Laseno SMP-120 Manuale utente
User Manual
Portable Smart Micro Laser Projector
Thank you for choosing Laseno SMP-120 portable smart micro laser projector. Before using
our product, please read this instruction manual carefully.
Please read the safety precausions and use the products properly.
The content of this user manual might change according to the software
version. The company reserves the rights to adjust and change the
content without further notie.
The pictures in the instruction manual might be not in full accord with the
actual products, and it is subjected to the actual product.
The software of this product is updatable.
1
Safe Use Precausions
Warning: please use the product properly according to the instruction manual.
Misuse might cause personal injury.
Ｄｏ ｎｏｔ ｕｓｅ ｗｈｅｎ ｄｒｉｖｉｎｇ． Ｐｌｅａｓｅ ｐａｙ ａｔｔｅｎｔｉｏｎ ｔｏ ｔｈｅ ｕｓｅ ｏｆ ｂａｔｔｅｒｙ．
Ｐｌｅａｓｅ ｐａｙ ａｔｔｅｎｔｉｏｎ ｔｏ ｔｈｅ ｕｓｅ ｏｆ ｂａｔｔｅｒｙ
To ensure the user’s safety, please read carefully the precausions and use properly this kind of product.
Due to the characteristics of laser light sorce, it needs warming up for a while to get the best effect.
Ｐｌｅａｓｅ ａｖｏｉｄ ｕｓｉｎｇ ｄａｍｐ ｐａｒｔｓ ｏｆ ｔｈｅ
ｂｏｄｙ ｔｏ ｔｏｕｃｈ ｔｈｅ ｐｒｏｄｕｃｔ ｏｒ ｔｈｅ
ｐｏｗｅｒ ｐｌｕｇ．
Ｔｈｅ ｒａｙ ｏｆ ｌｉｇｈｔ ｐｒｏｊｅｃｔｅｄ ｂｙ ｔｈｅ
ｐｒｏｄｕｃｔｓ ｓｈａｌｌ ｎｏｔ ｉｒｒａｄｉａｔｅ ｔｈｅ ｅｙｅｓ
ｏｆ ｈｕｍａｎ ｏｒ ａｎｉｍａｌｓ．
Ｐｌｅａｓｅ ｄｏ ｎｏｔ ｐｌａｃｅ ｔｈｅ ｐｒｏｄｕｃｔｓ，
ｂａｔｔｅｒｉｅｓ ｏｒ ｃｈａｒｇｅｒｓ ｏｎ ｏｒ ｃｌｏｓｅ ｔｏ ｔｈｅ
ｈｅａｔｉｎｇ ｄｅｖｉｃｅｓ （ｈｅａｔｅｒ， ｉｎｄｕｃｔｉｏｎ
ｃｏｏｋｅｒ， ｅｔｃ．）．
It might divert your attention and cause
traffic accidents. Please do not strike fiercely, or use sharp
objects to touch.
Please do not place it in high temperature
environment or heat up.
Please do not splash on it or immerse it into
the liqid.
Long time and high volume use might
cause the damage of hearing.
If playing with the high volume during
walking or driving, it might divert the
attention, even might cause accidents.
It might cause the damages of eyesight.
It may cause the damages of eyesight.
It may cause combustion or explosion.
2
Warning: please use properly this product according to the instruction manual.
Misuse might cause personal injury.
Ｐｌｅａｓｅ ａｖｏｉｄ ｆａｌｌｉｎｇ ｏｒ ｅｘｔｅｒｎａｌ ｓｔｒｉｋｅ． Ｐｌｅａｓｅ ｕｓｅ ｉｎ ｃｌｅａｎ ｅｎｖｉｒｏｎｍｅｎｔ．
Ｐｌｅａｓｅ ｂａｃｋ ｕｐ ｔｈｅ ｄａｔａ ｓｔｏｒｅｄ ｉｎ ｔｈｅ
ｐｒｏｄｕｃｔｓ．
Ｐｌｅａｓｅ ｐａｙ ａｔｔｅｎｔｉｏｎ ｔｏ ｔｈｅ ｐｕｂｌｉｃ
ｍｏｒａｌｉｔｙ ｄｕｒｉｎｇ ｔｈｅ ｕｓｅ ｏｆ ｔｈｅ ｐｒｏｄｕｃｔｓ
ｉｎ ｐｕｂｌｉｃ ａｒｅａ．
Ｐｌｅａｓｅ ｄｏ ｎｏｔ ｓｐｒａｙ ｃｏｌｏｒｓ ｏｎ ｔｈｅ ｐｒｏｄｕｃｔｓ
ｏｒ ａｆｆｉｘ ｐａｓｔｅｒｓ ｔｏ ｔｈｅｍ
Ｐｌｅａｓｅ ｄｏ ｎｏｔ ｔｒａｎｓｆｏｒｍ， ｒｅｐａｉｒ ｏｒ ｄｉｓｍａｎｔｌｅ
ａｔ ｗｉｌｌ．
It might cause the damages of product
display and appearance, or the damages of
internal fittings.
