Kyocera Data Security Kit (B) For Copier Manuale utente

1-1

General User Information

Introduction

This operation guide contains information on the proper use of the Data

Security Kit (B) (hereinafter, Security Kit), as well as cautionary notes relating

to its use. Be sure to carefully read this operation guide before using the

Security Kit.

About The Security Kit

The copier temporarily stores the original document, which is read as

electronic data, onto the copier’s hard disk. Printing is performed using this

data. Even after the printing is completed, the data remains stored on the hard

disk until it is overwritten by other data. Therefore, there is a possibility that

confidential information will be leaked if special tools are used to recover this

remaining data.

The Security Kit overwrites old data - data that is not required - and data

storage area where the data has been deleted to ensure that data cannot be

recovered. Overwriting is performed automatically, without user intervention.

Unsecured Data

The Security Kit secures data that is not required after it is printed, and data

that has been deleted. This means that the responsibility for maintaining data

before it is printed or data that is stored before it is deleted lies with the user.

1-2

General User Information

The data derived from the following functions must be administered by the

user.

• Document Management (Copy Function)

• Quick Copy (Printer Function)

• Proof and Hold (Printer Function)

• Private Print (Printer Function)

• Stored Job (Printer Function)

• Virtual MailBox (VMB) (Printer Function)

• Temporary code Job (Printer Function)

• Permanent code Job (Printer Function)

1-3

General User Information

Display during overwrite

Important!

To avoid damaging the hard disk, do not turn the copier power off during

overwrite (while the hard disk icon is alternating between the two icons).

Note • If the copier power is turned off while overwriting is still in progress, any

data that has not yet been overwritten will remain on the hard disk. In this

case, overwriting should be re-started from the beginning when the copier

is turned on again.

• In rare cases after the copier power is turned off during overwrite, the hard

disk icon may not change to . This means that overwrite may not be

possible because data was corrupted during data overwriting. Though the

copier will be able to overwrite data that is not required after it is printed,

contact your administrator, who is responsible for operating the copier and

for copier security, in order to restore overwriting to normal.

Icon display Details

The hard disk contains old data.

Alternating Old data is being overwritten.

Old data has been overwritten.

Ready to copy.

11x8½"

Paper Size Set

4 in 1

Sheet

Margin

Left

ProgramFunctionUser choice

Basic

11x8½"

Plain

11x8½"

Recycled

11x17"

Plain

8½x11"

Plain 11x8½"

Plain

MP tray

Plain

APS Auto %

Reduce

％100

Exposure

Auto

Staple

Left Top

Staple Off

％100

/Enlarge Mode

Exposure Erase

/Punch

Hard disk icon

1-4

General User Information

Data to be overwritten

Data to be overwritten are as follows.

Note The Security Kit immediately overwrites the original document data stored onto

the hard disk when copying, scanning or printing is cancelled while processing.

Copy Function

The original document data of a copy which output is completed

The original document data stored through a document management

function and deleted by the user

The original document data stored in Synergy Print Box that is deleted

because the expiration date was reached

Printer Function (when optional hard disk is installed)

Post-output print data

Print data in the private print mode and virtual mailbox function when

output is completed

Quick Copy, proof and hold, and Private Print data (Deleted when

power is turned off and then back on again.)

Data deleted by the user using the Quick Copy, proof and hold, Private

Print, Stored Job, virtual mailbox, Temporary code Job, or Permanent

code Job function

Data deleted when maximum number of documents is exceeded by

Quick Copy, or proof and hold print data

Data deleted when storage capacity is exceeded by Temporary code

Job print data

Scanner Function

Scanned original document data

1-5

Administrator Information

Table of Contents

Introduction ....................................................................................1-5

Security Kit Functions ...................................................................1-8

Security Kit Installation Procedures ..........................................1-13

Hard Disk Format .........................................................................1-15

Error Messages ............................................................................1-16

Introduction

This operation guide contains information on the proper use of the Data

Security Kit (B) (hereinafter, Security Kit), as well as cautionary notes relating

to its use. Be sure to carefully read this operation guide before using the

Security Kit. The individual who will be responsible for operating the copier and

for copier security (hereinafter, administrator) should read this guide. The

administrator should store this guide in a secure place.

