La Crosse Technology WS-9160U-IT Manuale utente

WS-9160U-IT www.lacrossetechnology.com/support Page | 1

Indoor

Temp.

ºF/ºC

Hanging

hole

Battery

compartment

2 “AAA”

Alkaline

batteries.

Foldout

stand

Buttons

Model: WS-9160U-IT

Instruction Manual

DC: 081815

WIRELESS THERMOMETER

Outdoor

Temp.

ºF/ºC +

Channel

Indicator

Time

12/24hr

Battery

compartment

2 “AA”

batteries

TX29U-IT

Temperature

Sensor

WS-9160U-IT www.lacrossetechnology.com/support Page | 2

Get Started

Step 1: Insert 2 fresh AA, batteries into the TX29U-IT

sensor according to the polarity marked in the battery

compartment.

Step 2: Insert 2 fresh AAA, Alkaline batteries into the wireless

thermometer according to the polarity markings.

Step 3: After 5 minutes place sensor outside in a shaded location.

Set 12/24 Hour, Temperature Units, Time

1. Hold the SET button to enter time set mode.

2. Press the + button to adjust values.

3. Press the SET button to confirm adjustments and move to next

item.

Settings order:

1. 12/24 Hour Format

2. Hour

3. Minutes

Note: 12h = ºFahrenheit & 24h = ºCelsius

Press SET to exit, or wait 30 seconds without pressing buttons to

return to the normal time display.

Fahrenheit/Celsius

The temperature is displayed in Fahrenheit when in 12-hour time

format and in Celsius in 24-hour time format.

1. Hold the SET button to enter time set mode.

2. 12h or 24h will flash.

3. Press the + button to change the time format

(temperature display).

4. Press the SET button to confirm.

Note: 12h = ºFahrenheit & 24h = ºCelsius

WS-9160U-IT www.lacrossetechnology.com/support Page | 3

Low

Battery

Icons

View/Reset MIN/MAX Readings

1. Press the MIN/MAX button once to view the minimum

indoor and outdoor temperature.

2. Press the MIN/MAX button once more to view the maximum

indoor and outdoor temperature.

3. Hold the MIN/MAX button for 3 seconds to reset all MIN/MAX

temperatures.

Note: When using multiple sensors, press the CH button then the

MIN/MAX button to view the MIN/MAX reading on a different

channel

Outdoor Temperature Reception Icon/Channel Indicator

The outdoor temperature reception icon will flash every

second when searching for the sensor.

Once connected, reception icon will show for 3 seconds

once the outdoor temperature update is received.

The channel indicator will show below the outdoor

temperature.

Press the CH button to view sensors on other channels.

Note: Channel 1 will not show if only one sensor is

connected.

Setup with Multiple Sensors

1. Insert batteries into sensor 1

2. Insert batteries into wireless thermometer

3. When outdoor temperature appears, insert batteries into

sensor 2

4. When channel 2 appears insert batteries into sensor 3

5. Keep wireless thermometer and all sensors together for 15

minutes.

Low Battery Icon

When the TX icon is displayed replace

batteries in the outdoor sensor.

When the RX icon is displayed replace

batteries in the wireless thermometer .

Outdoor

Reception

Icon

Outdoor

Channel

Icon

WS-9160U-IT www.lacrossetechnology.com/support Page | 4

Position Outdoor Sensor

Mount the outdoor sensor on a north-facing wall or in any well

shaded area. Under an eave or deck rail is preferred.

The maximum transmitting range to the wireless thermometer

is over 330 feet (100 meters) in open air, not including walls.

Restart

If the outdoor temperature shows dashes, remove batteries from

the station & outdoor sensor. Press any button on the station 20

times. After 15 minutes, return to Step 1.

Specifications

Indoor:

Temperature Range:

14.2°F to 139.8 °F (-9.9°C to 59.9°C)

Outdoor:

Temperature Range:

-39.8°F to +139.8°F

(-39.9°C to 59.9°C)

Distance:

Over 330 ft. (100 meters)

RF 915MHz (open air)

Interval:

About every 4 seconds

Power:

Wireless thermometer

2-AAA, IEC, LR3 batteries

(not included)

TX29U-IT Sensor:

2-AA, IEC, LR6 batteries

(not included)

Battery Life:

Wireless thermometer

Over 12 months

TX29U-IT Sensor:

Over 12 months

Dimensions:

Wireless thermometer :

3.3” x 0.89” x 5.86”

(84 x 22.6 x 149mm)

TX29U-IT Sensor:

1.5” x 0.83” x 5.05”

(38.2 x 21.2 x 128.3mm)

WS-9160U-IT www.lacrossetechnology.com/support Page | 5

Care and Maintenance

Do not mix old and new batteries

Do not mix Alkaline, Standard, Lithium or Rechargeable

Batteries

Always purchase the correct size and grade of battery most

suitable for the intended use.

Replace all batteries of a set at the same time.

Clean the battery contacts and also those of the device prior

to battery installation.

Ensure the batteries are installed correctly with regard to

polarity (+and -).

Remove batteries from equipment with is not to be used for

an extended period of time.

Remove expired batteries promptly.

Warranty and Support Information

La Crosse Technology, Ltd. provides a 1-year limited time

warranty (from date of purchase) on this product relating to

manufacturing defects in materials & workmanship.

View full warranty details online at:

www.lacrossetechnology.com/warranty_info.pdf

For warranty work, technical support or other information

contact our friendly support staff:

La Crosse Technology, Ltd

2830 26th Street S.

La Crosse, WI 54601

Contact Support:

1-608-782-1610

Product Registration:

www.lacrossetechnology.com/support/register

Online Product Support:

www.lacrossetechnology.com/support

Protected under U.S. Patents:

5,978,738 | 6,076,044 | RE43903

WS-9160U-IT www.lacrossetechnology.com/support Page | 6

FCC Statement

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

This device must not be co-located or operating in conjunction with any other

antenna or transmitter.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that

may cause undesired operation.

Caution!

The manufacturer is not responsible for any radio or TV interference caused by

unauthorized modifications to this equipment. Such modifications could void the

user authority to operate the equipment.

or duplicated or processed using electronic, mechanical or chemical process

without the written permission of the publisher.

This booklet may contain errors or misprints. The information it contains is

regularly checked and corrections are included in subsequent editions. We

disclaim any responsibility for any technical error or printing error, or their

consequences.

All trademarks and patents are recognized.
