Please read this guide thoroughly

before operating and keep it handy

for reference at all times.

REFRIGERATOR

User’s Guide

GC-249SA

GC-269SA

GC-279SA

CONTENT

NAME OF PARTS .......................................................................................2

MOVEMENT & TRANSPORTATION ........................................................3

EARTH CONNECTION ..............................................................................3

INSTALLATION ......................................................................................... 4

SAFETY GUARDS ..................................................................................... 5

HOW TO USE ............................................................................................. 7

BEST WAYS TO STORE FOOD ...............................................................9

WAYS TO DISASSEMBLE SPARE PARTS ..............................................11

INSTALLING LOCATION AND REPLACEMENT OF DOOR

OPENING TYPE (OPTION).......................................................................12

CLEANING THE REFRIGERATOR .........................................................13

DOES THE REFRIGERATOR HAVE A MALFUNCTION .......................14

THIS IS NOT A MALFUNCTION ..............................................................15

APPENDIX ..................................................................................................16

The working life of this set is 7 years since the date of delivery to consumer.

NAME OF PARTS

Note: The ﬁgure is only for reference.

Temperature control

Refrigerator Shelf

(2 or 3 pieces)

Fruit & vegetable

compartment cover

Fruit & vegetable

compartment

Evaporator

Freezing

compartment drawer

(3 or 4 pieces)

Adjustable foot

Bottle rack

Multi-functional

rack(4 or 5 pieces)

Egg tray

MOVEMENT & TRANSPORTATION

●BEFORE TRANSPORTATION

1.Remove all the food from the refrigerator,

secure the spare parts such as the shelves

by adhesive tape.

2.Fasten the adjustable foot to the direction.

Adjustable Foot

Note:Please fasten the adjustable foot to the direction before transportation, otherwise the oor

will be scraped or the foot will be blocked from moving.

●DURING TRANSPORTATION

1. Hold tightly the adjustable foot at the

bottom of the refrigerator and the

upper handle at the back.

2. During transportation, please note

that the refrigerator should not be

tilted.

3. When transporting to a more distant

place, the refrigerator should be

placed vertically on the vehicle.

(Otherwise problem will exist)

EARTH CONNECTION

Note: 1.The earth wire of this electrical appliance has been connected to the power plug ,please do

not change the power plug on your own.

2.Plug your refrigerator into a standard 230-240V household outlet,make sure the socket is

properly earthed.

3.If you receive an electrical shock by touching any part of the refrigerator,you should stop

using the refrigerator immediately and contact the specied maintenance service unit or

the retail shop of this product at once.

POWER CORD REPLACEMENT

If the supply cord is damaged,it must be replaced by a special cord or assembly from the

manufacturer or its service agent.

ACCESSIBLITY OF SUPPLY PLUG

The refrigerator-freezer should be positioned that the supply plug is accessible for quick

disconnection when accident happens.

INSTALLATION

Installing on a firm and flat surface

- Unstable installation is the main reason

of vibration and noise.

- When the refrigerator is installed unstably,

it can be stabilized by adjusting the

adjustable foot.

- Slightly rising the front part of the

refrigerator allow you to close the door

very easily.

- When installed on a carpet or oor,please put

a rm mat under the refrigerator otherwise

the bottom part will change colour.

Keep an appropriate distance between

the wall

- To ensure proper air circulation around the fridge-

freezer, please maintain sufficient space on both

the sides as well As top and maintain at least 2

inches (5 cm) from the rear wall.

- A smaller gap will restrict the operation of the

refrigerator,which may result in an increase in

power.

Installing in a less humid environment

- Do not install the refrigerator in a humid place

or where water can easily be splashed.

- If the refrigerator is installed in a humid

environment,it will go moldy.This will lower

insulation property and cause electricity leakage

Avoid installing near heat and gas

- High temperature will lower the refrigeration

and increase the power consumption.

- Installing near gas or smoke will change the

surface colour of the refrigerator.

Keep distance

Slightly rise

the front part

Adjustable Foot

More than

5cm rear

Humidity

mat

SAFETY GUARDS

● Please use the exclusive power socket.

- If the refrigerator uses the same power socket

as other electrical appliances,the socket could

be overloaded abnormally and re may be

resulted,which may cause a re.

●Please unplug the refrigerator before

changing the light bulb.

- Changing the light bulb as the refrigerator

is operating may cause an electric shock.

