LATICRETE STRATA_HEAT 0802-0067-2 Manuale utente

STRATA_HEAT™Wire installation using STRATA_HEAT Spacing Strips.

IMPORTANT

Read this manual before attempting

to install your STRATA_HEAT™ Wire.

Incorrect installation could damage the

STRATA_HEAT™ Wire and will invalidate the warranty.

Globally Proven

Construction Solutions

Globally Proven

Construction Solutions

120V & 240V

WIRE

Loose Cable Installation Manual

Warranty

LIFETIME*

n STRATA_HEAT™Wire

n Installation Manual

n STRATA_HEAT Spacing Strips not included in package

(Sold separately)

ITEMS REQUIRED FOR SYSTEM

INSTALLATION:

nA STRATA_HEAT Thermostat with an integrated Ground

Fault Circuit Interrupter or separate GFCI breaker

installed in the household panel

nDigital ohmmeter (multi-meter)

nElectrical housing boxes/switch plates

nElectrical conduit

nAdhesive or hot melt glue

Before You Begin .................................................................................3

Product Information ............................................................................. 3

Area Guide...........................................................................................4

Do’s and Dont’s.................................................................................5-6

STRATA_HEAT™ Wire Specifications ...................................................... 7

STRATA_HEAT Wire Heating Cable Selection.............................................8

Thermal Insulation ................................................................................8

Floor Coverings.....................................................................................8

Subfloor Preparation..............................................................................9

Controlling Your System ......................................................................10

Wiring Diagram 120V .........................................................................11

Wiring Diagram 240V .........................................................................12

Electrical Provisions.............................................................................13

Testing the System .............................................................................14

Planning Your Installation ....................................................................15

Installing the STRATA_HEAT Spacing Strips.............................................15

Spacing Guide....................................................................................15

STRATA_HEAT Wire Installation.............................................................16

Installing the Floor Sensor....................................................................17

Installing the STRATA_HEAT Thermostat.................................................17

Floor Coverings – Tiles & Stone, Carpet, Vinyl or Laminate Flooring..........18

Floor Coverings – Hardwood Flooring ...................................................19

Points to Remember ...........................................................................20

Troubleshooting ..................................................................................21

Notes ...............................................................................................22

Control Card.......................................................................................23

Floor Plan .........................................................................................24

Warranty...........................................................................................25

Notes................................................................................................26

CONTENTS

If these instructions are followed you should not have any problems

during installation. However, if you require assistance at any stage,

please call our helpline: 203-393-0010 ext 235.

Thank you for purchasing the STRATA_HEAT™Wire. This manual contains IMPORTANT information regarding the safe use and

installation of your heating cable. Please read through the entire manual carefully before you install or use the product.

Double check your measurements and ensure that you have the correct heating cable for the area you wish to heat. The heating element

MUST NOT be installed under appliances or permanent fixtures such as refrigerators, cabinets, tubs, vanity units etc. Below is a quick

reference guide.

BEFORE YOU BEGIN

Product Information

The STRATA_HEAT Wire consists of:

A twin conductor resistance heating cable with a primary insulation of Fluoropolymer with high dielectric strength and high temperature

properties. The conductors are covered by a ground braid providing additional mechanical strength and a ground path. A final outer jacket

of PVC is given to make it sturdier and provide corrosion protection.

The heating cable is terminated at one end with a 10' (3.1 m) cold lead. The conductor cores and ground braid are factory joined in a

water resistant joint assembly to each supply conductor and ground conductor of the unheated lead. The heater is terminated at the other

end with a smaller water resistant joint.

The unheated power connection lead (10 ft / 3.1 m) can be trimmed to your needs or extended using a suitable UL-approved wire.

Always complete cable connections in a junction box. Do not leave excess wire in the wall. This must be carried out by a qualified

electrician in accordance with local/state laws and guidelines. Inspect the entire heating cable for damage, this includes the factory made

joint and end termination. If any parts are damaged contact LATICRETE Customer Service.

