Lexmark C792 Family Manuale

Menu map

Menus list

Supplies Paper Menu Reports Settings

Cyan Cartridge

Magenta Cartridge

Yellow Cartridge

Black Cartridge

Waste Toner Bottle

Fuser

Transfer Module

Staples

Hole Punch Box

Default Source

Paper Size/Type

Configure MP

Substitute Size

Paper Texture

Paper Weight

Paper Loading

Custom Types

Custom Names

Custom Bin Names

Universal Setup

Bin Setup

Menu Settings Page

Device Statistics

Network Setup Page

Network [x] Setup Page

Profiles List

Print Fonts

Print Directory

Asset Report

General Settings

Flash Drive Menu

Print Settings

Setup Menu

Finishing Menu

Quality Menu

Job Accounting Menu

Utilities Menu

XPS Menu

PDF Menu

PostScript Menu

PCL Emul Menu

HTML Menu

Image Menu

Security Network/Ports Help

Miscellaneous Security Settings

Confidential Print

Disk Wiping

Security Audit Log

Set Date and Time

Active NIC

Standard Network or Network [x]*

Standard USB

Parallel [x]

Serial [x]

SMTP Setup

Print All Guides

Color Quality

Print Quality

Printing Guide

Media Guide

Print Defects Guide

Menu Map

Information Guide

Connection Guide

Moving Guide

Supplies Guide

*Depending on the printer setup, this menu appears as Standard Network, Network [x], or Wireless Network.

Menu map

Page 1 of 2

Understanding the printer control panel

123

Item Description

1Display Shows the status of the printer

2Home Lets you navigate back to the home screen

3Keypad Allows you to enter numbers, letters, or symbols on the printer

4Sleep Enables Sleep Mode or Hibernate Mode

The following are the statuses of the indicator light and the Sleep button:

•Entering or waking from Sleep Mode—The indicator light is illuminated solid green, Sleep button is

unilluminated.

•Operating in Sleep Mode—The indicator light is illuminated solid green, Sleep button is illuminated solid

amber.

•Entering or waking from Hibernate Mode—The indicator light is illuminated solid green, Sleep button is

illuminated blinking amber.

•Operating in Hibernate Mode—The indicator light is unilluminated, Sleep button is blinking amber for 1/10

of a second, then go completely unilluminated for 1.9 seconds in pulsing pattern.

The following actions wake the printer from Sleep Mode:

•Touching the screen or any hard button presses.

•Opening an input tray, cover, or door.

•Sending a print job from the computer.

•Performing a Power On Reset (POR) with the main power switch.

5Indicator light Off—The printer is off.

Blinking green—The printer is warming up, processing data, or printing.

Solid green—The printer is on, but idle.

Solid red—Operator intervention is needed.

6Stop/Cancel Stops all printer activity

Note: A list of options is displayed once Stopped appears on the display.

7USB port Allows you to connect a USB Bluetooth adapter, or a flash drive to the printer

Note: Only the front USB port supports flash drives.

Menu map

Page 2 of 2