The environment with much dust might
cause the products to work abnormally.
Please go to the maintenance point
specified by the company for repair.
The products of being dismantled,
transformed and repaired at will lose the
right on maintenance service.
It might affect the normal use of moving
parts.
Due to the misuse by user or repair, the
data stored in the products might lose.
Therefore, the company warns that it is
better for the users to back up the data. The
company will not undertake the
responsibility for the data loss.
At the places like a meeting room or a
cinema, please use the products cautiously
to avoid affecting others.
According to personal constitution, coating
or paster might cause anaphylactic reaction.
3
Features
Ｌａｓｅｒ ｌｉｇｈｔ ｓｏｕｒｃｅ
Take laser as light source; auto focus;
20~50 lumens; working time is over
25,000 hours.
ＰＣ ｃｏｎｎｅｃｔｉｏｎ
Support USB OTG function. It is possible to
connect the USB or wireless mouse/keybord
and bluetooth peripherals, the product
could also connect to the PC to make the
files copied, moved, etc.
Ｂｕｉｌｄ－ｉｎ Ａｎｄｒｏｉｄ ｓｙｓｔｅｍ
Based on Android system, it supports
various forms of media play. It is easy to
check and enjoy music, films, pictures
and games whenever and wherever
possible.
ＷＩＦＩ ｗｉｒｅｌｅｓｓ ｉｎｔｅｒｎｅｔ ａｃｃｅｓｓ
Wireless signals will be searched and
connected automatically.
Ｒｅａｄ ｆｉｌｅｓ ｔｈｒｏｕｇｈ ＵＳＢ ｉｎｔｅｒｆａｃｅ
Plug and play the USB flash disks, wireless
mouses and so on, easy to connect the
laptops and other external devices.
While maintaining the thickness of the
product body of 3.3 cm, battery life of
over 80 minutes could be guaranteed.
Ｕｌｔｒａ－ｔｈｉｎ ｂｏｄｙ ａｎｄ ｕｌｔｒａ－ｌｏｎｇ ｓｔａｎｄｂｙ ｔｉｍｅ
4
Fitting List
Charger
SMP-120 main part
User Manual
Mini USB cable
*The actual fittings might differ from the picture, which will be adjusted according to the
actual situations.
Warranty Card
产品型号名称(Prod.Name)：
产品编码():
请填写完整本凭证内容并由销售代理商盖章，同时索取合法有效发
票，否则将可能影响您获取售后服务。请注意：保修卡必须经过销
售商盖章方才生效。
提示
Green Front Projection TV ( Projector )
绿色正投影电视机 ( 投影机 )
保修卡
用户指南
Portable Smart Micro Laser Projector
激光移动智能机 ( 微型投影机 )
5
Names of different parts
*USB memory as much as 32GB
Lens
Keyboard
Interfaces
Mini USB interface
USB interface
Charger interface
Earphone interface
DC
USB
6
Connect the DC IN interface of the product and the power box with appendant charger.
During charging, LED will be red.
When the charging is completed, LED will become green.
Charging Instruction
Start up and shut down
Charging indicator
Charging
Charging complete
Press to start up.
Press for 4~5 seconds to shut down.
7
Self-inspection before the Repair
The projector cannot be switched on
Please confirm the charging status
Please confirm whether the noise comes from electric fan or other motors.
Please confirm whether the file formats are supported. The formats of some files
downloaded from internet cannot be played.
Please confirm whether the file storage route is correct.
Please move to darker place, where the image could be zoomed in.
Long time use of the projector will produce heat.
The data lost due to initialization or break down cannot be recovered if there is no
backup copy.
Please back up the projection data to the safe place.
The company will not take the responsibility for the damages caused by projection
data loss.
Please press the Reset to restart.
Working time of the projector which completes charging will be shortened if it is
placed in low or high temperature environment.
LED indicator will restart when pressing keyboard. Its
working
time will also be shortened
due to frequent use.
The projector has abnormal noise
The files cannot be played
The files stored in built-in memory
cannot be found
The screen is not clear
The projector is hot
The data in projector are lost
Keys do not work or the image
freezes during the use of projector
Battery working time does not
correspond with the user manual
8
Key function
Press on/off to start up,
showing main menu.
Long press on/off (4-5
seconds) to shut down.
Short press on/off to
select to shut down or
enter other modes.
Press Home to back to
main menu.
Press back to return or
cancel, right click the
mouse is the same.
Press OK to confirm, left
click the mouse is the
same.
Press Up, Down, Left,
Right to operate.
Basic Operation
Key
Description
on/off
Turn on/Turn off
Home
Cancel/Return
Menu
direction
key
OK
back
menu
home
Up, down, left, right
OK
Function
9