If you are missing any items from the box or believe that you have the incorrect STRATA_HEAT Wire to cover the area required, please call

the helpline for further assistance.

PRODUCT CODE

Cable Length

ft (m)

Uncoupling Systems Loose laid cable w/spacers

2 Pegs 3 Pegs 4 Pegs 2" (51 mm) 3" (76 mm) 4" (102 mm)

0802-0017-2 17 (5.2) 3 5 7 3 4 6

0802-0034-2 34 (10.4) 7 10 13 6 8 11

0802-0050-2 50 (15.2) 10 15 20 8 12 17

0802-0067-2 67 (20.4) 13 20 27 11 17 22

0802-0084-2 84 (25.6) 17 25 33 14 21 28

0802-0100-2 100 (30.5) 20 30 40 17 25 33

0802-0133-2 133 (40.5) 27 40 53 22 33 44

0802-0166-2 166 (50.6) 33 50 67 28 42 55

0802-0200-2 200 (61) 40 60 80 33 50 66

0802-0233-2 233 (70) 47 70 93 39 58 77

0802-0266-2 266 (81.1) 53 80 107 44 66 88

0802-0299-2 299 (91.1) 60 90 120 50 75 100

0802-0332-2 332 (101.2) 67 100 133 55 83 111

0802-0365-2 365 (111.3) 73 110 147 61 91 122

0802-0398-2 398 (121.3) 80 120 160 66 99 133

0802-0083-4 83 (25.3) 17 25 33 14 21 28

0802-0100-4 100 (30.5) 20 30 40 17 25 33

0802-0133-4 133 (40.5) 27 40 53 22 33 44

0802-0166-4 166 (50.6) 33 50 67 28 42 55

0802-0200-4 200 (61) 40 60 80 33 50 66

0802-0233-4 233 (70) 47 70 93 39 58 77

0802-0266-4 266 (81.1) 53 80 107 44 66 88

0802-0299-4 299 (91.1) 60 90 120 50 75 100

0802-0332-4 332 (101.2) 67 100 133 55 83 111

0802-0415-4 415 (126.5) 83 125 167 69 104 138

0802-0498-4 498 (151.8) 100 150 200 83 124 166

0802-0581-4 581 (177.1) 117 175 233 97 145 194

0802-0664-4 664 (202.4) 133 200 266 111 166 221

0802-0747-4 747 (227.7) 150 225 300 124 187 249

0802-0830-4 830 (253) 167 250 333 138 207 276

120 Volt

240 Volt

AREA GUIDE

Ensure that you have the correct STRATA_HEAT™Wire for the area you wish to heat using the table below.

DO’S AND…

DO carefully read this installation manual before commencing installation.

DO When loose laying the STRATA_HEAT™Wire on the floor, maintain a consistent cable spacing of no less than 2”

(51 mm) and no more than 4" (102 mm).

DO make sure all electrical work is done by qualified persons in accordance with local building and electrical codes, the

National Electrical Code (NEC), especially article 424, Part V of the NEC, ANSI/NFPA 70, for the US and Canadian

Electrical Code, Part 1, for Canada.

DO check the resistance of the STRATA_HEAT Wire before, during, and after installation to ensure that the

STRATA_HEAT Wire has not been damaged. The value should match the rating label found on the product. A

tolerance of +/- 5% is allowed.

DO ensure that the STRATA_HEAT Wire is connected to a Class A Ground Fault Circuit Interrupter (GFCI) at all times.

DO plan the heating system layout and installation so that any drilling after tiling (e.g. for fixtures such as vanity units,

tubs) will not damage the wiring. Remember to keep a copy for future reference.

DO take some pictures before installing the floor covering for future reference.

DO ensure that the STRATA_HEAT Wire is separated from other heat sources such as luminaires and chimneys.

DO ensure that the minimum bending radius is no less than 1" (25 mm) for the STRATA_HEAT Wire.

DO allow sufficient drying/curing of the subfloor before commencing installation of the STRATA_HEAT Wire.

