OWNER’S MANUAL

REFRIGERATOR-FREEZER

P/NO : MFL42818307/1 www.lg.com

Please read this manual carefully before operating

your set and retain it for future reference.

GA-B3*9B*QA

GA-B3*9B*CA

GA-B3*9P*QA

GA-B3*9P*CA

GA-F3*9B*QA

GA-B3*9U*QA

GA-B3*9U*CA

GA-B3*9TG**

GA-F4*9B*QA

GA-B4*9B*QA

GA-B4*9P*QA

GA-B4*9U*QA

GA-B4*9U*CA

GA-B4*9TG**

ENGLISH

РУССКИЙ

Примітка

Contents

Refrigerator

Freezer

Function

Super/Express Freezer

Child Lock

To Reverse

the Doors How to Reverse the Door

Vacation

Precaution

Registration

Important Safety Instruction

Identification of Parts

Installation

Starting

Display Panel for Temperature Control

Ice Making

Defrosting

Water Dispenser

Storing Food

Refrigerator work features

Cleaning

General Information

Trouble Shooting

Lamp Replacement

Remove/Install shelf

Disposal of your old appliance

Introduction

Installation

Operation

Care and

Maintenance

Trouble Shooting

Climatic class

Memory feature

Suggestion On

Food storage

The working life of this set is 7 years

since the date of delivery to consumer.

Door Alarm

Table of the technical characteristics

Removing/Installing bottom drawer

Removing/Installing freezer drawers

Introduction

Note

Technical characteristics of the refrigerator can be changed

by the Сompany-manufacturer without prior Notice.

Rating (V~HZ)

Climate сlass

Rated сurrent (A)

Rated input (W)

Defrost input (W)

-of sheath heater (W)

-of lamp, maximal (W)

Gross vol.total ( ℓ), Storage / Gross

-Freezer compartment ( ℓ), Storage / Gross

-Fresh food compartment ( ℓ), Storage / Gross

Refrigerant / Weight (g)

Insulation blowing agent

Dimensions :

-Height (mm), Net / Packing

-Depth (mm), Net / Packing

-Width (mm), Net / Packing

-Weigth (kg), Net / Packing

Freezer class

Cooling system

Efficient, GOST Р51565-2000

Electricity consumption, kW*hr / year

Sound power level, dBA

Table of the technical characteristics of a Refrigerator-Freezer:

Specification

296 / 315

210 / 211

651 / 744 617 / 744

82 / 89

303 / 322

264 / 283

651 / 744

617 / 744

Cyclopentane

86 / 104

230 ~ 50

0.6

100

170

369

352

178 / 179

217 / 218

67 / 74

No Frost

73 / 80

R600a 54g

595 / 655

1726 / 1815

1896 / 1985

Model

GA-B359B*QA

GA-B359B*CA

GA-B379B*QA

GA-B379B*CA

GA-B359P*QA

GA-B359P*СA

GA-B379P*QA

GA-B379P*СA

GA-F399B*QA

GA-F409B*QA

GA-B399B*QA

GA-B399U*QA

GA-B399U*CA

GA-B409B*QA

GA-B409U*QA

GA-B409U*CA

GA-B399P*QA

GA-B409P*QA

GA-B399TG**

GA-B409TG**

GA-B379U*QA

GA-B379U*СA

Introduction

Warning Caution

To avoid any risk of personal injury, material damage

or incorrect use of the appliance, be sure to

observe the following safety precautions.

(After reading these owner’s instructions,

please keep them in a safe place for reference).

Remember to hand them over to any subsequent owner.

Indicates that

a danger of

death or

serious injury

exists.

Indicates that

a risk of personal

injury or material

damage exists.

In a case of defying manual owner regulation,

manufacturer do not carry warranty liability.

The model and serial number are found on the outer side

of this unit. This number is unique to this unit and not

available to others. You should record requested

information here and retain this guide as a permanent

record of your purchase. Staple your receipt here.

Date of Purchase

Dealer Purchased From

Dealer Phone No.

Model No.

Dealer Address

Serial No.

Important Safety Instruction

Registration

Introduction

Warning

Do not change the power cord and do not

change its length.

This fridge-freezer must be properly installed and

located in accordance with the Installation

Instruction before it is used.

Do not disassemble, repair or alter the appliance.

It may cause fire or abnormal operations, which

way lead to injury.

To reduce the risk of fire, electric shock, or injury to

persons when using your product, basic safety

precautions should be followed.

