Lenovo A7700 Manuale utente

Lenovo A7700

User Guide V1.0

Lenovo A7700

Basics

Before using this information and the product it supports, be sure to read the following:

Quick Start Guide

Regulatory Notice

Appendix

The Quick Start Guide and the Regulatory Notice have been uploaded to the website at

http://support.lenovo.com.

Lenovo Companion

Looking for help? The Lenovo Companion app can offer you support for getting direct access to

Lenovo's web assistance and forums*, frequent Q&A*, system upgrades*, hardware function

tests, warranty status checks*, service requests**, and repair status**.

Note:

* requires data network access.

** is not available in all countries.

You have two ways to get this app:

Search for and download the app from Google Play.

Scan the following QR code with a Lenovo Android device.

Technical specifications

This section lists the technical specifications about wireless communication only. To view a full

list of technical specifications about your phone, go to http://support.lenovo.com.

Data FDD-LTE/TDD-LTE/WCDMA/GSM

Note: In some countries, LTE is not supported. To know if your smartphone

works with LTE networks in your country, contact your carrier.

WLAN WLAN 802.11 b/g/n, 2.4 GHz

BluetoothBluetooth 4.0

GPS Supported

Screen buttons

There are three buttons on your phone.

Multitask button: Press and hold to display menu options. Tap the Multitask button to see

the apps that are running. Then you can do the following:

Tap an app to open it.

Tap to lock the app or tap to unlock it.

Tap to stop running the app.

Tap to stop running all the apps except the locked ones.

Home button: Tap to return to the home screen.

Back button: Tap to return to the previous page or exit the current app.

Home screen

The home screen is the starting point for using your phone. For your convenience, the home

screen is already set up with some useful apps and widgets.

Note: Your phone's features and the home screen may be different depending on your

location, language, carrier, and model.

Customizing home screens in edit mode

Press and hold the Multitask button or any blank area on the home screen to enter edit mode.

Tap the back button to exit edit mode.

In edit mode, you can do any of the following:

To move a home screen, press and hold a screen thumbnail until it enlarges slightly, drag it

to the new location, and then release it.

To add a widget to the home screen, tap WIDGETS, swipe up or down to locate the widget

that you want, press and hold the widget until it pops out, drag it to where you want to place

it, and then release it.

Tip: Some widgets are grouped by app, swipe up or down to locate the app that you

want and swipe left or right to see the available widgets.

To change the wallpaper, tap WALLPAPERS, swipe left or right to locate the wallpaper that

you want, and then tap Set wallpaper.

Managing widgets and apps

Whether your home screen is in edit mode or not, you can do any of the following:

To move a widget or an app, press and hold the widget or app until its icon enlarges slightly,

drag it to where you want to place it, and then release it.

To create an app folder, press and hold an app until its icon enlarges slightly, and then drag

it onto another app.

To remove a widget from the home screen, press and hold the widget until its icon enlarges

slightly, slide your finger toward the top of the screen, and then drop the widget over .

To uninstall an app, press and hold the app, slide your finger toward the top of the screen,

and then drop the app over .

Note: System apps cannot be uninstalled. When you are trying to uninstall a system

app, does not appear at the top of the screen.

Screen lock

When your phone is on, press the On/Off button to lock the screen manually. Press the On/Off

button again to display the lock screen, and then swipe up from the bottom of the screen to

unlock.

Note: Swipe is the default screen unlocking method. To change your screen lock, see

Settings.

Notifications and Quick Settings

The Notification panel (see Figure 1: Notification) informs you of missed calls, new messages,

and activities in progress such as file downloading. The Quick Settings panel (see Figure 2:

Quick Settings) allows you to access frequently-used settings such as the WLAN switch.

Figure 1: Notification

Figure 2: Quick Settings

You can do any of the following:

To see notifications, swipe down from the top of the screen.

To close the Notification panel, swipe up from the bottom of the screen.

To dismiss a notification, swipe left or right across the notification.

To dismiss all notifications, tap at the bottom of the Notification panel.

To open the Quick Settings panel, swipe down from the top of the screen twice.

To close the Quick Settings panel, swipe up from the bottom of the screen.

USB connection

When you connect your phone to a computer using a USB cable, the Notification panel displays

a notification such as "USB computer connection". You can tap the notification, and then select

one of the following options:

Media device (MTP): Select this mode if you want to transfer any files between your phone

and the computer.

