Kodak S730 - EASYSHARE Digital Frame Manuale utente
KODAK EASYSHARE Digital Frame
User guide
S730
www.kodak.com
For help with your digital frame, www.kodak.com/go/digitalframesupport
Eastman Kodak Company
Rochester, New York 14650
© Kodak, 2009
All screen images are simulated.
KODAK, EASYSHARE, and PERFECT TOUCH are trademarks of Eastman Kodak
Company.
P/N 4H5194_en
Product features
www.kodak.com/go/digitalframesupport 1
ENGLISH
Back View
See the Extended user guide www.kodak.com/go/digitalframesupport
1 Memory card slot - SD/SDHC/MMC/XD/
MS/MS Pro Duo
3Speakers(2)
4 Rotating stand
2 DC-In 12V 1.5A 5 Wall mounting holes (3)
34
5
1
2
3
2www.kodak.com/go/digitalframesupport
Product features
ENGLISH
Front/Side Views
NOTE: When your hand is within
1 - 3 in. (2.5 - 7.6 cm)
of the borders, the lights turn on and
indicate where to touch. Tap a light on the right border to turn on the screen icons.
To use the Quick Touch Borders
, see page 4.
1LCDscreen 4Volumebutton
Quick Touch Borders: 5 Mode button
2 Side touch lights—tap only 6 Power button
3 Bottom touch lights—slide/tap arrows 7 USB connector (to USB drive)
8 USB connector (to computer)
9 Audio out (headphones or speakers)
10 Speakers (2)
2
1
3
7
6
8
9
5
4
10
www.kodak.com/go/digitalframesupport 3
1Getting started
Setting up the stand
Attaching the power cable
CAUTION:
Do not use this power cable with other devices, including digital
cameras.
Pull to adjust the frame angle for
best viewing.
Your frame displays pictures in landscape
orientation .
To change to portrait orientation , turn the
frame on its side.
Charge the battery (installed at the factory)
by leaving the power connected for at
least 3 hours. The frame does not need to
be turned on.
Your power cable may look different
from the one pictured. Use the plug
that accommodates your type of
power outlet.
4www.kodak.com/go/digitalframesupport
Getting started
Turning your frame on and off
Using the Quick Touch Borders
Power button - press and hold (for about 2
seconds), then release
Hover within 1 - 3 in. (2.5 - 7.6 cm) of
any border to turn on the lights.
Right border tap
lights
tap arrow lights or slide to move
forward or backward thru pictures
Menu
Play
Up
Down
OK or
move thru the
menus and
thumbnail rows
Bottom border
Right border icons
Tap the right border to turn on the icons.
(Select) or (Picture Finder)
Getting started
www.kodak.com/go/digitalframesupport 5
CAUTION:
Only use your finger on the borders. Borders do not react to sharp
or metal objects—and they may damage the border or screen.
Touch the lights—not the screen
Only the lights on the Borders are touch-sensitive.
Tapping on the right border
■Tap the light next to an icon to select it. Icons
change color when they’re selected.
■Tap the light next to the up/down arrows to move
up or down through menus or rows of thumbnails.
■Tap the light next to OK or to select the
highlighted item.
Tapping and sliding on the bottom border
■Tap the arrow lights to move the highlight one
picture at a time or to change selected values.
■Slide between the arrow lights to scroll through
pictures: like turning the pages of a book, slide left
to go forward, slide right to go back.
■For faster scrolling through large numbers of
thumbnail pictures, touch and hold an arrow light
(3 seconds).
DON’T
Tap the screen
DO
Tap the light
6www.kodak.com/go/digitalframesupport
Getting started
Setting your language
The language screen appears the first time you turn on your frame.
■Tap the light next to an up/down arrow to
highlight your language, then tap OK.
To change the language later:
■Tap (Menu) (Settings) Language
OK. Tap an up/down arrow to highlight your
language, then tap OK.
Your settings are saved and the Clock and Date screen
appears.
Setting the clock and date
1 Set the clock. Tap the down arrow to
highlight Clock, then slide or tap between the
left/right arrow lights to select the current time
(based on a 24-hour clock).
2 Set the date. Tap the down arrow to
highlight Year/Month/Day, then slide or tap
between the left/right arrow lights to select the
current date (three separate settings).
3Tap OK to save your settings and close the Menu
screen.
To close the screen without saving, highlight Exit,
then tap OK.
To change or set the clock, date, energy saver, and automatic timer later:
■Tap (Menu) (Settings) OK Time/On Off OK.
Press and hold to move quickly
through the time and date
settings.
Getting started
www.kodak.com/go/digitalframesupport 7
Inserting a memory card
Connecting a computer or USB device
MMC (MULTIMEDIA Card)
To insert a card, push it firmly into the slot.
To remove a card, pull it out of the slot.
XD
SD/SDHC (SECURE DIGITAL/SECURE
DIGITAL High Capacity)
MS Pro Duo (MEMORY STICK)
MS (MEMORY STICK)
Supported USB devices include a computer, flash
drive, card reader, hard drive*, etc.
USB devices are sold separately.
*External hard drives must be self-powered.
Connect to a computer
USB cable included
Connect a USB device
8www.kodak.com/go/digitalframesupport
Getting started
Enjoying your pictures immediately!
Installing the software
Use KODAK EASYSHARE Digital Display Software to manage your frame right from
your computer. Use the Sync feature to copy all your pictures from your computer to
your frame’s internal memory (see page 11).
1Insert the CD into your computer and follow the
on-screen instructions to install the software.
■Click Typical to install EASYSHARE Digital
Display Software and to upgrade a previous
version of EASYSHARE Software. Click Custom
to choose which applications to install.
■Update—if an update to Digital Display
Software is available on the Web, you receive a
notice during installation. Click Yes to install the
latest version and take advantage of new
features, including Sync.
2Double-click the Digital Display Software icon on your desktop to open the
software if it doesn’t open automatically.
When prompted, take a few minutes to electronically register your frame and software
for exclusive tips and offers. To register later, visit www.kodak.com/go/register.
To view your pictures and videos, insert a memory card or
other USB device. Your pictures play automatically.
CD packaged with
your frame.
Digital Display Software icon
EASYSHARE Software icon