DO ensure that each tile is solidly bedded in tile adhesive, with no gaps or voids beneath.

DO make sure that ALL STRATA_HEAT Wires including the joints are positioned under the final floor finish and

completely embedded in thinset/adhesive.

DO remember to install the floor probe for the STRATA_HEAT Thermostat. The floor sensor should be located in the centre

of two heating element runs. Ensure that the sensor does not touch or cross over any of the STRATA_HEAT Wires.

DO ensure that you have electrical provisions to run the heating system at 120VAC /or 240VAC depending on the

system being installed.

DO check the wattage and voltage of the STRATA_HEAT Wire to ensure you have the correct system for your application.

DO ensure that the cold tail conduit is kept separate from the sensor conduit.

DO remember to attach the rating labels included within this manual to the circuit breaker and thermostatics controls.

…DONT’S

DON’T allow the STRATA_HEAT™Wire on the mat to cross over or touch each other at any point as this can cause the cable

to overheat. Always use the STRATA_HEAT Spacing Strips to avoid this.

DON’T cut or shorten the STRATA_HEAT Wire at any time.

DON’T install the STRATA_HEAT Wire with any staples or other metal fixings that can damage the STRATA_HEAT Wire.

DON’T store tiles, sharp or heavy objects on any of the STRATA_HEAT Wire while tiling or bang a trowel on the installation

area to remove excess mortar from the trowel.

DON’T install the STRATA_HEAT Wire below 5°F (-15°C) ambient temperature.

DON’T attempt to bypass the GFCI if it trips and cannot be reset during normal operation. Consult a qualified electrician or

call the helpline for further assistance.

DON’T install the STRATA_HEAT Wire under permanent fixtures.

DON’T commence installation on a mud job/screed that has not been fully cured.

DON`T use the STRATA_HEAT Wire system until you have allowed sufficient drying period for the finished floor.

DON’T cover the cold lead joint or termination joint with tape when securing the subfloor. This may cause air pockets

resulting in the joints overheating.

DON’T install the STRATA_HEAT Wire beyond the room or area in which they originate.

DON’T attempt to repair the STRATA_HEAT Wire if it becomes damaged. Call the technical helpline for further instructions.

DON`T allow the STRATA_HEAT Thermostat to exceed the maximum temperature for your final floor finish. Always check

the maximum temperatures allowed with the floor covering manufacturer.

DON’T switch on the installed STRATA_HEAT Wire until tile adhesive has fully cured (1 – 3 weeks minimum), check

adhesive manufacturer’s instructions.

DON’T install the cold leads closer than 2" (51 mm) from the STRATA_HEAT Wire on the mat.

3.5" (89 mm)

Spacing

120 Volt

Area ft² (m²) Model Length ft (m) Wattage (W) Amps (A) Resistance (Ω)

5 (0.46) 0802-0017-2 17 (5.2) 65 0.5 221.5

10 (0.93) 0802-0034-2 34 (10.4) 130 1.1 110.8

15 (1.39) 0802-0050-2 50 (15.2) 195 1.6 73.8

20 (1.86) 0802-0067-2 67 (20.4) 260 2.2 55.4

25 (2.32) 0802-0084-2 84 (25.6) 325 2.7 44.3

30 (2.79) 0802-0100-2 100 (30.5) 390 3.3 36.9

40 (3.72) 0802-0133-2 133 (40.5) 525 4.4 27.4

50 (4.64) 0802-0166-2 166 (50.6) 655 5.5 22.0

60 (5.57) 0802-0200-2 200 (61) 785 6.5 18.3

70 (6.50) 0802-0233-2 233 (70) 920 7.7 15.6

80 (7.43) 0802-0266-2 266 (81.1) 1050 8.8 13.7

90 (8.36) 0802-0299-2 299 (91.1) 1180 9.8 12.2

100 (9.29) 0802-0332-2 332 (101.2) 1315 11.0 11.0

110 (10.22) 0802-0365-2 365 (111.3) 1445 12.0 10.0

120 (11.15) 0802-0398-2 398 (121.3) 1575 13.1 9.1

STRATA_HEAT™WIRE SPECIFICATIONS

3.5” (89 mm)

