Kyocera ECOSYS MA6000ifx Manuale utente

2022.9 3VC0V5611001

Pull the Cassette 1 completely out

of the machine.

123

Adjust the paper length and width guide to the

paper size required.

Fan the paper, then tap

it on a level surface.

Load paper.

Gently push the Cassette 1 back in.

Step 3 Loading Paper

+ Set print side face-down.

+ No bent or folder edges in the paper.

Such paper may cause paper jams.

+ Set the quantity of the paper less than

the maximum paper indication on the

side or the cassette.

+ If the paper is loaded without adj

usting the paper length guide and the pa

per width guides, skewed paper feeding,

and a paper jam will occur.

Step 2 Install Waste toner box

Open the top cover. After Removing the packing material,

shake and install the toner container. Close the top cover.

567

(for inch

models)

(On some

models)

Open the Box. Remove the machine carefully from the box

grasping both sides.

Lift the main unit from the handles by cardboard handles.

Step 1 Setting up the Machine

Recommended Installation Space

*1: The value when an optional rear tray (PT-320) is installed to the ECOSYS MA6000ifx and

ECOSYS MA5500ifx.

100 mm

(3.94")

300 mm

(11.81")

400 mm

(15.75")

400 mm

(15.75")

500 mm (19.69")200 mm (7.87")

500 mm (19.69") *1

Installation Environment

Kyocera Recommends selecting the Location for the machine as follows:

1. Room Temperature range: 50 to 90.5°F

2. Humidity Level: 10 to 80%

3. Power:

Avoid the following locations when selecting a site for the machine.

Adverse environmental conditions may affect the image quality.

+ Avoid locations near a window or with exposure to direct sunlight.

+ Avoid locations with vibrations.

+ Avoid locations with rapid temperature fluctuations.

+ Avoid locations with direct exposure to hot or cold air.

+ Avoid poorly ventilated locations.

Setup GuideECOSYS MA6000ifx/ECOSYS MA5500ifx

ECOSYS MA4500ifx/ECOSYS MA4500ix

A dedicated 120VAC 60Hz 15A outlet

A dedicated 200-240VAC 50/60Hz 15A outlet

120 V Specification Model:

230 V Specification Model:

Step 7 Installing Software

Access the following URL and select your model and OS.

Download Center: https://kyocera.info/

For Windows

Download and run the Web Installer and follow the

on-screen instructions to install the driver and software.

For Mac

Download and run the driver and follow the on-screen

instructions to install.

Step 4 Powering on the Machine

Turn the power switch ON at the front of the machine.

Connect the power cord to the rear of the machine and the

other end to the power outlet.

Reset

Stop

Start

Reset

Stop

Start

Step 5 Default Settings of the Machine

Step 6 Printing a Status Page

Select default language > [Next >].

The setup screen appears.

Next >

When the following screen appears,

select [Finish].

The settings can be configured in a

wizard style screen.

Follow the instructions on the screen.

NOTE

To proceed to the next screen,

select [Next >].

To return to the previous screen, select

[<< Previous].

To advances to the next item without

setting the current item, select [Skip >>].

Language Next >

Machine setup

End

Welcome!

Set time zone, date, and time.

If you want to set them later,

press [Skip >>].

Go to Settings >

<< Previous Skip >>

Date/Time

Network

Others

Home Screen Setup

Machine setup

To complete the setup, press [Finish].

Quick Setup Wizard in the System Menu

lets you easily configure basic settings.

Use this menu first. And use the de-

vice's web COMMAND CENTER RX to

easily configure advanced settings such

as email and network.

See the operation guide for details.

Finish

<< Previous

Date/Time

Network

Others

Home Screen Setup

[System Menu/Counter] Key > [Notification/Report] >

"Print Report/List"[Print Report/List]

[Status Page] > [Print]

System Menu/

Counter