Camera (PTP): Select this mode if you want to transfer only photos and videos between your

phone and the computer.

MIDI: Select this mode if you want MIDI-enabled applications on your phone to work with MIDI

software on the computer.

Charge only: Select this mode if you want to charge your phone only.

Built-in CD-ROM: Show a virtual CD-ROW containing some useful software.

USB debugging: Debug mode is active when USB is connected. Manage your mobile with a

computer, and it is recommended to use official software.

Calls

Making a call

Dialing a number manually

1.Open the Phone app.

2.In the DIALER tab, tap to display the dialpad if necessary.

3.Enter the phone number that you want to dial, and then tap .

Calling from the call log

1.Open the Phone app.

2.Tap the CALL LOG tab.

3.Tap a call log entry to make a call.

Calling a contact

1.Open the Phone app.

2.Tap the CONTACTS tab.

3.Locate the contact that you want to call, and tap the contact name to display the contact

details.

4.Tap the phone number that you want to dial.

Receiving calls

Answering or rejecting a call

When you receive a phone call, the incoming call screen appears. You can do one of the

following:

Drag the contact image to or tap to answer the call.

Drag the contact image to or tap to reject the call.

Silencing a call

You have the following ways to silence a call:

Press the volume up button or the volume down button.

Press the On/Off button.

Options during a call

When you are on a call, the following options are available on the screen:

Add call: displays the dialpad so you can call another person.

On/Cancel hold: puts the current call on hold or resumes the call.

Mute: turns the microphone on or off.

Record: starts or stops recording the call.

Dialpad: displays or hides the keypad.

Speaker: turns the speaker on or off.

: ends the call.

You can also press the volume button to turn the volume up or down.

Using the call log

The call log contains missed, outgoing, and incoming call entries. You can press and hold a call

log entry until the options menu appears, and then tap an option. For example, you can tap the

Copy to clipboard option to add the number to the clipboard.

Contacts

Creating a contact

1. Open the Contacts app.

2. Tap .

3. Enter the contact information.

4. Tap to Save.

Searching for a contact

1. Open the Contacts app.

2. Do one of the following:

Scroll the Contacts list up or down to locate the desired contact.

Tip: The Contacts list has an index along the side to help you navigate quickly. Tap a

letter to jump to a section.

Enter the contact name or initials in search box, then matching contacts are displayed as

you type.

Editing a contact

1. Open the Contacts app.

2. Find and tap the contact that you want to edit.

3. Tap , and then edit the contact information.

4. Tap to Save.

Deleting a contact

1. Open the Contacts app.

2. Press and hold to display menu options

3. Tap Delete, select the contact that you want to delete, and then tap OK.

Importing/Exporting contacts

1. Open the Contacts app.

2. Press and hold to display menu options

3. Tap Import/Export.

4. Choose which source do you want to copy contacts from, and then tap NEXT.

5. Choose which destination do you want to copy contacts to, and then tap NEXT.

6. Select the contact that you want to Import/Export, and then tap OK.

Messaging

Sending a message

You can use the Messaging app to send text messages and multimedia messages.

1. Open the Messaging app.

2. Tap .

3. Tap the recipient text box, and then enter a contact name or phone number. Matching

contacts are displayed as you type. Select a contact.

Or tap to add more recipients.

4. Tap the message text box, and then enter a message.

Tip: If you want to send a multimedia message, tap to select a media object type

such as pictures or video clips, and then attach a desired media object to the message.

5. Tap .

Searching for a message

1. Open the Messaging app.

2. Tap , and then enter all or part of the contact name, the phone number, or the message

into the search text box.

Deleting messages

1. Open the Messaging app.

2. In the list of message threads, tap a contact name or phone number to view the message

thread.

3. Press and hold a message until it is selected, tap , and then tap Delete.

Or tap > Delete all threads, and then tap Delete to delete all messages.

Camera

Camera basics

You can use the Camera app to take photos and record videos.

Tap , or to choose a camera mode.

Tap to take a photo.

Tap to record a video.

Tap the photo or video thumbnail to view the photo or video in the Gallery or Photos app.

For more information, see Gallery.

Tap to use Gesture capture.

Tap to use HDR (High Dynamic Range).

Tap to switch between flash modes.

Tap to switch between the front-facing camera and the rear-facing camera.