Spacing

240 Volt

Area ft² (m²) Model Length ft (m) Wattage (W) Amps (A) Resistance (Ω)

25 (2.32) 0802-0083-4 83 (25.3) 335 1.4 177.2

30 (2.79) 0802-0100-4 100 (30.5) 400 1.6 147.7

40 (3.72) 0802-0133-4 133 (40.5) 535 2.2 110.1

50 (4.64) 0802-0166-4 166 (50.6) 670 2.7 87.9

60 (5.57) 0802-0200-4 200 (61) 800 3.3 73.4

70 (6.50) 0802-0233-4 233 (70) 935 3.8 62.6

80 (7.43) 0802-0266-4 266 (81.1) 1070 4.4 54.9

90 (8.36) 0802-0299-4 299 (91.1) 1205 4.9 48.8

100 (9.29) 0802-0332-4 332 (101.2) 1340 5.5 44.0

125 (11.61) 0802-0415-4 415 (126.5) 1675 6.8 35.1

150 (13.94) 0802-0498-4 498 (151.8) 2010 8.2 29.2

175 (16.26) 0802-0581-4 581 (177.1) 2345 9.6 25.0

200 (18.58) 0802-0664-4 664 (202.4) 2680 11.0 22.1

225 (20.90) 0802-0747-4 747 (227.7) 3015 12.3 19.5

250 (23.23) 0802-0830-4 830 (253) 3240 13.5 17.8

Note: The STRATA_HEAT™Wire spacing must be no less than 3" (76 mm) at all times. The maximum area loading MUST NOT exceed

15W/sq ft. (15 W/929 cm2)

The table below can be taken as a general guide. Actual requirements will depend on the floor construction, type of floor coverings,

insulation levels etc. The STRATA_HEAT™ Wire selection will depend on the application.

Application W/sq ft

New floors in builds with high levels of insulation 13W/sq ft (13W/929 cm2)

Wooden floors 11W/sq ft (13W/929 cm2)

Wet areas (showers, bathrooms, steam rooms etc) 13W/sq ft (13W/929 cm2)

Note: The UL Listing for this product covers use in wet locations for CANADA only. Wet location installation in United States shall be

in accordance with the National Electric Code, NFPA 70 and any other applicable jurisdictional code and final acceptance is to be made by

the Authority having Jurisdiction (AHJ).

Thermal Insulation

The insulation levels of a floor will affect both the performance & running costs of under tile heating. Using the heating cable without

thermal insulation can take up to 5 hours to heat a room whereas a system with thermal insulation takes less than an hour.

If the LATICRETE STRATA_HEAT Wire is being installed onto a concrete base it is highly recommended that a layer of insulation is used

prior to installing the heating cable. The thermal insulation reflects the heat upwards instead of allowing heat to penetrate into the

subfloor, greatly improving the warm-up times & running costs.

The thickness of insulation required will depend on whether it is for floor renovation or a new floor.

Floor Coverings

All floor finishes should be installed as per the manufacturer´s instructions. With radiant heating, the floor covering is essentially part of

the heating system. The most suitable floor coverings are those with a low thermal resistance, normally referred to as the R-value.

The type and thickness of floor covering materials used with this product must not exceed a thermal insulation “R” value of 1.

Floor covering R Value

Carpet 1.0

Ceramic, Mosaic Tile 0.15

Laminate Flooring 0.675

Natural Stone 0.38 - 0.114

Wood Flooring 0.80

STRATA_HEAT™WIRE HEATING CABLE SELECTION

Ensure that the subfloor is smooth, dry and free from dust. Visually check that there are no objects on the floor that might damage the

heater.

Where necessary an appropriate smoothing compound should be applied and allowed to cure.

