Lenovo ThinkSystem DE Series Manuale utente
ThinkSystem DE Series
Installing DE6400 and DE6600
Machine Types: DE6400 (7DB6) and DE6600 (7DB7)
First edition (December 2022)
© Copyright Lenovo 2022.
L M TED AND RESTR CTED R GHTS NOT CE: f data or software is delivered pursuant to a General Services
Administration (GSA) contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No.
GS-35F-05925
Contents
1. Install and set up DE6400 and DE6600 storage systems 1
2. Install and set up DE6400 and DE6600 storage systems 2
2.1. Install process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê2
2.2. Prepare for installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê4
2.3. Install the hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê6
2.4. Power the controller shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê9
2.5. Complete storage system setup and configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê10
2.5.1. Step 1: Cable the data hosts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê10
Option 1: Direct-attach topology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê10
Option 2: Fabric topology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê11
2.5.2. Step 2: Connect and configure the management connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê11
Option 1: DHCP server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê11
Option 2: Static IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê12
2.5.3. Step 3: Configure storage system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê14
3. Appendix 15
3.1. General Practice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê15
3.2. Contacting support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê15
3.3. Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê15
3.4. Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ê16
Chapter 1. Install and set up DE6400 and DE6600 storage
systems
Learn how to install and set up the DE6400 or DE6600 storage system.
You can choose one of the following formats to guide you through installing and setting up your
new storage system.
•PDF
This is a PDF poster of step-by-step instructions with live links to additional content.
•Online instructions
These are the online setup instructions described on this site. Start with Prepare for installation
to get started.
1
Chapter 2. Install and set up DE6400 and DE6600 storage
systems
2.1. Install process
Before you install and set up your new storage system, familiarize yourself with
the installation process:
2
Direct-attach
or
Fabric?
Complete
system setup and
configuration
Direct-attach
topology
Fabrictopology
Management
Port Configuration
with Static IPAddress
Management port
configuration with DHCP
Connect and configure
the management
connection
After installing the
hardware
Prepare for installation
Receive, unpack, and
inventory equipment
Contact customer
supportto receive
missing items
Do I have
everything I
ordered?
No
Yes
Install hardware
Cable the data hosts
based onyour
network type
Power the
controller shelves
Complete storage
system setup and
configuration
3
2.2. Prepare for installation
Learn how to prepare for installation of your DE6400 or DE6600 series storage
system.
Before you begin
If you are cabling your DE6400 and DE6600 for SAS expansion, review the following information:
•Add SAS expansion cards for SAS expansion card installation.
•Cabling overview for SAS expansion cabling.
Steps
1. Create an account and register your hardware at Lenovo Data Center Support.
2. Ensure that the following items are in the box that you received.
Shelf with drives installed (end caps packaged
separately)
Rack-mount hardware
The following table identifies the types of cables you might receive. If you receive a cable not
listed in the table, see Lenovo Press to locate the cable and identify its use.
Connector type Cable type Use
RJ-45 Ethernet cables (if
ordered)
Management connection
4
Connector type Cable type Use
I/O cables (if ordered) Cabling the data hosts
Power cables (if ordered) Powering up the storage
system
3. Ensure that you provide the following items.
Phillips #2 screwdriver
Flashlight
ESD strap
5
2U rack space: A standard 19 in. (48.30 cm)
rack to fit 2U shelves of the following
dimensions.
Depth: 19.0 in. (48.3 cm)
Width: 17.6 in. (44.7 cm)
Height: 3.34 in. (8.48 cm)
Shelf: 24-drive
Max Weight: 60.5 lb (27.4 kg)
Using third-party cabinets
might cause the power
cables to restrict access to
the controller.
A supported browser for the management
software:
•Google Chrome (version 78 and later)
•Microsoft Internet Explorer (version 11 and
later)
•Microsoft Edge (88 and later)
•Mozilla Firefox (version 70 and later)
•Safari (version 12 and later)
2.3. Install the hardware
You can install a DE6400 or DE6600 storage system in a two-post rack or a
Lenovo system cabinet.
Before you begin
Before you install a DE6400 or DE6600 storage system, make sure you do the following:
•Register your hardware at Lenovo Data Center Support.
•Prepare a flat, static-free work area.
•Take anti-static precautions.
Steps
6
1. Unpack the hardware.
a. Unpack the contents and inventory the contained hardware against the packing slip.
b. Before proceeding, read through all the instructions.
2. Install the rails.
To prevent the equipment from toppling over, install the hardware from the
bottom of the rack or cabinet up to the top.
If instructions were included with your rack-mounting hardware, refer to them to learn how to
install the rails. For additional rack-mounting instructions, see Rack-mount hardware.
3. Install the shelf.
a. If you are installing multiple shelves, begin installing from the bottom to the top of the
cabinet. Position the back of the shelf onto the rails.
When installing the shelf, use a team-lift with two people.
b. Supporting the shelf from the bottom, slide it into the cabinet.
7
