Lexmark CS410 series Guida di riferimento rapido

Media guide

The printer supports the following paper and other specialty media sizes.

Supported paper sizes

Note: Your printer model may have a 650‑sheet duo tray, which consists of a 550‑sheet tray and an integrated 100‑sheet

multipurpose feeder. The 550‑sheet tray of the 650‑sheet duo tray supports the same paper sizes as the optional 550‑sheet

tray. The integrated multipurpose feeder supports different paper sizes, types, and weights.

Paper size and dimension Standard

250‑sheet tray

Manual

feeder

650‑sheet duo tray 550‑sheet

tray

Duplex

mode

550‑sheet tray Multipurpose

feeder

210 x 297 mm

(8.3 x 11.7 in.)

1 1 1 1

148 x 210 mm

(5.83 x 8.3 in.)

1 2 1 2 X

105 x 148 mm (4.1 x 5.8 in.)

X X 1XX

JIS B5

182 x 257 mm

(7.2 x 10.1 in.)

1 1 1 1 X

Letter

216 x 279 mm (8.5 x 11 in.)

1 1 1 1

Legal

216 x 356 mm (8.5 x 14 in.)

1 1 1 1

Executive

184 x 267 mm

(7.3 x 10.5 in.)

1 1 1 1 X

Oficio (Mexico)

216 x 340 mm

(8.5 x 13.4 in.)

1 1 1 1

Folio

216 x 330 mm (8.5 x 13 in.)

1 1 1 1

1The paper source supports paper size without size sensing.

2Universal is only supported in the standard 250and optional 550sheet tray if the paper size is from 148 x 215.9 mm (5.83 x 8.5 inches)

to 215.9 x 355.6 mm (8.5 x 14 inches).

3Universal is only supported in the multipurpose feeder and manual feeder if the paper size is from 76.2 x 127 mm (3 x 5 inches) to

215.9 x 359.9 mm (8.5 x 14.17 inches).

4Universal is only supported in duplex mode if the width is between 210 mm (8.27 inches) and 215.9 mm (8.5 inches) and length is

between 279.4 mm (11 inches) and 355.6 mm (14 inches).

Media guide

Page 1 of 4

Paper size and dimension Standard

250‑sheet tray

Manual

feeder

650‑sheet duo tray 550‑sheet

tray

Duplex

mode

550‑sheet tray Multipurpose

feeder

Statement

140 x 216 mm (5.5 x 8.5 in.)

X X 1XX

Universal

76 x 127 mm (3 x 5 in.) to

216 x 356 mm (8.5 x 14 in.)

X1,3 X1,3 XX

Universal

148 x 210 mm (5.8 x 8.3 in)

to 216 x 356 mm (8.5 x 14

in).

1,2 1,2 1,2 4

7 3/4 Envelope (Monarch)

98 x 191 mm (3.9 x 7.5 in.)

X X 1XX

9 Envelope

98 x 225 mm (3.9 x 8.9 in.)

XX1XX

10 Envelope

105 x 241 mm (4.1 x 9.5 in.)

XX1XX

DL Envelope

110 x 220 mm (4.3 x 8.7 in.)

XX1XX

C5 Envelope

162 x 229 mm (6.4 x 9 in.)

XX1XX

B5 Envelope

176 x 250 mm (6.9 x 9.8 in.)

XX1XX

Other Envelope

98 x 162 mm (3.9 x 6.3 in.)

up to 176 x 250 mm

(6.9 x 9.8 in.)

XX1XX

1The paper source supports paper size without size sensing.

2Universal is only supported in the standard 250and optional 550sheet tray if the paper size is from 148 x 215.9 mm (5.83 x 8.5 inches)

to 215.9 x 355.6 mm (8.5 x 14 inches).

3Universal is only supported in the multipurpose feeder and manual feeder if the paper size is from 76.2 x 127 mm (3 x 5 inches) to

215.9 x 359.9 mm (8.5 x 14.17 inches).

4Universal is only supported in duplex mode if the width is between 210 mm (8.27 inches) and 215.9 mm (8.5 inches) and length is

between 279.4 mm (11 inches) and 355.6 mm (14 inches).

Storing paper

Use these paper storage guidelines to help avoid jams and uneven print quality:

•For best results, store paper where the temperature is 21°C (70°F) and the relative humidity is 40 percent. Most label

manufacturers recommend printing in a temperature range of 18–24°C (65–75°F) with relative humidity between 40 and 60

percent.

•Store paper in cartons, on a pallet or shelf, rather than on the floor.

Media guide

Page 2 of 4

•Store individual packages on a flat surface.

•Do not store anything on top of individual paper packages.

•Take paper out of the carton or wrapper only when you are ready to load it in the printer. The carton and wrapper help keep

the paper clean, dry, and flat.

Avoiding jams

Load paper properly

•Make sure paper lies flat in the tray.

Correct loading of paper Incorrect loading of paper

•Do not remove a tray while the printer is printing.

•Do not load a tray while the printer is printing. Load it before printing, or wait for a prompt to load it.

•Do not load too much paper. Make sure the stack height is below the maximum paper fill indicator.

Media guide

Page 3 of 4

•Do not slide the paper into the tray. Load paper as shown in the illustration.

•Make sure the guides in the tray or the multipurpose feeder are properly positioned and are not pressing tightly against the

paper or envelopes.

•Push the tray firmly into the printer after loading paper.

Use recommended paper

•Use only recommended paper or specialty media.

•Do not load wrinkled, creased, damp, bent, or curled paper.

•Flex and straighten paper before loading it.

•Do not use paper that has been cut or trimmed by hand.

•Do not mix paper sizes, weights, or types in the same tray.

•Make sure the paper size and type are set correctly on the computer or printer control panel.

•Store paper per manufacturer recommendations.

Media guide

Page 4 of 4
