LENCO XEMIO-260 Manuale utente
XEMIO-260 USER MANUAL
1
Special Features
●Elegant appearance and easy to use.
●Multi-Code Player - Supporting MP1, MP2, MP3, WMA, formats.
●Drive Free U Disk - You may manage your files directly through “Portable Device”
in “My Computer” on Windows 2000 Operating System or above without driver.
Brief view of player
Appearance
A. Key function of buttons
Pre: To previous song or skip
backward
Next: To the next song or speed play
PLAY: To Play/ Pause/ Stop
VOL-: To decrease the volume
VOL+: To increase the volume
On/off: To turn/on the player
B. MP3 Mode
1
．
．．
．
Turn On/ Off
1.1 Make sure the switch is ON and not connect with computer. Long press ►II to
turn on and play the music directly. Long press ►II button to turn off.
Press ►II button to start playing the music.
2. Adjust the volume
Press +/- button to increase or decrease the volume during play mode.
3. To choose music
In MP3 mode, press Next/Pre Button to select previous or next music.
XEMIO-260 USER MANUAL
2
C. USB Mode
1. Plug-in the player into the computer with the USB cable, a USB window will be
shown in the computer (expect WINDOWS 98) when recognizing the MP3 player. A
removable disk drive will be shown in “My computer” folder. You can start Read/
Write operation now.
2. Remove the player from computer
In WINDOW system, please safety removes the player in the computer.
Otherwise, the data stored in the MP3 might be lost.
D. Indicator light & Battery
Play status: Red light flashing:
Pause status: Red light bright:
Connect to computer: Light bright
Recharge the battery: Light bright (recharge only in “ON” mode)
Recharge complete: Blue light bright:
**Recharge the battery:
(Please turn the player into “ON” mode, connect the player via USB cable with the
computer, battery will be automatically charged, 2-3 hours will be fully charged)
E. Using with MAC OS 9.X system or above
1. Connect the player with MAC computer, “Untitled” icon will display on the
desktop indicating the player is a removable disk, user can operate read and
write function.
2.
When you need to disconnect the player from the USB plug, please drag
“Untitled” icon to the recycled bin, then unplug the player, otherwise, the data
stored in MP3 might be loss.
Note: This player supports MAC 9.2 system or above.
XEMIO-260 USER MANUAL
3
F. Troubleshooting
G. Technical Specifications
Interface USB2.0(FS)
（
Read 1000K Byte
，
Write 800K Byte
）
Capacity Flash memory
：
4GB
Earphones output
power
（
L
）
10mW
＋（
R
）
10mW
（
32Ohm
）
MP3 bitrate 8K bps – 320K bps
WMA Bitrate 5K bps – 384K bps
Frequency response 20Hz
至
20KHz
MP3
、
WMA
Single noise Ratio 85dB
File type MP1
、
MP2
、
MP3
、
WMA
Working temperature -5 to 40°C
Supported operation system Windows98/SE/ME/2K/XP MAC OS 9.2 or above
Note: Product design and specification are subject to change without prior notice.
For information and support, www.lenco.eu
No Power 1. Check if battery is low.
2. Check if the player is ON.
No sound from
earphone
1. Check to see Volume is set “0” and connect the earphone
connects properly.
2. Make sure earphone is clean and in good status.
3. Damaged MP3 file may make noise and could not be played
Make sure that the music files are not damaged.
Failure of music
download
1. Check if USB cable is damaged and connected properly.
2. Check if driver is installed correctly.
3. Check if memory space is enough.
