Lenovo PHAB2 Come usare

Read this guide carefully before using your device.

Lenovo PHAB2

Safety, Warranty & Quick Start Guide

Lenovo PB2-650Y

Reading before using your device

Reading ﬁrst - regulatory information

Be sure to read the Regulatory Notice for your country or region before using the

wireless devices contained in your device. To obtain a PDF version of the Regulatory

Notice, refer to the “Downloading publications” section below.

Getting support

To get support on network service and billing, contact your wireless network operator.

To learn how to use your device and view its technical speciﬁcations, go to

http://support.lenovo.com.

Downloading publications

Electronic versions of your publications are available from http://support.lenovo.com.

To download the publications for your device, go to http://support.lenovo.com and

follow the instructions on the screen.

Accessing your User Guide

Your User Guide contains detailed information about your device. Go to http://sup-

port.lenovo.com and follow the instructions on the screen.

Legal notices

Lenovo and the Lenovo logo are trademarks of Lenovo in the United States, other

countries, or both.

Other company, product, or service names may be trademarks or service marks of

others.

Manufactured under license from Dolby Laboratories. Dolby, Dolby Atmos, and the

double-D symbol are trademarks of Dolby Laboratories.

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant

a General Services Administration “GSA” contract, use, reproduction, or disclosure is

subject to restrictions set forth in Contract No. GS-35F-05925.

Micro USB connector

11 12

On/Off button

Speaker

Microphone

Volume buttons

Headset jack

Card tray

Rear camera

Touch screen

Front camera

5 66

Receiver

Light/Proximity sensor

Flash 14 15

Anti-noise microphones

Lenovo PHAB2 overview

Lenovo PB2-650Y

Model Version

WLAN + LTE (Voice)

Indicator

Micro-SIM

microSD

Micro-SIM1

Micro-SIM2

Step 3. Carefully insert the card tray with the installed

cards back into the slot.

Install the Micro-SIM and the microSD cards as shown.

Only Micro-SIM card works with your device.

Do not insert or remove the Micro-SIM card while your device is on. Doing so can

permanently damage your Micro-SIM card or device.

Preparing your device

Step 1. Insert the eject tool that comes with your device

into the hole in the card tray.

Step 2.

Position the Micro-SIM and microSD cards

into the corresponding card slot.

Position the Micro-SIM1 and Micro-SIM2

cards into the corresponding card slot.

Pull out the card tray and do one of the following:

Turning on/off

You might need to charge the battery before using your device.

Charge the battery as shown.

Connect your device to a power outlet using the cable and USB power adapter

provided.

Low battery Fully charged Charging

Turn on: Press and hold the On/Off button until the Lenovo logo appears.

Turn off: Press and hold the On/Off button for a few seconds, then tap Power off.

Restart: Press and hold the On/Off button for a few seconds, then tap Reboot.

Starting to use your device

Taking screenshots

Press and hold the On/Off button and the Volume down button at the same time.

Important safety and handling information

Plastic bag notice

DANGER: Plastic bags can be dangerous. Keep plastic bags away from babies and

children to avoid danger of suffocation.

Built-in rechargeable battery notice

DANGER: Do not attempt to replace the internal rechargeable lithium ion battery. Risk

of explosion if the battery is replaced with an incorrect type. Contact Lenovo Support

for factory replacement.

Caution about high volume usage

Warning：exposure to loud noise from any source for extended periods of time may

affect your hearing. The louder the sound,the less time is required before your hearing

could be affected. To protect your hearing:

Limit the amount of time you use headsets or headphones at high volume.

Avoid turning up the volume to block out noisy surroundings.

Turn the volume down if you can’t hear people speaking near you.

If you experience hearing discomfort, including the sensation of pressure or fullness in

your ears, ringing in your ears or mufﬂed speech, you should stop listening to the

device through your headset or headphones and have your hearing checked.

