LG 3828JS8034M Manuale utente
P/NO.3828JS8034M
FRIDGE-FREEZER
User's Guide
Please read this User's Guide carefully
before operating and keep it handy for
reference at all times.
3
Introduction
Installation
Operation
Suggestion on
food storage
Care and
maintenance
Trouble shooting
To Reverse the
Doors
Table of Contents
Important safety Instruction
Disposal of the old appliance &
packing of new appliance
Identification of Parts
Location
Electrical Connection
Starting
Storing food
Making Ice
Defrosting
Cleaning
General Information
Tips for saving Energy
Trouble shooting
How to Reverse the Door
Door handle
4
6
7
8
9
9
10
10
12
13
14
17
18
15
11
The appliance is suitable for storing the frozen goods.
It is restricted for household use. If it is used for industrial or
commercial purpose, observe the related regulations firmly. If
using other purpose or misuse, the manufacturer is not
responsible for the damages of occasion.
Ignoring the recommendations for environmental use will
make your appliance consume higher energy.
Introduction
Precaution
Important Safety Instruction
This fridge-freezer must be properly installed and
located in accordance with the Installation
Instruction before it is used.
Never unplug your fridge-freezer by pulling on the
power cord. Always grip plug firmly and pull straight
out from the outlet.
When moving your appliance away from the wall,
be careful not to roll over or damage the power
cord.
After your fridge-freezer is in operation, do not
touch the cold surfaces in the freezer compartment,
particularly when hands are damp or wet. Skin may
adhere to these extremely cold surfaces.
Pull out the power plug prior to cleaning the fridge-
freezer.
Never damage, severely bend, pull out, or twist the
power cord because power cord damage may cause a
fire or electronic shock. Never place glass products in the
freezer because they may be broken when their inner
contents are frozen.
Don't use an
extension cord If possible, connect the fridge-freezer to its own
individual electrical outlet to prevent it and other
appliances or household lights from causing an overload.
4
5
Introduction
wwDanger
Important Safety Instruction
Risk of child entrapment.
Before you throw away your old refrigerator or freezer:
Take off the doors.
Leave the shelves in place so that children may not easily
climb inside.
wwWarning wKeep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
wDo not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
wDo not damage the refrigerant circuit.
wDo not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the
type recommended by the manufacturer.
wThe refrigerant and insulation blowing gas used in the
appliance require special disposal procedures.
At disposal, please consult with service agent or a
similarly qualified person.
Grounding
(Earthing)
In the event of an electric short circuit, grounding (earthing)
reduces the risk of electric shock by providing an escape
wire for the electric current. In order to prevent possible
electric shock, this appliance must be grounded. Improper
use of the grounding plug can result in an electric shock.
Consult a qualified electrician or service person if the
grounding instructions are not completely understood, or if
you have doubts on whether the appliance is properly
grounded.
Accessibility of
Supply Plug
Supply Cord
Replacement
The supply plug of the refrigerator-freezer should be
placed in easy accessible position for quick disconnection
in emergency.
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
Introduction
Disposal of the old
appliance
Disposal of the old appliance &
packing of new appliance
The old appliance whose life has expired should be
destroyed in order to make it safe prior to disposal. Take
out power plugs, separate connection wires and remove
or destroy all springs, latches or bolting, to prevent
children from being trapped during play.
For environmental protection, old refrigerators should be
disposed off by a professional disposition agency. If you
have any question, please consult with the local sale
agency or local authority.
Disposal of
packing of new
appliance
All packing materials used for this appliance are
environment-friendly.
Matters concerning material are as follows:
PE : Polyethylene – Foil or pocket for packing
PS : Formed objects made of foamed
CFC-FREE polystyrene
PP : Strapping tape made of polypropylene
Take back offer This appliance contains fluid (refrigerant, lubricant) and is
made of parts and materials which are reusable and/or
recyclable.
All the important materials should be sent to the
collection center of waste material and can be reused
after rework (recycling). For take back, please contact
with the local agency.
6
NOTE This is a basic model. The shape of refrigerator is
subject to change.
7
Identification of Parts
Installation
Location
This appliance is suitable for using at ambient
temperature between +16°C and +38°C. If the ambient
temperature drops below +16°C, it is possible that the
freezing foods in the freezer compartment are thawed
because the temperature of the freezer gets warm.
To ensure proper air circulation around the fridge -freezer,
please maintain sufficient space on both the sides as well
as top and maintain at least 2 inches (5 cm) from the rear
wall.
8
NOTE Place on a flat and firm flooring. If the floor is not
even, adjust the feet by using the leveling screw
at the front edge of the cabinet.
If the front is slightly higher than the rear, the door
can close more easily.
9
Installation
Electrical connection
This appliance should be connected to the mains AC
220~240V , 50 Hz. You must connect this appliance only
to the power socket with grounding complying with the
related regulations and only an approved expert should
install this appliance.
Starting
Before switching it on, leave the appliance standing for
at least 2 hours, so that the circulation of the refrigerant
stabilizes and no operating problems occur.
Operation
°C
h
When the appliance powers on, the initial state displayed
on LED is "-18°C".
Button K1 (Defrost):
Button K2 (Quick freezing):
Press butoon K2 for the first time, indicator "-", "°C"shut off,
indicator "h" light on and initial freezing time displayed is"3h".
Press button K2 for the second time the freezing time displayed
is "2h". Press button K2 for the third time the freezing time
displayed is "1h". The compressor will ren from 1hour to
3 hours according to the freezing time displayed on LED.
Press button K2 for the fourth time, the indicators will recover
the state before quick freeze.
Button K3 (Temperature regulation):
Press button K3 continuously, the provided temperature
displayed will be from -14°C to -24°C circularly.
Pressbutton K1 forthree seconds the first time, indicator"-", "°C",
"h" shut off, compressor stop running and the value displayed on
LED is"OF". Pressbutton K1 forthree seconds the second time ,
indicator "-", "°C", "h" display normally, compressor running
normally and LED displays the initial state.
10
Suggestion on food storage
Storing food
Opening the door often or keeping the door opened a
long time, increases the inside temperature. This causes
the storage life and flavor of the foods to reduce, and
increases the energy consumption.
Make sure foods that are not frozen do not touch the
frozen foods. The frozen foods may melt.
The packing materials suitable for refrigerating the foods are
- Polyethylene bags, Plastic foil, freezing containers.
The suitable wrapping materials are
- Rubber band, Plastic clips, attaching tape, string.
Before sealing, get rid of air from packing bags and foil.
The remained air makes the storing foods dry.
You can freeze foods quickly when packing is level. Do
not store bottles in freezer compartment. They may
break when frozen.
NOTE Do not touch deep-frozen foods with wet hands.
You could get chilblains on your hands.
Making Ice
To make ice cubes, fill ice
tray 3/4 full with water and
place it on the bottom of the
freezer compartment.
To remove ice cubes, hold the ice tray at its ends and
twist gently.
Tips
To remove ice cubes easily, run water on the tray
before twisting.
