Kodak Picture Frame Manuale utente

KODAK Smart Picture Frame

User’s Guide (non-Networked

Version)

Congratulations! You now can view your favorite pictures in new and exciting

ways. You can:

mStore and view up to 36 pictures in your Smart Picture Frame.

mView pictures from your COMPACTFLASH Card.

mCreate custom slide shows, showcasing your favorite pictures.

NOTE: This product is network-capable. However, this configuration does

not support networking features at this time.

Visit Kodak on the World Wide Web at www.kodak.com

SmartPictureFrameNon-Networked.book Page 1 Tuesday, October 9, 2001 4:36 PM

Eastman Kodak Company

343 State Street

Rochester, N.Y. 14650

Kodak is a trademark of Eastman Kodak Company.

All other trademarks and service marks are property of their

respective owners.

P/N 7E3743

SmartPictureFrameNon-Networked.book Page 2 Tuesday, October 9, 2001 4:36 PM

Table of Contents

1 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Unpacking the Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Caring for Your Smart Picture Frame . . . . . . . . . . . . . . . . . . .2

2 Getting Connected. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Connecting the Power Cord. . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Learning the Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Turning the Frame On and Off . . . . . . . . . . . . . . . . . . . . . . . . .5

Setting the Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

3 Adding Pictures to Your Smart Picture Frame . . . . . . . 7

Inserting a COMPACTFLASH Card. . . . . . . . . . . . . . . . . . . . . .8

Copying Pictures From a COMPACTFLASH Card . . . . . . . . . .9

4 Enjoying Your Pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Viewing Pictures in the Frame Memory . . . . . . . . . . . . . . . . . .11

Viewing Pictures on a COMPACTFLASH Card . . . . . . . . . . . . 12

Still Picture Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Slide Show Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Rotating Pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Deleting Pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

SmartPictureFrameNon-Networked.book Page i Tuesday, October 9, 2001 4:36 PM

5 Customizing Your Smart Picture Frame . . . . . . . . . . . . .17

Setting On and Off Times. . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Keeping Your Picture Frame Secure . . . . . . . . . . . . . . . . . . . .18

6 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

7 Limited Warranty and Regulatory Information. . . . . . . 23

Electrical Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Limited Warranty and Limitation of Liability . . . . . . . . . . . 23

How to Obtain Replacement. . . . . . . . . . . . . . . . . . . . . . . . . 25

Federal Communications Commission Statement . . . . . . 25

Canadian ICES-003 Statement . . . . . . . . . . . . . . . . . . . . . 26

Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Disclaimers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

SmartPictureFrameNon-Networked.book Page ii Tuesday, October 9, 2001 4:36 PM

1Getting Started

Unpacking the Box

Documentation

Packet

AC Power Supply

KODAK Smart

Picture Frame

SmartPictureFrameNon-Networked.book Page 1 Tuesday, October 9, 2001 4:36 PM

Unpacking Your Frame

Always handle your KODAK Smart Picture Frame with care. Though it is

designed for durability, the liquid crystal display (LCD) is fragile and could be

damaged if it is dropped or struck.

Something Missing? Something Damaged?

Locate the serial number on the back of your frame, and call 1-800-235-6325

for Kodak Customer Support.

NOTE: Keep the original product packaging in case you need to return the

frame or move it to a new location.

Choosing a Location

Locate your frame where it's easy to see and is away from direct sunlight and

exposure to extreme temperatures.

Caring for Your Smart Picture Frame

mDo not allow liquids to come in contact with the frame.

mIf necessary, clean the screen with a damp cloth.

mIf your frame must be cleaned, treat it like other fine wood furniture;

gently apply wood cleaners, or use a damp cloth. Do not allow the cleaner

to contact the screen.

CAUTION: Avoid using alcohol-based window cleaners, as these can

damage the protective screen surface. Do not spray liquid

cleaners around the frame; these can damage the electronics.

SmartPictureFrameNon-Networked.book Page 2 Tuesday, October 9, 2001 4:36 PM

2Getting Connected

NOTE: This product is network-capable. However, this configuration does

not support these networking features at this time:

Connecting the Power Cord

mShare!

mChannels

mOrder Prints

mFrame Locking

mSet Update Times

mUpdate Now!

mAdvanced/Set Dialing Options

1 Plug the power cord into the

bottom of the frame.

NOTE: Even if the power is

disconnected from the Smart

Picture Frame, your stored

pictures are safe.

2Plug the power supply into the

wall socket.

Po w e r Co rd

Power Supply

and Cord

SmartPictureFrameNon-Networked.book Page 3 Tuesday, October 9, 2001 4:36 PM

Learning the Buttons

* Not supported in this configuration

On/Off Turns the frame on and off

Pictures/Channels Switches the display between pictures and channels*

Menu Toggles the menu on and off; cancels an operation

Right/Left Arrows Displays next or previous picture or menu option

OK Selects the current menu option, or a picture

Share! Sends pictures*

Pictures/Channels

COMPACTFLASH

Share!

Right Arrow

OK Left ArrowMenu

On/Off

Card Slot

SmartPictureFrameNon-Networked.book Page 4 Tuesday, October 9, 2001 4:36 PM

Turning the Frame On and Off

Setting the Time

The first time you turn on the frame, you are prompted to set the time:

1 Use the arrow buttons on the top of the frame to adjust the hour, then press

OK.

2Use the arrow buttons to set the minutes, then press OK.

3Use the arrow buttons to select AM or PM, then press OK.

4Accept or re-enter the settings. When finished, press OK.

If you want to adjust the time after the initial setting:

1 Press the Menu button.

2Select Advanced, then press OK.

3Select Set the Time, then press OK.

4Go to Step 1 of the previous procedure.

To turn the frame on, press the

On/Off button or any other

button.

To turn the frame off, press the

On/Off button.

On/Off Button

SmartPictureFrameNon-Networked.book Page 5 Tuesday, October 9, 2001 4:36 PM

SmartPictureFrameNon-Networked.book Page 6 Tuesday, October 9, 2001 4:36 PM
