223279 15
Parboiling boost
Switch on the cooking zone by means of corresponding
cooking zone button 햻. Press the Minus key 햽and select
cooking level 9. Then switch on the parboiling boost by means
of the Plus key 햶. During the parboiling stage, the cooking
level display 햲switches continuously between the “A” sign
(parboiling boost) and the cooking level which has been set.
Now you can select the subsequent cooking level 1 - 8. If you
quit cooking level 9 without selecting a subsequent cooking
level from 1-8, then the parboil boost is shut off automatically
after 10 seconds. The parboiling boost time depends on the
subsequent cooking level which has been selected. Details are
given in the accompanying time chart.
If the Plus key 햶is selected after the required subsequent
cooking level has been selected, the parboiling boost time is
adjusted upwards in accordance with the time chart. If the
Minus key 햽is pressed after the required subsequent cooking
level has been deselected, the parboiling boost is stopped
beforehand.
Two-circuit / three-circuit connection
Two-circuit / three-circuit connection of the respective cooking zone can only be effected after the corresponding
cooking zone has been activated and switched on.
Select the desired cooking level 1-9. Switch on the second heating element by means of the Multi-circuit key 햵.
The control lamp 햴of the selected cooking zone lights up. Connect the third heating circuit by pressing the Multi-
circuit key 햵once again. The second control lamp 햴lights up. The corresponding cooking zone must also be
activated in order to switch off the two-circuit / three-circuit connection. The outer heating circuits are switched off
by pressing the Multi-circuit key 햵once again. The control lamps 햴are then no longer lit.
Warming zone
The warming zone is suitable for foods that have finished cooking and
which should be covered to keep them warm.
Operation of the warming zone is carried out with the Touch-Control
switch. Two keys have to be pressed in successive in order to switch on
the warming zone. First the key button has to be pressed (LED-1 lights
up).
Now the I-key must be pressed within 6 seconds (LED-1 goes out/ LED-2
is lit), and the warming zone is switched on.
By pressing the 0-key the warming zone is then switched off again (LED-2
goes out).
Pot Recognition (PR)
If your range is equipped with Pot Recognition the PR will check whether a metal pot is on the cooking zone after
a cooking level has been selected. If no pot is recognized, a uwill appear in the display and the heating element
will remain inactive. If a pot is now placed on the cooking zone within 10 minutes, the heating element will turn
itself on and the selected cooking level will appear in the display. Cooking zones with two-circuit heating or frying
zone will automatically be re-powered, i.e., the PR also recognizes the size of the pot. If no pot is placed on the
cooking zone, the range will turn off after 10 minutes for safety reasons.
The PR recognizes only metal pots. To be able to cook with non-metallic cooking ware, as well, the PR can be
turned off for each cooking zone. To do this, the required cooking zone 햻must be activated 햳and a cooking
level selected. Now the Multi-circuit key 햵and then the corresponding cooking zone key 햻should be pressed.
Cooking can now be done without PR. The two-circuit heating or frying zone can now be re-powered by means of
the Multi-circuit key 햵.
To reactivate PR, turn off the cooking zone. When the cooking zone is turned on again, PR will again be active.
