MPX G2

Software Version 1.1

Installation Instructions & Release Notes

SAFETY SUMMARY

The following general safety precautions must be observed during all phases of operation, service, and repair of this unit. Failure to comply with

these precautions or with specific warnings elsewhere in these instructions violates safety standards of design manufacture and

intended use of this unit. Lexicon, Inc. assumes no liability for failure to comply with these requirements.

GROUND THE INSTRUMENT

To minimize shock hazard, the unit chassis and cabinet must be

connected to an electrical ground. The unit is equipped with a three-

conductor AC power cable. The power cable must be either plugged

into an approved three-contact electrical outlet or used with a three-

contact to two-contact adapter with the grounding wire (green) firmly

connected to an electrical ground (safety ground) at the power outlet.

The power jack and mating plug of the power cable meet International

Electrotechnical Commission (IEC) safety standards.

DO NOT OPERATE IN AN EXPLOSIVE ATMOSPHERE

Do not operate the unit in the presence of flammable gasses or

fumes. Operation of any electrical instrument in such an environment

constitutes a definite safety hazard.

KEEP AWAY FROM LIVE CIRCUITS

Operating personnel must not remove unit covers. Component

replacement and internal adjustments must be made by qualified

maintenance personnel. Do not replace components with power cable

connected. Under certain conditions, dangerous voltages may exist

even with the power cable removed. To avoid injuries, always

disconnect power and discharge circuits before touching them.

DO NOT SERVICE OR ADJUST ALONE

Do not attempt internal service or adjustment unless another person

capable of rendering first aid resuscitation is present.

DO NOT SUBSTITUTE PARTS OR MODIFY INSTRUMENT

Because of the danger of introducing additional hazards, do not install

substitute parts or perform any unauthorized modification to the unit.

Dangerous voltages capable of causing death are

present in this instrument. Use extreme caution

when handling, testing, or adjusting.

WARNING

These service instructions are intended for use by

qualified personnel only. Do not perform any

servicing other than that contained in these

instructions unless qualified to do so. Refer to the

Safety Summary on page 2 prior to performing

any service.

WARNING

ELECTROSTATIC DISCHARGE

(ESD) PRECAUTIONS

The following practices minimize possible damage to ROMs resulting from

electrostatic discharge or improper insertion.

• Keep parts in original containers until ready for use.

• Avoid having plastic, vinyl, or Styrofoam in the work area.

• Wear an anti-static wrist strap.

• Discharge personal static before handling devices.

• Remove and insert boards with care.

• When removing boards, handle only by non-conductive surfaces and

never touch open-edge connectors except at a static-free workstation.*

• Minimize handling of ROMs.

• Handle each ROM by its body.

• Do not slide ROMs or boards over any surface.

• Insert ROMs with the proper orientation, and watch for bent pins on ROMs.

• Use anti-static containers for handling and transport.

* To make a plastic-laminated workbench anti-static, wash with a solution of

Lux liquid detergent, and allow to dry without rinsing.

CAUTION

DANGEROUS PROCEDURE WARNINGS

Warnings such as the examples below precede potentially dangerous

procedures throughout this document. Instructions contained in the

warnings must be followed.

DOCUMENTATION CONVENTIONS

This document contains software installation instructions and release notes for MPX G2 Software Version

1.1. Refer to the MPX G2 User Guide for general safety, installation, and operating instructions.

The following symbols are used in this document:

Calls attention to a procedure, practice, condition or the like that, if not correctly

performed or adhered to, could result in injury or death.

Calls attention to a procedure, practice, condition or the like that, if not correctly

performed or adhered to, could result in damage or destruction to part or all of the

product.

Note: Calls attention to information that is essential to highlight.

This document should not be construed as a commitment on the part of Lexicon, Inc. The information it contains is subject to

change without notice. Lexicon, Inc. assumes no responsibility for errors that may appear within this document.

Lexicon, Inc.

3 Oak Park

Bedford, MA 01730-1441 USA

Tel 781-280-0300

Fax 781-280-0490

www.lexicon.com

Customer Support

Tel 781-280-0300

Fax 781-280-0495 (Sales)

Fax 781-280-0499 (Service)

Lexicon Part No. 070-15031 | Rev 0 | 10/02

CAUTION

WARNING

Software Version 1.1 Installation Instructions & Release Notes

MPX G2

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Preserving User Bank Programs & System Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Installation Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Step One: Open the MPX G2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Step Two: Install the ROM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Release Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

New Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

New & Improved Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Comp (S) • RingMod

New Parameter Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Mix • Note (Test Tone) • Time (Delay)

Advanced Editor Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Advanced Editor Mode Controls

DSP Step Count . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Meters Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Errata Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Software Version 1.1 Installation Instructions & Release Notes Lexicon

CONTENTS

This upgrade kit includes one of each of the following:

• MPX G2 Software Version 1.1 ROM

• Extractor tool

• Anti-static wrist strap

• MPX G2 Software Version 1.1 Installation Instructions &

Release Notes (this document)

This kit does not include a Phillips Head screwdriver,

which is needed to remove the two screws on the rear

panel and the three screws on each side of the unit.

