Lexmark S600 Manuale utente

1Unpack printer

Notes:

•Place the printer near the computer

during setup. If you're setting up on

a wireless network, then you may

move the printer after setup is

complete.

•Do not attach the USB cable until

prompted to do so.

•The packaged printhead is shipped

inside the printer.

•Contents may vary by model and

region.

2Remove tape and packing material from all areas of the

printer

Lexmark S600 Series Installation

3Raise paper support

4Raise printer control panel

5Open printer and remove packaged printhead

Lexmark S600 Series Installation

6Close printer

7Use lever to extend paper guides

8Load paper

Notes:

•Use the lever to adjust the paper

guides.

•Do not load more than 100 sheets in

the paper tray.

Lexmark S600 Series Installation

9Extend paper exit tray

10 Connect power cord only

Note: DO NOT attach the USB cable yet.

CAUTION—POTENTIALINJURY: Read the safety information included with this product before connecting

power or making any cabling connections.

11 Make sure printer is on

Lexmark S600 Series Installation

12 Follow prompts on the printer control panel

1Follow the prompts on the printer

control panel.

2After following the prompts, click

Continue below.

13 Install printhead and ink cartridges

If you need to install the printhead and

cartridges, click Continue.

If not, you can close this window.

14 Open printer and remove any tape from latch

Note: The carriage moves to the

printhead installation position as shown.

Lexmark S600 Series Installation

15 Squeeze and lift latch

16 Remove printhead from disposable container

17 Insert printhead and close latch until it clicks

Lexmark S600 Series Installation

18 Close printer

19 Open printer

Note: The printhead moves to the

cartridge installation position as shown.

Lexmark S600 Series Installation

20 First, insert each color ink cartridge. Then, use two hands

to install black cartridge.

21 Close printer

Lexmark S600 Series Installation

22 Touch OK to print alignment page

Notes:

•Do not remove the page until

printing stops. The alignment page

may take a while to print and will

move in and out during the process.

•Streaks on the alignment page are

normal and not an indication of a

problem.

•The alignment page that prints may

differ from the one shown.

•Recycle the alignment page.

Lexmark S600 Series Installation