Service and support information

The following information describes the technical support that is available for your

product, during the warranty period or throughout the life of your product. Refer to the

Lenovo Limited Warranty (LLW) for a full explanation of Lenovo warranty terms. See

“Lenovo Limited Warranty notice” later in this document for details on accessing the

full warranty.

Online technical support

Online technical support is available during the lifetime of a product at:

http://www.lenovo.com/support

Telephone technical support

You can get help and information from the Customer Support Center by telephone.

Before contacting a Lenovo technical support representative, please have the

following information available: model and serial number, the exact wording of any

error message, and a description of the problem.

Your technical support representative might want to walk you through the problem

while you are at your device during the call.

Worldwide Lenovo support telephone list

Important: Telephone numbers are subject to change without notice. The most

up-to-date telephone list for the Customer Support Center is always available at:

http://www.lenovo.com/support/phone

If the telephone number for your country or region is not listed, contact your Lenovo

reseller or Lenovo marketing representative.

* Excludes some components. 90-day limited warranty for power adapters, keyboards,

plastics and hinges.

Type of warranty service

1. Customer Replaceable Unit (“CRU”) Service

2. On-site Service

3. Courier or Depot Service

4. Customer Carry-In Service

5. Mail-in Service

6. Customer Two-Way Mail-in Service

7. Product Exchange Service

For a full explanation of the types of warranty service, refer to the full warranty. See

“Lenovo Limited Warranty notice” for details on accessing the full warranty.

Country or region Warranty period

Guatemala, Costa Rica, Venezuela, Peru,

Uruguay, Ecuador, Colombia, Chile, Argentina,

El Salvador

1,4

Type of warranty

service

Parts and Labor - 1 year

Battery Pack/Earphone

- 1 year

United States of America, Canada, Mexico 1,5

Panama 2,4

Brazil 2,5

Parts and Labor - 1 year

Battery Pack/Earphone

- 1 year

Parts and Labor - 1 year

Battery Pack/Earphone

- 1 year

Parts and Labor - 1 year

Battery Pack/Earphone

- 1 year

Warranty information

Lenovo Limited Warranty notice

This product is covered by the terms of the LLW, version L505-0010-02 08/2011. You

can read the LLW at http://www.lenovo.com/warranty/llw_02. You can read the LLW in

a number of languages from this Web site. If you cannot view the LLW from the Web

site, contact your local Lenovo ofﬁce or reseller to obtain a printed version of the LLW.

Warranty period and type of warranty service

Energy efﬁciency mark

Environmental, recycling, and disposal information

General recycling statement

Lenovo encourages owners of information technology (IT) equipment to responsibly

recycle their equipment when it is no longer needed. Lenovo offers a variety of

programs and services to assist equipment owners in recycling their IT products. For

information on recycling Lenovo products, go to http://www.lenovo.com/recycling.

Important battery and WEEE information

Additional recycling statements

Additional information about recycling device components and batteries is in your User

Guide. See “Accessing your User Guide” for details.

Battery recycling marks

Batteries and electrical and electronic equipment marked with the symbol of a

crossed-out wheeled bin may not be disposed as unsorted municipal waste.

Batteries and waste of electrical and electronic equipment (WEEE) shall be

treated separately using the collection framework available to customers for

the return, recycling, and treatment of batteries and WEEE. When possible,

remove and isolate batteries from WEEE prior to placing WEEE in the waste

collection stream. Batteries are to be collected separately using the

framework available for the return, recycling, and treatment of batteries and

accumulators.

Country-speciﬁc information is available at:

http://www.lenovo.com/recycling

Restriction of Hazardous Substances Directive (RoHS)

The latest environmental information about our products is available at

http://www.lenovo.com/ecodeclaration.

European Union

This Lenovo product,with included parts (cables, cords, and so on) meets the

requirements of Directive 2011/65/EU on the restriction of the use of certain hazardous

substances in electrical and electronic equipment (“RoHS recast” or “RoHS 2”).

For more information about Lenovo worldwide compliance on RoHS, go to:

http://www.lenovo.com/social_responsibility/us/en/RoHS_Communication.pdf
