Larson Electronics EPL-SBDL-150RT-72 Manuale utente

EPL-SBDL-150RT-72

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

1of 2

This explosion prooflightis designed for illumination of industrial locations. It uses the latest in

solidstate lighting technology forlong life, low maintenance and high efficiency.

The unique design focuses the light where itis needed, giving improved efficiency over a

conventional HID luminaire.

An internal, universal input, power-factor-corrected switch-mode supplyallowsit to be used from

any nominal 100-277 Volts AC, 50/60Hz or 11-25 Volts AC/DC.

WARNING

To avoid the risk of fire, explosion or electric shock, this product should be installed, inspected

and maintained by a qualified electrician only, in accordance with all applicable electrical codes.

To avoid electric shock:

•Be certain electrical power is OFF before and during installation and maintenance.

•Luminaire must be connected to a wiring system with an equipment-grounding conductor.

To avoid explosion:

•Make sure the supply voltage is within the luminaires’ voltage rating.

•Ensure the marked T rating is less than the ignition temperature of the Hazardous

Atmosphere.

•Do not operate in ambient temperatures above those indicated on the luminaire nameplate.

•Do not operate if the lens is cracked or damaged. All fasteners should be properly seated.

For supply connections, usewirerated for at least 110°C

Recommended mounting height is 25-40 feet.

MOUNTING/ADJUSTMENT

The high output LED light head is mounted to an adjustable two-part swing arm constructed of light

weight aluminum. The two piece arm design provides two pivot points, one at the mounting bracket

and one in the center of the swing arm. The aluminum swing arm swings 170° from the mounting

bracket point and 340° from the center pivot point, while the light head is vertically adjustable up to

270°, providing full adjustability for this 150 Watt explosion proof LED fixture and allows users to

position the light as needed during operations. This switch blade swing arm can be mounted with the

light head oriented on the top side or bottom side of the arm, allowing operators to illuminate objects

in any location. This swing arm is ideal also for mounting the unit to loading door areas and docks for

use as a loading bay or dock light.

150 Watt Explosion Proof C1D1 LED Switch Blade Dock Light - 6' Pivoting

Aluminum Arm - 17,500 Lumens

Instruction Manual

EPL-SBDL-150RT-72

Larson Electronics, LLC Phone: (800) 369-6671 Fax: (903) 498-3364 www.larsonelectronics.com

2of 2

WIRING (see attached wiring diagram)

This unit comes preconfigured with 10` SOOW cord w/ Flying Leads,voltage, beam, and color.

Once mounted, plug cord into compatible receptacle with correct voltage. Voltage: 100-277 Volts

AC, 50/60Hz or 11-25 Volts AC/DC

MAINTENANCE

Caution: To avoid personal injury, disconnect power to the light and allow the unit to cool

down before performing maintenance.

Warning: No user serviceable parts inside of fixture. Risk of electric shock. Removal of the lens

will void the warranty.

1. Perform visual, mechanical and electrical inspections on a regular basis. We recommend

routine checks to be made on a yearly basis. Frequency of use and environment should

determine this. It is recommended to follow an Electrical Preventive Maintenance Program

as described in NFPA 70B: Recommended practice for Electrical Equipment.

2. The lens should be cleaned periodically as needed to ensure continued photometric

performance. Clean the lens with a damp, non-abrasive, lint-free cloth. If not sufficient, use

mild soap or a liquid cleaner.

3. Inspect the cooking fins on the luminaire to ensure that they are free of any obstructions

or contamination (i.e. excessive dust build-up). Clean with a non-abrasive cloth if

needed.

4. Do not operate if the lens is cracked or damaged. All fasteners should be properly seated.

WARRANTY

Should further information not covered by these instructions be required, please contact Larson Electronics at

1-800-369-6671 or sales@larsonelectronics.com for further assistance.

Please visit LarsonElectronics.com for Warranty and Return information.

WARNING: CHECK NAMEPLATE

FOR PROPER VOLTAGE. DAMAGE

FROM IMPROPER VOLTAGE WILL

VOID WARRANTY.
