Leenders LOBBE Manuale utente
SINCE 1979
LOBBE
INSTALLATION EN
LOBBE HARRIE LEENDERS
LOBBE HARRIE LEENDERS
To level
Use the 2 bolts in the back of
the base to level the Lobbe and
prevent it from wobbling.
Points of attention installation Lobbe
LOBBE HARRIE LEENDERS
General instructions and regulations
Installation
•To secure the warranty, the Lobbe must be installed by a properly qualied person employed by a
dealer recognized by Harrie Leenders Haardkachels. See leenders.nl for a current list of addresses of
recognized dealers or contact the manufacturer.
•The stove is susceptible to scratching. Handle with care.
•After installation, check the draught by burning some kindling wood.
Use
•All local regulations including those referring to national and European standards must be observed
when installing the appliance.
•Ensure there is sufcient ventilation/air supply in the room where the stove is installed. Air extractors
such as a cooker hood may cause problems due to ue gases escaping from the stove into the room.
•The appliance is not suitable for a shared ue system.
•The appliance must be installed on a oor having sufcient bearing capacity.
•Ensure adequate access for cleaning the appliance, the ue-gas connection and the chimney.
Safety instructions
•Glass is quite susceptible to breaking and broken glass is quite sharp. Take appropriate measures.
•For general safety, we refer to the VCA guidelines.
•Note: After installation, ensure there is no inammable and/or explosion-hazardous material in or on
the stove such as a spray can, packing material and the like.
Distance to combustible materials
Back: 200 mm
Side: 350 mm
Front: 1200 mm
Specications Lobbe
•Nominal power = 5.2 kWh
•Flue gas mass ow = 5.8 g/s
•Appliance weight = 125 kg
•Minimum chimney draught = 11.9 Pa
•Flue gas temperature directly over the stove = 211 °C