1. When connecting the power

The dedicated outlet should be used.

Using several devices at one outlet

may cause fire.

Do not allow the power cord bent

or pressed by the heavy object

to be damaged.

It causes electric shock or fire by the electric

damage of the power cord or others.

If the supply cord is damaged, it must be replaced

by the service agent or a similarly qualified

person in order to avoid a hazard.

Using several devices at one

outlet may cause fire.

Water may be flown into or the

plug may be damaged, which

causes fire or electric shock.

It may damage the power cord to

cause fire or electric shock.

Introduction

When the power cord or the power plug

is damaged or the holes of the outlet are

loosed, do not use them.

Remove water or dust from the power plug

and insert it with the ends of

the pins securely connected.

Do not pull out the cord or touch

the power plug with wet hands.

It may cause electric shock

or injury.

Dust, water or unstable connection

may fire or electric shock.

Make sure of grounding.

The incorrect grounding may cause

breakdown and electric shock.

It may cause electric shock or short

circuit to make fire.

2. When using the fridge-freezer

Do not place the heavy object or the dangerous

object, flower vase, cup, cosmetics,

medicine or any container with water

on the fridge-freezer.

When opening or closing the door

it may be dropped to cause injury,

fire or electric shock.

Do not cling to the door or the shelves of the door

or the home bar of the freezer or

the cool chamber.

It may make the fridge-freezer fallen

down or damage the hands.

Especially, do not allow the children

to do the above.

Ground

Wire

Copper

Flat

More than

30 inches

(80 сm)

Introduction

Do not install the fridge-freezer in the

wet place or the place which water

or rain splashes.

Deterioration of insulation of electric

parts may cause electric leakage.

Do not use or store inflammable

materials ether, benzene, alcohol,

medicine, LP gas, spray or

cosmetics near orin the

fridge-freezer.

It may cause explosion or fire.

Do not place the lit candle within

the fridge-freezer to deodorize.

It may cause explosion or fire.

Do not store the medicine or the academic

materials at the fridge-freezer.

When the material with the strict

temperature control is stored,

it maybe deteriorated or it may

make anunexpected reaction to

cause anyrisk.

Avoid the heating devices.

It may cause fire.

Do not put any living animal in

the fridge-freezer.

The Academic

Medicine

The Medicine

Benzene

Ether

Thinner

Introduction

Thinner

Use the submerged fridge-freezer

after checking it.

It may cause electric shock or fire.

When gas is leaked, do not touch the fridge-freezer

or the outlet and ventilate the room immediately.

In this fridge-freezer uses natural gas

(isobutene, R600a) as the environment-

friendly refrigerant, even a small its

amount (80~90g) is combustible.

When the gas is leaked by the severe

damage during delivering,installing or

using the fridge-freezer,any spark may

cause fire or burn. For further operation,

contact the service center.

Do not spray water at the outside

or the inside of the fridge-freezer

or do not clean it with benzene

or thinner.

Deterioration of insulation of electric

parts may cause electric shock or fire.

Do not insert the hands into the bottom

of the fridge-freezer.

The iron plate of the bottom may

cause injury.

Carry the fridge-freezer with

the handle bar at the bottom of

the front and the topof the rear.

Otherwise, your hands may be

slipped to cause injury.

Because opening or closing the

door of the fridge-freezer may

cause injury to the person

around it, be careful, please.

Opening or closing the door may

cause feet or hands to be caught in

the chink in door or the child to be

get hurt by the corner.

Introduction

When any strange smell or smoke

is detected from the fridge-freezer,

disconnect the power plug immediately

and contact to the service center.

It may cause fire.

Service center

Do not allow any person except the

qualified engineer to disassemble,

repairor alter the fridge-freezer.

It may cause injury, electric shock

or fire.

Do not use the fridge-freezer for

non-domestic purpose (storing

medicine or testing material,

using at the ship, etc.).

It may cause an unexpected risk such

as fire, electric shock, deterioration of

stored material or chemical reaction.

When disposing the fridge-freezer,

remove the packing materials

from the door, leave the shelves

in place.

It may cause to lock out the child.

Install the fridge-freezer on the solid

and level floor.

Install the fridge-freezer on a plane

surface to prevent it's falling down

and injury or death.

Do not insert the hands or the metal

stick into the exit of coolair, the cover,

the bottom of thefridge-freezer,

the heatproof grill (exhaust hole)

at the backside.

It may cause electric shock or injury.
