CMP-PRESENT40
Wireless RF Presenter
I. Instruction of Smart Pointer
It consists of laser pointer, wireless mouse, and wireless keyboard. It is designed as a handy-tool for
presentation, teaching, meeting, speech, training that associated with computer applications.
Package Contents :
- Remote control
- U B receiver
- U B extension cable
Setup :
Plug the receiver to the U B port of PC. The system will automatically search for the suitable driver,
please follow the instruction when prompted.
C UTION :
keep the area in front of the receiver.
if the U B port is at the rear of PC, use the extension cable provided to reposition it.
II. Function :
) When the switch is put on “KEYBOARD”, it functions as a wireless keyboard as below :
Laser key: press to generate red laser light.
Page up Key : as the Page Up in ordinary keyboard.
Page down Key : as the Page Down in ordinary keyboard.
Start : press “∧”Key and generate start function of computer.
Blank screen : press “∨ “ Key to blank screen ( Press again to return to show status ).
Start slide show : press “< ” Key to start the slide show through shortcut after you open one
file under PowerPoint.
Escape : press “> “ Key to make escape function on computer.
B).When you select the switch on “MOU E”, it functions as a wireless mouse as below:
Laser Key : press to generate red laser light.
Mouse Left Click: press “LEFT” key.
Mouse Right Click: press “RIGHT” key.
Mouse Pointer up : press “∧”Key.
Mouse Pointer down : press “∨“ Key.
Mouse Pointer left : press “<” Key.
Mouse Pointer right : press “>“ Key.
( Tip: hold down the arrow keys to faster the cursor move speed .)
III. Technical Parameters:
Transmitter
Class ⅡClass Ⅲ
Control distance ＞20m ＞20m
Laser distance ＞200m ＞400m
Battery AAA x 2pcs AAA x 2pcs
Working voltage 2.4-3.5V 2.4-3.5V
leep current 1uA 1uA
Wavelength 650nm 650nm
Max output ＜1mW ＜5mW
Class Class ⅡClass Ⅲ
Dimension 11.9x3.1x1.7cm 11.9x3.1x1.7cm
Weight 58g 58g
Receiver
ystem Windows 98, E, Me, 2000, XP, Mac O , Linux
Compatible plug U B1.1, U B2.0
Working voltage 4.5-5.5V
Dimension 7.35x2.7x1.7cm
Weight 16g
