Lexmark Z51 Color Jetprinter Manuale utente

Lexmark Z51

Getting Started

Color Jetprinter

Prepare for setup

1Unpack your printer.

2Remove all packing material from the printer.

3IMPORTANT: Before you connect your printer

to your computer, make sure your printer and

computer are powered off and unplugged.

cartridges

User’s Guide

Setup

software

Power

supply

Getting

Started

2Connect the parallel cable

2a... to the printer

1Use a parallel cable that supports bidirectional

communication (IEEE 1284-compatible), such as

Lexmark P/N 1329605.

Note: If you are using Windows 98, you can use a

USB (Universal Serial Bus) cable. For

help, refer to the instructions in your

printed User’s Guide.

2Fasten the metal clips on the printer to the parallel

cable.

2b... to the computer

Make sure you tighten the screws.

3Plug in your printer

3a. Connect both ends of the

power supply

1Connect the power supply to the printer.

2Plug the power supply into an electrical outlet.

3b. Press the Power button

If the Power light is on, continue with step 4.

If not, check your connections.

Power button

Power light

4Install the print cartridges

4a. Raise the front cover

When you raise the front cover, the print cartridge

carrier moves to the loading position.

Color

Black

4b. Unpack the cartridges

1Remove each new print cartridge from its

packaging.

2Remove the sticker and the transparent tape

covering the gold area on the cartridges.

Tape

Sticker

Avoid touching the

gold contact area

4c. Insert the cartridges

4d. Snap the cartridges into

place

1Push back on the cartridges until they snap

securely into place.

If the print cartridges move loosely in the carrier,

they are not locked into place. Make sure the

cartridges snap into place.

2Close the front cover.

SNAP

55a. Prepare for loading

Paper exit

tray

Media support

5b. Place up to 100 sheets of

plain paper in the auto-

matic feeder

Insert the paper against the right side of the

automatic feeder.

5c. Adjust the media guide

Squeeze the release tab and media guide together

and slide the media guide to the edge of the paper.

Release tab

Media guide

6Install the printer

software

Before you install the printer software, make sure you

shut down all running applications.

To install the printer software, follow the steps for

your operating system:

Windows 95, 98, and NT 4.0:

1Make sure your computer is on and Windows is

running.

IMPORTANT: If Windows displays a message

indicating your printer has been found, select

Cancel. If the Update Device Driver Wizard

appears, select Cancel.

2Insert the Lexmark Z51 Color Jetprinter CD

into your CD-ROM drive.

•If the Lexmark Z51 Printer Software menu

screen appears after a few moments, continue

with step 3.

•If nothing appears on the screen after a few

moments, follow these instructions:

aFrom the Start menu, choose Run.

bIn the Open: text box, type the letter of

your CD-ROM drive, followed by :\setup

(for example, d:\setup), then click OK.

3When the Lexmark Z51 Printer Software menu

screen appears, click the Install Printer Software

button.

4Follow the instructions on your screen.

Windows 3.1 and 3.11:

1Make sure your computer is on and Windows is

running.

2Insert the Lexmark Z51 Color Jetprinter CD

into your CD-ROM drive.

3From the Program Manager menu bar, choose

File, then choose Run.

4In the Command-Line: text box, type the letter of

your CD-ROM drive, followed by :\setup (for

example, d:\setup), then click OK.

5When the Lexmark Z51 Printer Software menu

screen appears, click the Install Printer Software

button.

6Follow the instructions on your screen.

OS/2:

1Open an OS/2 Window.

2Insert the Lexmark Z51 Color Jetprinter CD

into your CD-ROM drive.

3From an OS/2 prompt, type the letter of your CD-

ROM drive, followed by :\setupos2 (for example,

d:\setupos2), then press Enter.

4Click Install Drivers and Documentation. Click

OK.

5Follow the instructions on your screen.

Refer to the Lexmark Z51 User’s Guide for

information on how to install the printer software

from diskettes.

Congratulations!

You have successfully set up your printer. Refer to

your Lexmark Z51 User’s Guide (or CD-ROM if

you are using Windows NT 4.0 or OS/2) for

information about:

•How to use the buttons and lights

•How to print on plain paper and other media

•Quick Fixes for printer problems

•Caring for your printer

Lexmark Customer Support

Center

Lexmark Customer Support Center

1-800-Lexmark

539-6275

Outside the USA, see the printer registration card for the

number appropriate for your country.

Hours of Operation:

9 AM-9 PM Monday through Friday

12 PM-6PM Saturday and Sunday (Eastern Time).

Or you may contact Lexmark at:

http://www.lexmark.com

Please have the following information available so we may

serve you faster. (Located on the back of the printer)

Machine Type number _______________________

Serial number ______________________________

Date purchased _____________________________

Store where purchased_______________________

(USA and Canada)
