Lexmark CS410 series Manuale utente

Print quality guide

If the solutions here do not correct the problem, then contact customer support.

Characters have jagged or uneven edges

Action Yes No

Step 1

aPrint a font sample list to check if the fonts you are using are supported by

the printer.

1From the printer control panel, navigate to any of the following:

•> Reports > Print Fonts

•Settings > Reports > Print Fonts

2Select PCL Fonts or PostScript Fonts.

bResend the print job.

Are you using fonts that are supported by the printer?

Go to step 2. Select a font that is

supported by the printer.

Step 2

Check if the fonts installed on the computer are supported by the printer.

Are the fonts installed on the computer supported by the printer?

The problem is solved. Contact customer

support.

Clipped pages or images

Leading edge

Trailing edge

ABCDE

Print quality guide

Page 1 of 18

Action Yes No

Step 1

aMove the width and length guides in the tray to the correct positions for the

paper loaded.

bResend the print job.

Is the page or image clipped?

Go to step 2. The problem is solved.

Step 2

From the printer control panel, set the paper size and type in the Paper menu

to match the paper loaded in the tray.

Does the paper size match the paper loaded in the tray?

Go to step 3. Do one or more of the

following:

•From the printer

control panel, change

the paper size to

match the paper

loaded in the tray.

•From the printer

control panel, change

the paper type to

match the paper

loaded in the tray.

Step 3

aDepending on your operating system, specify the paper size from Printing

Preferences or from the Print dialog.

bResend the print job.

Is the page or image clipped?

Go to step 4. The problem is solved.

Step 4

aRemove, and then reinstall the imaging kit.

Warning—Potential Damage: Do not expose the imaging kit to direct light

for more than 10 minutes. Extended exposure to light may cause print

quality problems.

Warning—Potential Damage: Do not touch the underside of the imaging

kit. This could damage the imaging kit.

bResend the print job.

Is the page or image clipped?

Contact customer

support.

The problem is solved.

Gray background on prints

ABCDE

Leading edge

Trailing edge

Print quality guide

Page 2 of 18

Action Yes No

Step 1

Reduce the toner darkness.

aFrom the Quality menu on the printer control panel, reduce the toner

density.

Note: 4 is the factory default setting.

bResend the print job.

Did the gray background disappear?

The problem is solved. Go to step 2.

Step 2

aRemove, and then reinstall the imaging kit.

Warning—Potential Damage: Do not expose the imaging kit to direct light

for more than 10 minutes. Extended exposure to light may cause print

quality problems.

Warning—Potential Damage: Do not touch the underside of the imaging

kit. This could damage the imaging kit.

bResend the print job.

Did the gray background disappear?

The problem is solved. Contact customer

support.

Horizontal voids appear on prints

Leading edge

Trailing edge

Action Yes No

Step 1

aMake sure your software program is using a correct fill pattern.

bResend the print job.

Do horizontal voids appear on prints?

Go to step 2. The problem is solved.

Step 2

aLoad the specified tray or feeder with a recommended type of paper.

bResend the print job.

Do horizontal voids appear on prints?

Go to step 3. The problem is solved.

Print quality guide

Page 3 of 18

Action Yes No

Step 3

aRemove, and then reinstall the imaging kit.

Warning—Potential Damage: Do not expose the imaging kit to direct light

for more than 10 minutes. Extended exposure to light may cause print

quality problems.

Warning—Potential Damage: Do not touch the underside of the imaging

kit. This could damage the imaging kit.

bResend the print job.

Do horizontal voids appear on prints?

Go to step 4. The problem is solved.

Step 4

Replace the imaging kit, and then resend the print job.

Do horizontal voids appear on prints?

Contact customer

support.

The problem is solved.

Incorrect margins on prints

ABCD

Action Yes No

Step 1

aMove the width and length guides in the tray to the correct positions for the

paper size loaded.

bResend the print job.

Are the margins correct?

The problem is solved. Go to step 2.

Step 2

From the printer control panel, set the paper size in the Paper menu to match

the paper loaded in the tray.

Does the paper size match the paper loaded in the tray?

Go to step 3. Do one or more of the

following:

•Specify the paper size

from the tray settings

to match the paper

loaded in the tray.

•Change the paper

loaded in the tray to

match the paper size

specified in the tray

settings.

Print quality guide

Page 4 of 18

Action Yes No

Step 3

aDepending on your operating system, specify the paper size from Printing

Preferences or from the Print dialog.

bResend the print job.

Are the margins correct?

The problem is solved. Contact customer

support.

Paper curl

Action Yes No

Step 1

Move the width and length guides in the tray to the correct positions for the

size of the paper loaded.

Are the width and length guides positioned correctly?

Go to step 2. Adjust the width and

length guides.