If the cable is being fitted to a solid floor it is essential that the concrete slab has been allowed to cure.

If using the HYDRO BAN®Boards, use a suitable cement based adhesive and screws to the subfloor as per the instructions.

If installing in a wet room ensure a slope in the mortar bed is maintained in order to direct water to the drain pipe.

SUBFLOOR PREPARATION

LATICRETE only recommends STRATA_HEAT™ Thermostats designed for use with underfloor heating to control the STRATA_HEAT Wire

loose heating cables. When using multiple loose heating cables you can connect them in parallel to the same thermostat. Check with your

installer or call LATICRETE for circuit sizes and maximum loads.

The thermostats come with a 9' (2.74 m) sensor cable to detect the temperature under the floor finish. The end of the probe wire

contains a capped sensor that should be evenly centered between two heating cables at least 12" (305 mm) into the heated area. At no

time should the probe wire cross the heating cable.

If you have more than one heating cable, all the lead wires need to be connected in parallel to the thermostat. For convenience, it may

be easier to run multiple lead wires to a junction box and then take a single wire (which has the appropriate rating) from the junction box

to the thermostat.

NOTE: 240V wires are Red and Black. 120V wires are Yellow and Black. Connect ground wires to the power source ground.

The total Amp load of the heating cable(s) must not exceed the thermostat’s Amp limit or the Amperage rating of the circuit or other

control switch without using an appropriately rated contactor/relay.

The LATICRETE STRATA_HEAT Wire has a maximum resistive load of 15 Amps. Please refer to the table on page 7 to calculate the

amperage load for your particular system.

For smaller areas, you may be able to utilize an existing circuit. In most cases, however, you will need a separate dedicated circuit to

power the LATICRETE STRATA_HEAT Wire heating cables.

The STRATA_HEAT Thermostat should be connected to the main electrical supply via a fuse or circuit in accordance with the National

Electrical Code. If the STRATA_HEAT Thermostat used does not include a built-in Ground Fault Circuit Interrupter (GFCI), then one must be

added to the circuit between the main power supply and the thermostat. If the thermostat does include a GFCI, it is NOT recommended to

include another in the circuit, as this may cause accidental tripping of the control unit.

Further details on the installation of the thermostat can be found in the instruction manual included with the thermostat.

Ensuring Safety

Install the STRATA_HEAT Thermostat within the same room as the STRATA_HEAT Wire heating cables. In order to ensure the efficient

running of the system within bathrooms, we recommend that the controls are located at least 60 inches (1.52 m) away from shower

openings or basin back splash areas so you minimize the possibility of exposure to water.

The control card on page 23 of this manual must be attached to the circuit breaker box for referral by the homeowner or electrical

inspector.

CONTROLLING YOUR SYSTEM

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali LATICRETE Sistema di riscaldamento

LATICRETE

LATICRETE STRATA_HEAT 120V Manuale utente

Manuali Sistema di riscaldamento popolari di altre marche

aerauliqa

aerauliqa QR350ABP Manuale utente

WatchGas

WatchGas ATEX BEACON Manuale utente

Viessmann

Viessmann Vitoligno 300-H Istruzioni operative

Lampoassa

Lampoassa 203GT Manuale utente

MSA

MSA SOA-1022 Manuale utente

nilan

nilan Compact P Manuale utente

ITR

ITR OASIS NE-S Manuale utente

Carrier

Carrier 48LJD Dimensioni e guida di installazione

aldes

aldes EVEREST XV Manuale utente

Kober

Kober C22SPV23MEF Manuale utente

Oxygen

Oxygen X-Air V400 Manuale utente

Carrier

Carrier FB4CNF Manuale utente

Kroll

Kroll HM200 Manuale

Kroll

Kroll HM200 Manuale

NuAire

NuAire XBOXER XBC Series Manuale utente

Trane

Trane VR104GD-U Series Manuale utente

Vents

Vents VUT V mini Manuale utente

Viessmann

Viessmann Divicon Manuale utente
