
CAMERAIDENTIFICATION
1SHUTTER BUTTON
2SELF-TIMER BULB/RED-EYE-
REDUCTION BULB
3AUTO-FOCUS WINDOWS
4LIGHT SENSOR
5FLASH
6VIEWFINDER LIGHT DIFFUSER
7VIEWFINDER
8LENS/LENS COVER
9STRAP POST
10 FILM-DOOR LATCH
11 VIEWFINDER EYEPIECE
12 FLASH-READY LIGHT
13 FILM-DOOR-LOCK INDICATOR
14 LCD PANEL
15 SELF-TIMER BUTTON
16 FOCUS-MODE BUTTON
17 EXPOSURE-MODE BUTTON
18 TRIPOD SOCKET
19 LCD BACKLIGHT BUTTON
20 FILM-REWIND BUTTON
21 ON/OFF BUTTON
22 BATTERY DOOR
23 FILM-GUIDE RAILS
24 DX/DXN CODE SENSORS
25 FILM CHAMBER
26 FILM DOOR
27 FILM WINDOW
Unfold cover flaps of manual
to view camera diagrams.
4
LCD Panel
28 FRAME COUNTER
29 NIGHTVIEW SYMBOL
30 FILL-FLASH SYMBOL
31 FLASH-OFF SYMBOL
32 PORTRAIT SYMBOL
33 BATTERY SYMBOL
34 SELF-TIMER SYMBOL
35 INFINITY-FOCUS SYMBOL
36 AUTO-FOCUS INDICATOR
37 AUTO-FLASH INDICATOR
38 FILM-MOTION INDICATOR
ATTACHING THE STRAP
1. Insert one end of the
strap under the
STRAP
POST
(9) and
pull it through.
2. Thread the longer
end of the strap
through the
shorter loop.
3. Pull the strap tight.
5
LOADING THE BATTERY
This camera uses one 3-volt lithium
KODAK K123LA (or equivalent)
Battery that supplies power for all
camera operations.
1. Open the
BATTERY
DOOR
(22).
•Before you remove the old
battery, turn off
the camera.
2. Insert the battery into the
chamber as shown.
3. Snap the
battery
door
closed.