These screws are Lexicon Part Number 640-10498.

PRESERVING USER BANK PROGRAMS &

SYSTEM SETTINGS

User Bank programs will be preserved during the

software installation process. But, to avoid accidental

initialization of User Bank programs and other system

settings, it is recommended to dump system information

to an external MIDI storage device before installing the

new software. To do this, refer to the instructions that

begin at the top of the next column.

System select: 

Audio

If desired, follow the instructions that begin below to

perform MIDI dumps of system information and User

Bank programs:

1. Connect a 5-pin MIDI cable from the MPX G2 to an

external MIDI storage device. This cable should be

connected from the MIDI OUT connector on the

MPX G2 to the MIDI IN connector on the external

MIDI device.

2. Press the front panel System button to enable

System Mode. The front panel display will appear as

shown in the figure below.

3. Rotate the front panel selection knob two clicks to

the right, until the MIDI option is selected as shown

in the figure at the top of the next page. The

selection knob is located to the right of the Effect

buttons.

4. Press the front panel > Yes 11 button times, until the

MIDI Dump option is selected as shown in the figure

below. The front panel Store button LED will flash to

indicate that the MPX G2 is armed to transmit a

MIDI dump.

Software Version 1.1 Installation Instructions & Release Notes

MPX G2

5. Rotate the front panel selection knob to the right

until the All Programs option is selected as shown in

the figure below.

System select: 

MIDI

MIDI Dump

Current Pgm

MIDI Dump

All Programs

Sending SysEx

bulk data . . .

6. Press the front panel Store button to send this dump

to the designated external MIDI storage device.

When the dump is in progress, the front panel

display will appear as shown in the figure below.

7. When the All Programs dump is complete, repeat

steps 4, 5, and 6 until all of the following MIDI dump

options have been executed: Map 1, Map 2, Map 3,

Chain 1, Chain 2, Chain 3, Chain 4, Chain 5, Chain

6, Chain 7, Chain 8, Chain 9, Chain 10, Setup 1,

Setup 2, Setup 3, Setup 4, and Setup 5.

8. Follow the instructions that begin on the next page

to install Software Version 1.1.

. . . Preserving User Bank Programs & System Settings continues on page 8

Software Version 1.1 Installation Instructions & Release Notes Lexicon

Preserving User Bank Programs & System

Settings (continued from page 7)

9. When the new software is installed, refer to the

external MIDI storage device documentation to send

the MIDI dumps back to the MPX G2. This will

restore User Bank programs and system settings.

INSTALLATION INSTRUCTIONS

Performing this upgrade is a simple process. But, to avoid

problems, please follow these instructions carefully. Pay

particular attention to precautions that appear in this

document, including the Safety Summary that begins on

page 2. Any damage caused during installation is not

covered under warranty.

STEP 1: OPEN THE MPX G2

1. Using a Phillips head screwdriver, remove the two

rear panel screws identified in the figure at the top of

the next column.

2. Using a Phillips head screwdriver, remove the three

screws on each side of the unit (for a total of six

screws). These screws are identified in the figures

below.

Turn off and disconnect all power to the MPX G2

prior to installing the new software.

WARNING

FOOT

PEDAL

LEFT

RIGHT

(MONO)

REMOTE/IN

MIDI

THRU OUT

FOOT

SWITCH

INSERT RETURNS

MPX G2

LEXICON, INC.

MADE IN U.S.A.

100-240V~

50-60 Hz, 25W

SERIAL NO.

REMOTE

POWER IN

LEFT

RIGHT

MAIN OUTPUTS

LEVEL

(FROM PREAMP)

10 0

INSERT SEND

(TO PREAMP) (TO POWER AMP/CONSOLE)

GUITAR

INPUT

PHONES

Rear Panel Front Panel

Front Panel Rear Panel

3. Remove the top cover by gently sliding it straight

back, away from the front panel as shown in the

figure at the top of the next page.

Software Version 1.1 Installation Instructions & Release Notes

MPX G2

POWER SUPPLY

ROM

PIN 1

ROM U93

4. Before proceeding to Step 2: Install the ROM:

A. Put on the anti-static wrist strap.

B. Attach the copper tape to the MPX G2 chassis.

STEP 2: INSTALL THE ROM

1. Refer to the figure below to locate the ROM on the

MPX G2 main board (location U93).