Tap to configure the other camera settings.

Taking a screenshot

Press and hold the On/Off button and the volume down button at the same time to take a

screenshot.

By default, the screenshots are stored in your phone's internal storage. To view the screenshots,

do one of the following:

Open the Gallery app and find the Screenshot album.

Open the File Manager app and go to the Internal Storage > Pictures > Screenshots

folder.

Gallery

Viewing photos and videos

1. Open the Gallery app.

2. Tap an album.

By default, photos and videos are grouped together by album. If you want to group photos or

videos by location, tap , and then select Locations. If you want to group photos or videos

by time, tap , and then select Times.

3. Tap a photo or video to view it in full screen mode.

4. Do any of the following:

To see the next or previous photo or video, swipe left or right.

To zoom in or out of a photo, stretch or pinch the photo. When you zoom in, you can drag

to see other parts of the photo.

To view a video, tap .

Sharing photos and videos

When you are viewing a photo or video, tap anywhere on the screen, tap , and then select a

sharing channel such as Gmail or Bluetooth to share the photo or video with others.

If you want to share multiple photos and videos at the same time, do all of the following:

1. Open the Gallery app.

2. When viewing a group of photos or videos, press and hold the photo or video that you want to

share until it is selected.

3. Tap more items.

4. Tap , and then select a sharing channel.

Deleting photos and videos

When you are viewing a photo or video, tap anywhere on the screen, tap > Delete, and then

tap OK to delete the photo or video.

If you want to delete multiple photos and videos at the same time, do all of the following:

1. Open the Gallery app.

2. When viewing a group of photos or videos, press and hold the photo or video that you want to

delete until it is selected.

3. Tap more items.

4. Tap .

Altri manuali per A7700

Indice

Altri manuali Lenovo Telefono cellulare

Lenovo

Lenovo A6020a46 Manuale utente

Lenovo

Lenovo moto c Manuale utente

Lenovo

Lenovo A5000 Manuale utente

Lenovo

Lenovo Vibe Shot Z90a40 Manuale utente

Lenovo

Lenovo IDEAPHONE S890 Manuale utente

Lenovo

Lenovo S856 Manuale utente

Lenovo

Lenovo A369i Manuale utente

Lenovo

Lenovo Moto G8 Plus Manuale di installazione e funzionamento

Lenovo

Lenovo i909 Manuale utente

Lenovo

Lenovo PHAB2 Plus Manuale utente

Lenovo

Lenovo A859 Manuale utente

Lenovo

Lenovo A606 Manuale utente

Lenovo

Lenovo A7010 Manuale utente

Lenovo

Lenovo Legion Phone Duel 2 Manuale utente

Lenovo

Lenovo TAB S8-50 Manuale utente

Lenovo

Lenovo S930 Manuale utente

Lenovo

Lenovo S580 Manuale utente

Lenovo

Lenovo E156 Manuale utente

Lenovo

Lenovo Phab Plus Manuale del proprietario

Lenovo

Lenovo A6600 Manuale utente

Lenovo

Lenovo PHAB Plus PB1-770M Come usare

Lenovo

Lenovo IdeaTab A1000 Manuale utente

Lenovo

Lenovo VIBE P1m SERIES Manuale utente

Lenovo

Lenovo S90-L Manuale utente

Manuali Telefono cellulare popolari di altre marche

Zte

Zte BLADE A520 Manuale utente

Nokia

Nokia Lumia 620 Manuale utente

Blackbe;rry

Blackbe;rry KEYone Manuale utente

Bea-fon

Bea-fon X5 Premium Manuale utente

Blackbe;rry

Blackbe;rry 8707 Series Manuale utente

Blackbe;rry

Blackbe;rry Storm Istruzioni operative

LG LM-X420QN Manuale utente

LifeWatch

LifeWatch V Manuale utente

Bea-fon

Bea-fon SILVER LINE SL860 Manuale utente

IKI Mobile

IKI Mobile KF4.5i Manuale utente

Hitech

Hitech HT-850 Manuale utente

Yezz

Yezz Fashion F10 Manuale utente

Point Mobile

Point Mobile PM60 Manuale utente

Blackbe;rry

Blackbe;rry Q10 Manuale utente

Blackbe;rry

Blackbe;rry Bold 9900 Manuale utente

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuale utente

LG LM-K420EMW Manuale utente

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuale utente