Step 2

From the printer control panel, set the paper type and weight in the Paper menu

to match the paper loaded in the tray.

Do the paper type and weight match the type and weight of the paper in the

tray?

Go to step 3. Specify the paper type

and weight from the tray

settings to match the

paper loaded in the tray.

Step 3

aDepending on your operating system, specify the paper type and weight

from Printing Preferences or from the Print dialog.

bResend the print job.

Is the paper still curled?

Go to step 4. The problem is solved.

Step 4

aRemove the paper from the tray, and then turn it over.

bResend the print job.

Is the paper still curled?

Go to step 5. The problem is solved.

Step 5

aLoad paper from a fresh package.

Note: Paper absorbs moisture due to high humidity. Store paper in its

original wrapper until you use it.

bResend the print job.

Is the paper still curled?

Contact customer

support.

The problem is solved.

Print quality guide

Page 5 of 18

Print irregularities

) )

ABCDE

Leading edge

Trailing edge

Action Yes No

Step 1

aMove the width and length guides in the tray to the correct positions for the

size of the paper loaded in the tray.

bResend the print job.

Do print irregularities still appear?

Go to step 2. The problem is solved.

Step 2

From the printer control panel, set the paper size and type in the Paper menu

to match the paper loaded in the tray.

Is the tray set to the size and type of the paper loaded in the tray?

Go to step 3. Do one or more of the

following:

•Specify the paper size

from the tray settings

to match the paper

loaded in the tray.

•Change the paper

loaded in the tray to

match the paper size

specified in the tray

settings.

Step 3

aDepending on your operating system, specify the paper type and weight

from Printing Preferences or from the Print dialog.

bResend the print job.

Do print irregularities still appear?

Go to step 4. The problem is solved.

Step 4

Check if the paper loaded in the tray has texture or rough finishes.

Are you printing on textured or rough paper?

From the printer control

panel, set the paper

texture in the Paper

menu to match the paper

loaded in the tray.

Go to step 5.

Step 5

aLoad paper from a fresh package.

Note: Paper absorbs moisture due to high humidity. Store paper in its

original wrapper until you use it.

bResend the print job.

Do print irregularities still appear?

Go to step 6. The problem is solved.

Print quality guide

Page 6 of 18

Action Yes No

Step 6

Replace the imaging kit, and then resend the print job.

Do print irregularities still appear?

Contact customer

support.

The problem is solved.

Print is too dark

Action Yes No

Step 1

aFrom the Quality menu on the printer control panel, select Color Adjust.

bResend the print job.

Is the print still too dark?

Go to step 2. The problem is solved.

Step 2

aFrom the Quality menu on the printer control panel, reduce the toner

darkness.

Note: 4 is the factory default setting.

bResend the print job.

Is the print still too dark?

Go to step 3. The problem is solved.

Step 3

aFrom the printer control panel, set the paper type, texture, and weight in

the Paper menu to match the paper loaded in the tray.

bResend the print job.

Is the tray set to the type, texture, and weight of the paper loaded?

Go to step 4. Change the paper loaded

in the tray to match the

paper type, texture, and

weight specified in the

tray settings.

Step 4

aDepending on your operating system, specify the paper type, texture and

weight from Printing Preferences or from the Print dialog.

bResend the print job.

Is the print still too dark?

Go to step 5. The problem is solved.

Print quality guide

Page 7 of 18

Action Yes No

Step 5

Check if the paper loaded in the tray has texture or rough finishes.

Are you printing on textured or rough paper?

From the printer control

panel, set the paper

texture in the Paper

menu to match the paper

loaded on the tray.

Go to step 6.

Step 6

aLoad paper from a fresh package.

Note: Paper absorbs moisture due to high humidity. Store paper in its

original wrapper until you use it.

bResend the print job.

Is the print still too dark?

Go to step 7. The problem is solved.

Step 7

Replace the imaging kit, and then resend the print job.

Is the print still too dark?

Contact customer

support.

The problem is solved.

Print is too light

Action Yes No

Step 1

aFrom the Quality menu on the printer control panel, select Color Adjust.

bResend the print job.

Is the print still too light?

Go to step 2. The problem is solved.

Step 2

aFrom the Quality menu on the printer control panel, increase the toner

darkness.

Note: 4 is the factory default setting.

bResend the print job.

Is the print still too light?

Go to step 3. The problem is solved.

Print quality guide

Page 8 of 18

Action Yes No

Step 3

From the printer control panel, set the paper type, texture, and weight in the

Paper menu to match the paper loaded in the tray.

Is the tray set to the type, texture, and weight of the paper loaded?

Go to step 4. Specify the paper type,

texture, and weight from

the tray settings to match

the paper loaded in the

tray.

Step 4

aDepending on your operating system, specify the paper type, texture, and

weight from Printing Preferences or from the Print dialog.

bResend the print job.

