Lexmark X9350 Manuale di istruzioni

Wireless USB Wired

START HERE

If you answer “yes”

to any of these

questions, turn to the

section indicated

for Setup and

Connection

instructions.

Do you want to connect the printer to a

wireless network?

Use the Wireless Setup and Connection.

Do you want to connect the printer

directly to the computer?

Use the USB Setup and Connection.

Do you want to connect the printer to a

wired ethernet network?

Use the Wired Setup and Connection.

Wireless

Find the following wireless network

settings. See your wireless documentation,

or contact the person who set up your

wireless network.

•The name of your wireless network

(SSID)

•The type of security you use to protect

your wireless network

•The password for your wireless

network

Before you start 1You need the following items to

complete Wireless Setup:

2Temporarily move the printer

near the computer.

Wireless Setup and Connection

3Load paper.

Installation CD

Wireless Configuration Cable

Telephone cord

Print cartridges

Power cord

Wireless

1Press or to select the

language.

2Press to locate the Country

setting.

3Press or to select the

country or region.

4Press to scroll to Set Date

and Time, and then press .

4Prepare the printer.

1Use the keypad to enter the time, and

use or to scroll between hours

and minutes.

2Press or to scroll to AM, PM, or

24Hr, and use or to change

the setting.

3Press or to scroll to Current

Date.

4Use the keypad to enter the date, and

use or to scroll between day,

month, and year.

5Press to save the settings.

5Adjust the settings.

Wireless

6Insert the print cartridges.

The printer automatically aligns

the print cartridges and prints an

alignment page. This may take a

few minutes.

7Make sure the computer is on, and then insert the

CD.

Wireless

Important! If prompted,

click Cancel on any New

Hardware screens.

91Select Network

Installation.

2Click Next.

3Read and accept the

license agreement.

Network Installation

Click Setup Wireless.

12 Temporarily connect the Wireless

Network Configuration cable to the

printer and to your computer.

Select your

network, and then

click Next.

Click Next.

Wireless

16 If prompted, enter the

password or security

key(s) for your wireless

network.

20 When configuration is

complete, disconnect the

Wireless Network

Configuration cable, and

then click Next.

Note: If you do not know this information,

see the wireless network documentation or

contact the person who set up your

wireless network.

Note: If you do not know this information,

see the wireless network documentation or

contact the person who set up your

wireless network.

If prompted, select the

type of security you use

to protect your wireless

network, and then click

Next.

19 Choose the printer

connection, and then click

Next.

17 Verify the network

settings are correct,

and then click Next.

Next >

18 Click Next.

Wireless

If this is the only

computer on the

wireless network,

setup is

complete.

To print from other

computers on the

network, complete

steps 25–31, and

repeat until all

computers are

networked.

Make sure the next

computer is on, and then

insert the CD.

2524

To use the fax

feature, move the

printer near a

telephone wall jack,

and connect the

telephone cord to

both the printer and

the wall jack.

23 Follow the instructions

on the screen to

complete installation.

Click Next.

2221 Assign a name to the

computer, select an

optional PIN for security,

and then click Next.

Wireless

29 Assign a name to the

computer, select an

optional PIN for security,

and then click Next.

Follow the

instructions on the

screen to complete

installation.

3130 Click Next.

1Select Network

Installation.

2Click Next.

3Read and accept the

license agreement.

26 Click Next.

Network Installation

Click Next.

Wireless

etup trou

oot

For additional Setup troubleshooting information, see the Troubleshooting

chapter of the User’s Guide.

etwor

ng trou

oot

For additional Networking troubleshooting information, see the

Networking chapter of the User’s Guide.

Incorrect language

appears on the display.

1Press to turn the printer off.

2Press once, and then immediately press and hold

and .

3Release the buttons.

4Press or repeatedly until the language you

want appears on the display.

5Press or repeatedly until the option for

Country is highlighted.

6Press or repeatedly until the country or region

you want appears on the display.

7Press or repeatedly until Set Date and Time

is highlighted.

8Press .

9Set the date and time. For more information, see step

5 in the Setup documentation.

Software does not

install.

1Turn off and then restart the computer.

2Click Cancel on all New Hardware screens.

3Insert the CD, and then follow the instructions on the

computer screen to install the software.

If the Install screen does not appear:

1Insert the CD.

2Click Start ÆRun.

3Type D:\Setup, where D is the letter of the CD-ROM

drive.

4Click OK.

Power button is not lit. 1Disconnect the power cord from the wall outlet and

then from the printer.

2Plug the cord all the way into the power supply on the

printer.

3Plug the cord into an electrical outlet that other

electrical devices have been using.

4If the light is not on, press .

Printer is unable to join

the network or printer is

configured correctly, but

cannot be found on the

network.

Make sure the printer settings match those used by the

wireless network.

Make sure the printer is within range of the wireless

network.

If your network uses MAC address filtering, provide the

MAC address for the printer to your network. For more

information, see the User’s Guide.

Network name does not

appear on the list of

available networks.

Select I want to enter a different configuration , and

then click Next.

If the network still does not appear:

1Select I want to enter a different configuration, and

then click Next.

2Enter the network name (SSID).

3Select the appropriate channel for the network.

4Select the mode for your network. Select

Infrastructure if you are using a wireless router.

5Click Next.

6Select the type of security you use to protect your

wireless network, and then click Next.

7If you have security, enter the password or network

key(s).

8Verify the settings are correct, and then click Next.

Network printer does not

print.

Make sure all cables to the printer and electrical outlet

are secure.

Make sure the network is operating properly.

Restart the computer.

Uninstall and then reinstall the software. For more

information, see the User’s Guide.

USB

1 2 Move the printer near the

computer.

USB Setup and Connection

3Load paper.

Installation CD

USB cable

(purchased separately)

Telephone cord

You need the following items to

complete USB Setup:

Print cartridges

Power cord
