Lenovo 3000 C315 Manuale utente
Version 1.0 2010.01
User Guide
C310/C315 Series
31041659
Important Safety Information
Before using this manual, it is important that you read and understand all of the
related safety information for this product. Refer to the Safety and Warranty Guide
that you received with this product for the latest safety information. Reading and
understanding this safety information reduces the risk of personal injury or damage
to your product.
Danger: Be aware of extremely hazardous or lethal situations.
Attention: Be aware of possible damage to programs, devices, or data.
Note: Pay attention to this important information.
© Copyright Lenovo 2010.
1
Contents
Contents
Important Safety Information
Chapter 1 Using the Computer Hardware.............................. 1
1.1 Front view................................................................................2
1.2 Left and right view of the computer .........................................3
1.3 Rear view of the computer.......................................................4
1.4 Computer stand .....................................................................5
1.5 Connecting your computer ......................................................6
1.6 Important information about using the computer ...................10
1.7 Keyboard and Mouse (wired) .................................................12
1.8 Using the Remote Control. ....................................................13
Chapter 2 Lenovo Touch Control Software Operating
Instructions............................................................ 17
2.1 Startup and Configuration......................................................18
2.2 Lenovo Touch screen User Gesture Instructions ....................24
2.3 Precautions when using Lenovo Touch..................................32
Chapter 3 Using the Rescue System .................................... 35
3.1 OneKey Recovery..................................................................36
3.2 Driver and Application Installation ..........................................36
3.3 System Setup........................................................................37
3.4 System Backup .....................................................................38
3.5 System Recovery ..................................................................38
3.6 Create Recovery Disc ............................................................38
Chapter 4 Using the Computer Software ............................. 39
4.1 Power2Go — Burning Discs .................................................40
4.2 McAfee Security Center.........................................................41
2Contents
Chapter 5 System Maintenance and Recovery.................... 43
5.1 Restoring the System ............................................................44
5.2 Backup and Restore..............................................................44
5.3 Cleaning Up the Disk .............................................................44
5.4 Checking For, and Correcting Disk Errors ..............................45
5.5 Defragmenting the Disk(s)......................................................45
5.6 Performing Daily Maintenance Tasks......................................45
Chapter 6 Troubleshooting and Confirming Setup.............. 47
6.1 Troubleshooting Display Problems .........................................48
6.2 Troubleshooting Audio Problems ...........................................49
6.3 Troubleshooting Software Problems.......................................49
6.4 Troubleshooting Problems with Optical Drives and
Hard Disks.............................................................................50
6.5 Special considerations for troubleshooting Windows .............51
1
2
3
4
5
6
Chapter
This chapter contains the following
topics:
Computer hardware introduction
Information on computer connections
Note: The descriptions in this chapter might
vary from your computer, depending on
computer models and configurations.
User Guide 1
Using the Computer Hardware
2User Guide
1.1 Front view
LCD On/Off
Brightness up
Volume up
Brightness down
Volume down
Power button
3
User Guide
1.2 Left and right view of the computer
Attention: Be sure not to block any air vents on the computer. Blocked
air vents may cause thermal problems.
1 2 3
Memory card reader Optical drive slot
USB ports (2)
4User Guide
1.3 Rear view of the computer
1
2
3
4
5
6
7
8
Power connector USB ports (Some models have
4 USB ports)
TV tuner (Select models only) IEEE 1394 connector
PS/2 keyboard connector Headphone connector
Ethernet connector Microphone connector
5
User Guide
1.4 Computer stand
40° max.
12° min.
Use the stand to position the display to your preference. It can be rotated
between12º and 40º from the vertical.
The stand provides stability to the computer; it is not a removable part.
Attention:
1. The computer stand must remain installed at all times to ensure
maximum system stability.
2. Make sure the angle of the computer is at least 12 degrees from the
vertical; otherwise the computer will be unstable and could fall over.
To open the computer stand, do the following:
