Lexmark MS810 Series Manuale utente

Supplies Guide

When Cartridge low appears, you may need to order a new toner cartridge. You may be able to print a limited number of

pages when the message first appears, but it is best to have the new cartridge available when the current one runs out.

Ordering toner cartridges

Notes:

•Estimated cartridge yield is based on the ISO/IEC 19752 standard.

•Extremely low print coverage for extended periods of time may negatively affect actual yield.

Item Return Program cartridge

For the United States and Canada

Toner Cartridge 521

High Yield Toner Cartridge 521H

Extra High Yield Toner Cartridge 521X*

For the European Union, European Economic Area , and Switzerland

Toner Cartridge 522

High Yield Toner Cartridge 522H

Extra High Yield Toner Cartridge 522X*

For the Asia Pacific Region (includes Australia and New Zealand)

Toner Cartridge 523

High Yield Toner Cartridge 523H

Extra High Yield Toner Cartridge 523X*

For Latin America (includes Puerto Rico and Mexico)

Toner Cartridge 524

High Yield Toner Cartridge 524H

Extra High Yield Toner Cartridge 524X*

For Africa, Middle East, Central Eastern Europe, and Commonwealth of Independent States

Toner Cartridge 525

High Yield Toner Cartridge 525H

Extra High Yield Toner Cartridge 525X*

* This toner cartridge is supported only in MS811n, MS811dn, MS812dn, and MS812ne printer models.

For more information on countries located in each region, visit www.lexmark.com/regions.

Supplies Guide

Page 1 of 3

Item Regular cartridge

Worldwide

High Yield Toner Cartridge 520HA1

Extra High Yield Toner Cartridge 520XA2

1This cartridge is supported only in MS810n and MS810dn printer models.

2This cartridge is supported only in MS811n, MS811dn, MS812dn, and MS812ne printer models.

Ordering an imaging unit

Extremely low print coverage for extended periods of time may cause imaging unit parts to fail prior to exhaustion of toner.

For more information on replacing the imaging unit, see the instruction sheet that came with the supply.

Part name Lexmark Return Program Regular

Imaging unit 520Z 520ZA

Ordering a maintenance kit

To identify the supported fuser type, view the label on the fuser. Do either of the following:

•Remove the toner cartridge and imaging unit. The two-digit fuser type code (such as 00 or 01) can be seen on the front of

the fuser.

Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes. Extended

exposure to light may cause print quality problems.

•Pull down the printer rear door. The two-digit fuser type code (such as 00 or 01) can be seen on the rear of the fuser.

Notes:

•Using certain types of paper may require more frequent replacement of the maintenance kit.

•The separator roller, fuser, pick rollers, and transfer roller are all included in the maintenance kit and can be individually

ordered and replaced if necessary.

•For more information on replacing the maintenance kit, see the instruction sheet that came with the supply.

Lexmark Return Program fuser maintenance kits and part numbers for MS810, MS811, and MS812

Fuser maintenance kit type Part number

Type 00 40X8420

Type 01 40X8421

Type 02 40X8422

Type 03 40X8423

Type 04 40X8424

Supplies Guide

Page 2 of 3

Lexmark regular fuser maintenance kits and part numbers for MS810, MS811, and MS812

Fuser maintenance kit type Part number

Type 05 40X8425

Type 06 40X8426

Type 07 40X8427

Type 08 40X8428

Type 09 40X8429

Ordering a roller kit

For more information on replacing the roller kit, see the instruction sheet that came with the part.

Lexmark roller kit and part number

Type Part number

Printer engine roller maintenance kit 40X7706

Ordering staple cartridges

Part name Part number

Staple cartridges 25A0013

Supplies Guide

Page 3 of 3
