Menus

Use the LocalTalk Menu to change printer settings affecting jobs sent to the printer through a

LocalTalk port.

Select a menu item for more details:

Note: Values marked by an asterisk are the factory default settings.

• Job Buffering • LocalTalk Zone

• LocalTalk Addr • NPA Hosts

• LocalTalk Buffer • NPA Mode

• LocalTalk Name • PCL SmartSwitch

• LocalTalk Port • PS SmartSwitch

LocalTalk Menu

Paper handling

Maintenance

Troubleshooting

Administration

Index

Printing

www.lexmark.com

Lexmark T522

AB C D E F G H I J K L M N O P Q R S T U V W X Y Z

Menus

Job Buffering

Purpose:

To temporarily store jobs on the printer hard disk before printing.

Values:

Note: Changing the Job Buffering menu item automatically resets the printer.

Off* Does not buffer the print job to the hard disk.

On Buffers print jobs to the hard disk.

Auto Buffers print jobs only if the printer is busy processing data from another input port.

LocalTalk Menu

Paper handling

Maintenance

Troubleshooting

Administration

Index

Printing

www.lexmark.com

Lexmark T522

AB C D E F G H I J K L M N O P Q R S T U V W X Y Z

Menus

LocalTalk Addr

Purpose:

To identify the LocalTalk Node number assigned to the printer. This menu item cannot be

modified through the operator panel.

LocalTalk Menu

Paper handling

Maintenance

Troubleshooting

Administration

Index

Printing

www.lexmark.com

Lexmark T522

AB C D E F G H I J K L M N O P Q R S T U V W X Y Z

Menus

LocalTalk Buffer

Purpose:

To configure the size of the LocalTalk input buffer.

Values:

Note: Changing the LocalTalk Buffer menu item automatically resets the printer.

Disabled Disables the LocalTalk port.

Auto* Printer automatically calculates LocalTalk Buffer size (recommended).

6K to maximum

size allowed User specifies the LocalTalk Buffer size. The maximum size depends

on the amount of memory in your printer, the size of the other link

buffers, and whether Resource Save is set to On or Off. To maximize

the range for the LocalTalk Buffer size, disable or reduce the size of

the parallel, serial, network, infrared, and USB buffers.

LocalTalk Menu

Paper handling

Maintenance

Troubleshooting

Administration

Index

Printing

www.lexmark.com

Lexmark T522

AB C D E F G H I J K L M N O P Q R S T U V W X Y Z

Menus

See also:

Resource Save

LocalTalk Menu

Paper handling

Maintenance

Troubleshooting

Administration

Index

Printing

www.lexmark.com

Lexmark T522

AB C D E F G H I J K L M N O P Q R S T U V W X Y Z

Menus

LocalTalk Name

Purpose:

To identify the printer model name stored in printer memory. This menu item cannot be

modified through the operator panel.

LocalTalk Menu

Paper handling

Maintenance

Troubleshooting

Administration

Index

Printing

www.lexmark.com

Lexmark T522

AB C D E F G H I J K L M N O P Q R S T U V W X Y Z

Menus

LocalTalk Port

Purpose:

To activate the LocalTalk port.

Values:

Disabled* Disables the LocalTalk port and all other menu items in the

LocalTalk Menu.

LTalk Option <x> Activates the specified LocalTalk port.

LocalTalk Menu

Paper handling

Maintenance

Troubleshooting

Administration

Index

Printing

www.lexmark.com

Lexmark T522

AB C D E F G H I J K L M N O P Q R S T U V W X Y Z

Menus

LocalTalk Zone

Purpose:

To identify the LocalTalk Zone provided by the LocalTalk network. This menu item cannot be

modified through the operator panel.

LocalTalk Menu

Paper handling

Maintenance

Troubleshooting

Administration

Index

Printing

www.lexmark.com

Lexmark T522

AB C D E F G H I J K L M N O P Q R S T U V W X Y Z

Menus

NPA Hosts

Purpose:

To specify the maximum number of NPA hosts that can register for NPA alerts.

Values:

Note: Changing this menu item automatically resets the printer.

1...10 (2*)

LocalTalk Menu

Paper handling

Maintenance

Troubleshooting

Administration

Index

Printing

www.lexmark.com

Lexmark T522

AB C D E F G H I J K L M N O P Q R S T U V W X Y Z

Menus

NPA Mode

Purpose:

To specify whether the printer performs the special processing required for bidirectional

communication, following the conventions defined in the Network Printing Alliance (NPA)

Protocol.

Values:

Note: Changing this menu item automatically resets the printer.

On Printer performs NPA processing. If data is not in NPA format, it is rejected as

bad data.

Off Printer does not perform NPA processing.

Auto* Printer examines the data to determine the format and then processes it

appropriately.
