LG LBNC10551V Manuale utente

For inquiries or comments, visit www.lg.com or call：

1-800-243-0000 USA, Consumer User

1-888-865-3026 USA, Commercial User

1-888-542-2623 CANADA

www.lg.com

LG Customer Information Center

OWNER'S MANUAL

FRIDGE&

FREEZER

Read this owner's manual thoroughly before operating the appliance and keep

it handy for reference at all times.

EN ENGLISH ES ESPAÑOL

FR FRANÇAIS

MFL62883390

LBNC10551V

LBNC10551W

LBNC12551V

Express

Reversing the Doors(Optional)

General

California Proposition 65 (USA only)

This product contains chemicals known to the State of California to cause cancer and

birth defects or other reproductive harm. Wash hands after handling.

Do not use an extension cord.

DISPOSAL

Junked or abandoned refrigerators are dangerous, even if they are sitting for only a few days.

When disposing of the refrigerator, remove the packing materials from the door or take

off the doors but leave the shelves in place so that children may not easily climb inside.

This appliance is intended to be used in household and similar applications such as staff

kitchen areas

applications.

The parts shown may vary depending on the model.

Note

Door bins

(4 or 6 EA)(2 or 3 EA)

Door bin for 2L bottles

Leveling leg

LED light

Ice tray

Removable glass shelf

Multi-flow

refrigeration system

Fruit and vegetable drawer

Freezer drawers

Internal control panel

(not in all models)

• Choose the suitable place. Locate the

refrigerator in a place convenient for its

use;

• This is a freestanding refrigerator and requires

a minimum of 2 inches (5 cm) clearance

above, behind, and at both sides for adequate

air circulation and to reduce energy

consumption.

• Do not install the refrigerator near heat

sources and in a zone exposed to direct

sunlight or high humidity;

• Make sure that electrical voltage indicated

in the manual meets the parameters of

your mains;

• Do not remove the round stickers on the

rear side of the refrigerator.

They have a decorative function closing

the fabrication holes;

• To exclude vibration, check the refrigerator

installation using a level. If necessary, turn

the adjustable feet to compensate irregularity

of the floor.

To ensure better closing of the door, the

refrigerator should be slightly inclined

backwards. To turn the adjustable feet,

slightly incline the refrigerator.

• Before use, carefully wash the refrigerator;

• Install the removable parts, such as ice tray,

etc. to the appropriate places.

It is necessary to prevent possible damages

during transportation;

• Insert the power cord plug to the power

outlet. Do not power other electric appliance

from the same outlet.

After first installation of the refrigerator, let it

work for 2-3 hours for stabilization of the

operating temperature inside and only then

fill the refrigerator with fresh or frozen

foodstuffs. After disconnection of the

refrigerator from the mains, wait at least 5

minutes to switch on it again. Now, the

refrigerator is ready for service.

CONNECTION

Dimensions and Clearances

•

refrigerator through doors or narrow openings.

•

Assembling the Doors and Drawers in this manual.

•The installation location chosen for the refrigerator should allow space behind the unit for connections and

•Too small of a distance from adjacent items may result in lowered freezing capability and increased electricity

consumption charges. Allow at least 29 4/5 inches (758 mm) in front of the refrigerator to open the doors, and at

least 2 inches (50 mm) between the back of the refrigerator and the wall.

- List LBNC10551V

LBNC10551W

LBNC12551V

A Depth without handle

(643 mm)

B Width (595 mm)

C Height to Top of Case 67 4/5"

( 1722 mm)

D Height to Top of Hinge 68 3/8"

( 1737 mm)

74 1/2"

( 1892 mm)

75 1/8"

( 1907 mm)

E Back Clearance 2"

(50 mm)

(556 mm)

(1158 mm)

(50 mm)

F Depth without Door 21 9/10"

GDepth (Total with Door Open

90°)

45 3/5"

29 4/5"

23 1/2"

25 3/8"

(643 mm)

(595 mm)

23 1/2"

25 3/8"

K Front Clearance (758 mm)

(556 mm)

(1158 mm)

21 9/10"

45 3/5"

29 4/5"

(758 mm)

M Depth with handle (643 mm)

25 3/8"

(643 mm)

CONTROL PANEL

Internal display

Vacation modeQuick freeze Freezer temperature control Refrigerator temperature control

The initial temperature in the refrigerator and freezer compartments is 3 °C(37 °F)

and -20 °C(-4 °F),

respectively.

To change the temperature settings, press the temperature control button for the

appropriate compartment.

TEMPERATURE CONTROL

EXPRESS FREEZE

This function increases both icemaking and freezing capabilities.

Press the button to turn on the Express Freeze function and the indicator light for 24 hours.

After 24 hours, the Express Freeze function and the indicator light turn off. The freezer

returns to the previously set temperature. Press the Express Freeze button at any time

while the function is running to manually turn it off.

The Express Freeze indicator remains lit as long as the function is running.

NOTE: The displayed temperature is the target temperature only. The actual internal

temperature of the refrigerator depends on the amount and type of food

stored inside.

After initial installation, allow the temperature settings to stabilize for at least 2 to 3

days before adjusting them.

Internal LED display