Is the print still too light?

Go to step 5. The problem is solved.

Step 5

Make sure that the paper has no texture or rough finishes.

Are you printing on textured or rough paper?

From the printer control

panel, set the paper

texture in the Paper

menu to match the paper

loaded in the tray

Go to step 5.

Step 6

aLoad paper from a fresh package.

Note: Paper absorbs moisture due to high humidity. Store paper in its

original wrapper until you use it.

bResend the print job.

Is the print still too light?

Go to step 7. The problem is solved.

Step 7

Replace the imaging kit, and then resend the print job.

Is the print still too light?

Contact customer

support.

The problem is solved.

Printer is printing blank pages

Print quality guide

Page 9 of 18

Action Yes No

Step 1

aCheck if there is packing material left on the imaging kit.

1Remove the imaging kit.

2Check if the packing material is properly removed from the imaging kit.

Warning—Potential Damage: Do not expose the imaging kit to direct

light for more than 10 minutes. Extended exposure to light may cause

print quality problems.

Warning—Potential Damage: Do not touch the underside of the

imaging kit. This could damage the imaging kit.

3Reinstall the imaging kit.

bResend the print job.

Is the printer still printing blank pages?

Go to step 2. The problem is solved.

Step 2

Replace the imaging kit, and then resend the print job.

Is the printer still printing blank pages?

Contact customer

support.

The problem is solved.

Printer is printing solid black pages

Action Yes No

Step 1

aRemove, and then reinstall the imaging kit.

Warning—Potential Damage: Do not expose the imaging kit to direct light

for more than 10 minutes. Extended exposure to light may cause print

quality problems.

Warning—Potential Damage: Do not touch the underside of the imaging

kit. This could damage the imaging kit.

bResend the print job.

Is the printer printing solid black pages?

Go to step 2. The problem is solved.

Step 2

Replace the imaging kit, and then resend the print job.

Is the printer printing solid black pages?

Contact customer

support.

The problem is solved.

Print quality guide

Page 10 of 18

Altri manuali per CS410 series

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Lexmark Stampante

Lexmark

Lexmark Optra S 2455 Manuale utente

Lexmark

Lexmark E360dtn Manuale

Lexmark

Lexmark MX711 Series Manuale

Lexmark

Lexmark T 430 Manuale utente

Lexmark

Lexmark 4079 - Plus Color Jetprinter Inkjet Printer Manuale utente

Lexmark

Lexmark Optra M410 Manuale utente

Lexmark

Lexmark T630 - Printer - B/w Istruzioni per il montaggio

Lexmark

Lexmark C748 Guida alla configurazione

Lexmark

Lexmark 3200 - MFP - Option Manuale utente

Lexmark

Lexmark CS310 Series Manuale utente

Lexmark

Lexmark E260 Series Manuale utente

Lexmark

Lexmark MS810de Manuale tecnico

Lexmark

Lexmark C746 Manuale

Lexmark

Lexmark CS410 series Manuale utente

Lexmark

Lexmark 772dn - C Color Laser Printer Manuale

Lexmark

Lexmark X790 series Manuale utente

Lexmark

Lexmark MX6500e 6500e Manuale utente

Lexmark

Lexmark X748dte Manuale utente

Lexmark

Lexmark 23S0300 Manuale del proprietario

Lexmark

Lexmark 6500E Manuale del prodotto

Lexmark

Lexmark E350d Istruzioni operative e di sicurezza

Lexmark

Lexmark MS810 Series Manuale utente

Lexmark

Lexmark Optra E 4026-0XX Manuale utente

Lexmark

Lexmark C935 Series Manuale utente

Manuali Stampante popolari di altre marche

Canon

Canon i70 Series Manuale utente

Evolis

Evolis Elypso Manuale utente

Kyocera

Kyocera FS-9530DN Manuale utente

Canon

Canon LASER SHOT LBP-1210 Manuale utente

Samsung

Samsung BIXOLON SRP-350plusF Manuale utente

Canon

Canon PIXMA PRO-1 Series Manuale utente

Canon

Canon PIXMA G3560 Guida all'installazione

Dell

Dell Color Laser Printer 2130cn Manuale utente

Tektronix

Tektronix Phaser 840 Manuale utente

Epson

Epson ET-7750 Istruzioni operative

Canon

Canon CLBR 460ps Manuale utente

Eltron

Eltron P210 Guide Manuale utente

Ricoh

Ricoh MD-P1 Manuale utente

Epson

Epson SC-F7100 series Manuale utente

Epson

Epson Stylus C40UX Manuale utente

Canon

Canon imagePASS-A2 Manuale utente

Canon

Canon S820D Manuale utente

IRA3D

IRA3D POETRY4 Manuale utente