2. Examine the ROM provided in the upgrade kit.

Because the manufacturing process leaves the pins

angled out slightly from the ROM body, the pins

must be straightened before insertion.

To straighten the pins:

A. Place the ROM on its side on a static-free, flat

surface. See page 3 for instructions to create a

static-free workstation.

B. Hold the body of the ROM. Gently exerting

pressure downward, roll the ROM back and forth

to force both rows of pins into a position parallel

to the workstation. This is demonstrated in the

figure below.

. . . Step Two: Install the ROM continues on page 10

Software Version 1.1 Installation Instructions & Release Notes Lexicon

Step 2: Install the ROM (continued from page 9)

3. Using the ROM extractor tool as shown in the figure

below, remove the ROM from location U93.

ROMs inserted backwards might be destroyed.

Incorrect insertion of ROMs might also cause

damage to the board. Make sure the notch on the

ROM aligns with the notch on the ROM socket.

Damage caused during installation is not covered

under warranty.

CAUTION

ROM

PIN 1

NOTCH

4. Insert the Software Version 1.1 ROM in place of the

old ROM. Be careful not to bend the pins. The notch

on the ROM (shown in the figure below) should

align with the notch on the ROM socket. When the

ROM is inserted, inspect the pins to make sure none

have been bent.

RELEASE NOTES

Software Version 1.1 includes the new enhancements

described in this section.

• The Time parameter in the Delay (S), Delay (D), Echo

(S), and Echo (D) effects can now be set above 5,000

milliseconds without creating ping pong effects.

• When working with MIDI Pgm Maps, different

Program Change messages can now be assigned to

the same program.

• Program Change messages with values greater than

100 will no longer activate the "Sort programs by

number" feature when sent to the unit. Rather, these

messages will select the corresponding MIDI Pgm Map.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Lexicon Hardware per computer

Lexicon

Lexicon MPX 200 - REV 1 Manuale utente

Lexicon

Lexicon MPX 1 - MIDI IMPLEMENTATION DETAILS Manuale utente

Lexicon

Lexicon NUVERB - FOR MACINTOSH Manuale utente

Lexicon

Lexicon MPX 100 Manuale utente

Lexicon

Lexicon VORTEX Manuale utente

Lexicon

Lexicon VORTEX - MANUAL 2 Manuale utente

Lexicon

Lexicon CP-3 PLUS - THEORY AND DESIGN REV 2 Manuale

Lexicon

Lexicon PCM 96 - V1.1.3 Manuale utente

Lexicon

Lexicon MPX 500 Manuale utente

Lexicon

Lexicon PCM 96 - V2.1.6 Manuale utente

Lexicon

Lexicon CP-3 Manuale utente

Lexicon

Lexicon MPX 200 - REV 2 Manuale utente

Lexicon

Lexicon MPX 550 Manuale utente

Lexicon

Lexicon MPX 500 Manuale di istruzioni

Lexicon

Lexicon 700t Guida per l'amministratore

Lexicon

Lexicon PCM 80 Manuale utente

Lexicon

Lexicon MV-5 Manuale utente

Lexicon

Lexicon MPX 500 Manuale utente

Lexicon

Lexicon MV-5 Manuale utente

Lexicon

Lexicon CP-3 PLUS - THEORY AND DESIGN REV 2 Manuale utente

Lexicon

Lexicon 480L - UPDATE V3.0 Manuale utente

Lexicon

Lexicon PCM 42 Manuale utente

Lexicon

Lexicon CP-1 PLUS V2.0 Manuale utente

Lexicon

Lexicon MPX 110 - REV 1 Manuale utente

Manuali Hardware per computer popolari di altre marche

EMC2

EMC2 VNX Series Manuale del proprietario

Panasonic

Panasonic DV0PM20105 Manuale utente

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuale utente

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuale utente

Raidon

Raidon iT2300 Manuale utente

National Instruments

National Instruments PXI-8186 Manuale utente

Hauppauge

Hauppauge WinTV-HVR-2250 Manuale utente

Kontron

Kontron CP6002 Manuale utente

Manhattan

Manhattan 702843 Manuale utente

Aphex

Aphex 230 Manuale utente

AMD

AMD Phenom II Manuale operativo

Intel

Intel NUC 12 Pro Manuale utente

dbx

dbx Zone Pro 1260 Manuale utente

Galaxy

Galaxy GHDX2-2430S-24F4D Manuale utente

Intel

Intel AXXRMFBU4 Manuale utente

Kontron

Kontron DIMM-PC/MD Manuale utente

ST X-NUCLEO-SAFEA1B Istruzioni operative

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuale utente