Attachments

The Security Kit comes with the following items:

• Security key (service representative will attach to copier.)

• Operation guide (this manual)

• Installation guide (for use by service representative)

About The Security Kit

The copier temporarily stores the original document, which is read as

electronic data, onto the copier’s hard disk. Printing is performed using this

data. Even after the printing is completed, the data remains stored on the hard

disk until it is overwritten by other data. Therefore, there is a possibility that

confidential information will be leaked if special tools are used to recover this

remaining data.

The Security Kit overwrites old data - data that is not required - and data

storage area where the data has been deleted to ensure that data cannot be

recovered. Overwriting is performed automatically, without user intervention.

1-6

Administrator Information

The Security Kit secures data on the copier’s internal hard disk, but does not

secure any other type of data (data sent to the computer, etc.) Note that data

security is not guaranteed even if only one of the conditions required for

data security described below is not met.

Conditions Required for Data Security

The followings are required for fulfilling the validity of data security using the

Security Kit.

Dependable Administrator

A dependable administrator is required in the department to take responsibility

on security on the copiers using this Security Kit.

Safe Physical Location of Installation

The copier should be installed in a location which the accessibilities are limited.

This avoids unauthorized personnel to use the copiers.

Dependable Service Representative

All maintenance activities must be performed by the service representative,

with the administrator in attendance.

Unsecured Data

The Security Kit secures data that is not required after it is printed, and data

that has been deleted. This means that the responsibility for maintaining data

before it is printed or data that is stored before it is deleted lies with the user.

The data derived from the following functions must be administered by the

user.

• Document Management (Copy Function)

• Quick Copy (Printer Function)

• Proof and Hold (Printer Function)

• Private Print (Printer Function)

• Stored Job (Printer Function)

• Virtual MailBox (VMB) (Printer Function)

• Temporary code Job (Printer Function)

• Permanent code Job (Printer Function)

1-7

Administrator Information

About Security Mode

Security mode refers to the machine status in which the Security Kit has been

installed on the copier and is functioning properly. When the copier is in the

security mode, a hard disk icon will be displayed on the right upper corner of

the touch panel.

(The hard disk icon is displayed on the screens of the copy, printer, and

scanner functions.)

Important!

If a hard disk icon is not displayed on the screen of the copier, printer, and

scanner functions, it could mean that the machine is not in the security mode.

Contact your service representative.

Note You can determine the operational status of the overwrite function by

monitoring changes to the image of the hard disk icon. See page 1-10 Display

during overwrite for further details.

Ready to copy.

11x8½"

Paper Size Set

4 in 1

Sheet

Margin

Left

ProgramFunctionUser choice

Basic

11x8½"

Plain

11x8½"

Recycled

11x17"

Plain

8½x11"

Plain 11x8½"

Plain

MP tray

Plain

APS Auto %

Reduce

％100

Exposure

Auto

Staple

Left Top

Staple Off

％100

/Enlarge Mode

Exposure Erase

/Punch

Hard disk icon

1-8

Administrator Information

Security Kit Functions

Overwrite Function

Function details

Overwrites old document data when copying or printing is completed.

Overwriting method

3-time Overwrite or Once Overwrite (See page 1-14 Step 3: Hard Disk

Overwrite Setting for further details.)

Execution timing

Overwrites existing old document data after a job is completed.

Data to be overwritten

See page 1-11 Data to be overwritten for further details.

Overwrite-in-Progress Screen

The hard disk icon alternates between the two icons (See page 1-10

Display during overwrite for further details.)

Security Kit

Copy

Function

Scanner

Function

Printer

Function

Hard Disk

Sends to

computer

Output

1 Monitors the status of

operations, overwrites

old image data.

2 Formats the hard disk.

Temporarily

stores original

document data

Optional Hard Disk