● Please note that the back of the

refrigerator should not touch the

power plug.

- The power plug being pressed could be

easily damaged and this may cause re or

electric shock.

●Please do not put heavy things on top

of the refrigerator.

- When you open the door, the heavy things

could easily fall down and hurt you.

● Please unplug the refrigerator first

before cleaning.Do not do this with

wet hands.

- This may probably cause electric shock.

●Please do not climb on the door.

- The refrigerator could be turned over and

hurt small children.

Use a exclusive

power socket

● Please do not store ammable

things like ether,benzene,alcohol

and liqueed gas in the refrigerator.

- Flammable things like ether,benzene,alcohol

and liqueed gas may cause re.

●Please do not store medicine or

academic information in the

refrigerator.

- Things which require strict

temperature control should

not be stored in the refrigerator,

otherwise they will go bad or

produce accidental effect.

ether

benzene

alcohol

● Please keep away from fire.

- Can cause re.

● In case of a gas leak,please do not

touch the refrigerator and the power

socket, you should open the windows

and the door for ventilation.

- As a spark may cause

a explosion and

lead to re.

● Please do not place water container

such as vases,glasses,cosmetic or

medicine on top of the refrigerator.

- Liquid spilt over

the refrigerator

will reduce the

insulation effect,

and may cause

an electric shock

or re.

● Please do not store bottles in the

freezing compartment.

- As bottles in the freezing compartment,

liquid inside will be frozen and the

bottle will break.

● Please do not install in a humid place

or where water can easily be splashed.

- This will reduce the insulation effect and may

cause an electric shock.

● Please unplug the refrigerator if it is

not to be used for a long time.

- Reduced insulation may cause an

electric shock or re.

● During transportation,please hold the

adjustable feet at the bottom of the

refrigerator and the upper handle at

the back.

- Otherwise,the refrigerator may fall down.

● When the refrigerator is

unplugged, please wait for ve

minutes before you plug it again.

- Otherwise the compressor will be

overloaded.

SAFETY GUARDS

after 5 minutes

Initial operation

●Clean the inner part of the refrigerator before using.

●Do not put foods into the refrigerator until it has been plugged in for 3 hours.

Temperature control

●The thermostat used for controlling the temperature inside the refrigerator is located on the

top of the refrigerator.

●The ﬁgure on the thermostat does not stand for a practical value. The smaller the ﬁgure is,

the higher the temperature inside the refrigerator is.

●Temperature control

● Power failure leads to the rising of the freezing compartment's temperature,this may shorten

the storage of foods and decline the quality.

● If the power supply is off for too long,be sure to get rid of any water or ice underside the

drawer of the freezing compartment before reconnection of the power supply, so as to avoid

the foods and the ice freezing together.

Note

Thermostat knob

Lamp cover

Position Function

0 Stop

1-2 Warm

3-4 Normal

5-6 Cold

7 Quick freezing

HOW TO USE

* Power failure

If power failure is known in advance,please

● Turn the thermostat to "7" two hours before power failure.

● Place more ice cubes in the refrigerator compartment.

● Do not place anymore food in the refrigerator.

● Do not open the door more than necessary.

HOW TO USE

Defrost

As the refrigerator operates, the moisture from foods

or in the air may be frosted on to the inner part of the

refrigerator and the surface of evaporator. Too thick

frost will affect the operation of the refrigerator, so

regularly defrosting is necessary. Usually, defrosting

is necessary when the thickness reaches 5 mm.

●Refrigerator compartment

Defrosts automatically, moisture on the inner side runs

into the drip tray through the drain pipe. The heat gene-

rated by compressor evaporates the water automatically.

- keep the drain pipe straight so that water can inpour

into the drip tray. When it's blocked,take out the drain

cover,clean it and then replace it.

Freezing compartment

Before defrosting—turn the thermostat knob to "0",open the door,take out foods and drawers in

the freezing compartment,foods may be put into refrigerator compartment temporarily.

Defrosting—remove the frost on the inner side of the freezing compartment and on the surface

of the evaporator with the ice scraper,then wipe off the water with a dry cloth.

After defrost—turn the thermostat knob to the former position.

Ice making

● Fill the ice tray with water to 4/5 of its

capacity and place it into the freezing

compartment,turn the thermostat knob

to "6".

● Twist the both sides of the ice tray so

as to remove the ice cubes easily.

Drain pipe

Note:

Ice scraper
