Kodak 1.8x Magnifying LED Manuale utente
User Manual
KODAK 1.8x Magnifying
LED Slide Viewer
TO SEE THIS GUIDE IN FRENCH, ITALIAN,
GERMAN, OR SPANISH, PLEASE VISIT
WWW.KODAKPHOTOPLUS.COM
OR USE THIS QR CODE:
Um diese Anleitung auf Französisch, Italienisch, Deutsch oder Spanisch zu
lesen, besuchen Sie bitte www.kodakphotoplus.com oder nutzen Sie diesen
QR-Code. | Per visualizzare questa guida in francese, italiano, tedesco o
spagnolo, si prega di visitare www.kodakphotoplus.com, oppure di usare
questo codice QR. | Para ver esta guía en francés, italiano, alemán o
español, por favor, visite www.kodakphotoplus.com o use este código QR. |
Pour consulter ce guide en anglais, en italien, en allemand ou en espagnol,
veuillez aller sur le site www.kodakphotoplus.com ou utiliser ce code QR.
EN
CONTENTS
1. INTRODUCTION
2. SPECIFICATIONS
3. PACKAGE CONTENTS
4. SAFETY PRECAUTIONS
5. PRODUCT OVERVIEW
6. INSTALLING BATTERIES
7. VIEWING A SLIDE
8. CARE & MAINTENANCE
9. CUSTOMER SERVICE
10. WARRANTY LINK
3
4
5
5-6
7
8
9
10
10
11
EN | 3
Thank you for purchasing the KODAK 1.8x Magnifying LED Slide Viewer. This
User Guide is intended to provide you with guidelines to ensure that operation
of this product is safe and does not pose risk to the user. Any use that does
not conform to the guidelines described in this User Guide may void the
limited warranty.
Please read all directions carefully before using the product and retain this
guide for reference. This product is intended for household use only. It is not
intended for commercial use.
This product is covered by a limited one-year warranty. Coverage is subject to
limits and exclusions. See warranty for details.
1. INTRODUCTION
4 | EN
• Product type: Slide viewer
• Dimensions: 2.4" x 6.1" x 0.9" (62 x 155 x 24 mm)
• Weight: 0.3 lbs. (132 g)
• Power source required: Yes (battery powered)
• Power source: 4 x 1.5 V AA batteries (not included)
• Light source: LED
• Magnification: 1.8x
• Compatible slides: 35mm slides
• Installation required: No
• Adult assembly required: No
• Additional tools required: No
• Country of origin: China
• Warranty included: Yes
• Warranty length: 1 year
2. SPECIFICATIONS
EN | 5
• KODAK 1.8x Magnifying LED Slide Viewer
• User guide
WARNING! Please read all safety precautions and instructions carefully
before using this product.
• Do not attempt to disassemble this device for any reason.
• Do not try to open the device’s casing or attempt to modify it in any way.
Doing so could create the risk of serious accident or injury and will void
the product’s limited warranty.
• Maintenance and repairs to this product should always be performed
exclusively by authorized service providers. Do not attempt to repair this
product on your own.
• Keep the unit away from all types of moisture, as this could damage the
internal components and create the risk of fire and electrical shock.
3. PACKAGE CONTENTS
4. SAFETY PRECAUTIONS
6 | EN
• Never operate the unit with wet hands, as you could damage the product
or cause serious injury to yourself.
• Never use the unit in the rain or snow.
• To avoid the risk of accidents, choking hazards, or damaging the unit,
keep it and all included accessories out of the reach of children
and/or animals.
• Batteries are not included. When inserting batteries, make sure that the
positive and negative polarities match with the markings in the
compartment.
• Do not mix old and new batteries together.
EN | 7
1. Lens cover
2. Power light
3. Power switch
4. Magnifying glass
5. LED backlight
6. Battery compartment
7. Neck lanyard
5. PRODUCT OVERVIEW
8 | EN
1. 2. 3.
1. Remove the battery door from the bottom of the slide viewer.
2. Insert four (4) AA batteries (not included) into the battery compartment.
3. Close the compartment with the battery door.
6. INSTALLING BATTERIES
EN | 9
7. VIEWING A SLIDE
1.
2.
3.
1. Fold out the lens cover to position the magnifying lens over the backlight.
2. Move the power switch to the ON position to turn on the backlight.
3. To view a slide, place it over the backlight and under the magnifying lens.
4. When you are finished using the unit, fold up the magnifying lens and
turn o the device.
4.
