OWNER’S MANUAL
FRENCH DOOR
REFRIGERATOR
lease read this owner's manual thoroughly before
operating and keep it handy for reference at all times.
LMX30995**
www.lg.com
ENGLISH FRANÇAIS ESPAÑOL
2TABLE OF CONTENTS
ENGLISH
TABLE OF CONTENTS
3 PRODUCT FEATURES
4
IMPORTANT SAFETY
INSTRUCTIONS
7 COMPONENTS
7 Refrigerator Exterior
8 Refrigerator Interior
9 INSTALLATION
9 Installation Overview
10 Specifications
11 Unpacking Your Refrigerator
11 Choosing the Proper Location
11 - Flooring
12 - Ambient Temperature
12 - Measuring the Clearances
12 Removing/Assembling the Refrigerator
Door Handles
13 Removing/Assembling the Freezer
Drawer Handle
13 Removing/Assembling the Doors and
Drawers
14 - Removing the Left Refrigerator Door
15 - Removing the Right Refrigerator Door
16 - Assembling the Right Refrigerator Door
17 - Assembling the Left Refrigerator Door
18 - Removing the Freezer Drawers
21 - Assembling the Freezer Drawers
22 Connecting the Water Line
22 - Before You Begin
22 - Water Pressure
22 - What You Will Need
23 - Water Line Installation Instructions
25 Turning On the Power
26 Leveling and Door Alignment
26 - Leveling
26 - Door Alignment
27 HOW TO USE
27 Before Use
28 Control Panel
28 - Control Panel Features
30 In-Door Ice Bin
30 - Detaching the In-Door Ice Bin
30 - Assembling the In-Door Ice Bin
31 Automatic Icemaker
31
- Turning the Automatic Icemaker On or Off
32 - When You Should Turn the Icemaker Off
32 - Normal Sounds You May Hear
32 - Preparing for Vacation
33 Ice and Water Dispenser
33 - Dispenser
33 - Using the Dispenser
33 - Locking the Dispenser
33 - Cleaning the Dispenser Stand
34 Storing Food
34 - Food Preservation Location
35 - Food Storage Tips
35 - Storing Frozen Food
36 Humidity Controlled Crisper and
Glide’N’Serve
37
Detaching and Assembling the Storage Bins
38
Door-In-Door
40 Adjusting the Refrigerator Shelves
41 MAINTENANCE
41 Cleaning
42 Replacing the Fresh Air Filter
42 Replacing the Water Filter
47 SMART DIAGNOSIS™
47 Using Smart Diagnosis™
48 TROUBLESHOOTING
58 WARRANTY
3
PRODUCT FEATURES
ENGLISH
PRODUCT FEATURES
* Depending on the model, some of the following functions may not be available.
FILTERED WATER AND ICE DISPENSER
The water dispenser dispenses fresh, chilled water.
The ice dispenser dispenses cubed and crushed ice.
DOOR ALARM
The Door Alarm function is designed to prevent refrigerator malfunctioning
that could occur if a refrigerator door or freezer drawer remains open. If a
refrigerator door or freezer drawer is left open for more than 60 seconds, a
warning alarm sounds at 30 second intervals.
HUMIDITY CONTROLLED CRISPER
The Humidity Controlled Crisper is designed to help keep your fruits and
vegetables fresh and crisp. You can control the amount of humidity in the
crisper by adjusting the setting between Low and High.
LIDE‘N’SERVE
Glide‘N’Serve provides storage space with a variable temperature control
that keeps the compartment colder than the refrigerator. It is a convenient
place to store sandwiches or meat to be cooked.
ICE PLUS
Ice production can be increased by approximately 20 percent when the
freezer section is maintained at the coldest temperature for a 24-hour
period.
4IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
This guide contains many important safety messages. Always read and obey all safety messages.
WARNIN You can be killed or seriously injured if you do not follow instructions.
CAUTION
Indicates an imminently hazardous situation which, if not avoided, may result
in minor or moderate injury, or product damage.
WARNIN
To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety
precautions should be followed, including the following:
Power
NEVER unplug your refrigerator by pulling on the power cord. Always grip the plug firmly and pull it
y
straight out from the outlet.
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a
y
similarly qualified person in order to avoid a hazard. Do not use a cord that shows cracks or abrasion
damage along its length or at either the plug or connector end.
Do not use an uncertified power outlet.
y
Unplug the power plug immediately in the event of a blackout or thunderstorm.
y
Plug in the power plug with the power cord facing downward.
y
Installation
Contact an authorized service center before you install or relocate the refrigerator.
y
When moving your refrigerator away from the wall, be careful not to roll over or damage the power
y
cord.
Prior to use, ensure that you are connecting this product to a dedicated, grounded electrical outlet
y
rated for use with this product (115V, 60Hz, AC only). It is the user’s responsibility to replace a
standard 2-prong wall outlet with a standard 3-prong wall outlet.
Do not install the refrigerator where there may be a danger of the unit falling.
y
Use
DO NOT allow children to climb, stand, or hang on the refrigerator doors or on the shelves in the
y
refrigerator. They could damage the refrigerator and seriously injure themselves.
Do not hang on to or place heavy objects on the refrigerator’s dispenser.
y
Do not place heavy or dangerous objects (bottles with liquid) on the refrigerator.
y
Do not put live animals inside the refrigerator.
y
Do not allow children to climb into the product when it is in use.
y
In the event of a gas leak (propane/LPG), ensure adequate ventilation and contact an authorized service
y
center before resuming use. Do not touch or disassemble the electric outlet of the refrigerator.
In the event of a refrigerant leak, move flammable objects away from the refrigerator. Ensure adequate
y
ventilation and contact an authorized service center.
Do not use or place flammable substances (chemicals, medicine, cosmetics, etc) near the refrigerator
y
or store them inside the refrigerator. Do not place the refrigerator in the vicinity of flammable gas.
This is the safety alert symbol. It alerts you to safety messages that inform you of
hazards that can kill or hurt you or others, or cause damage to the product.
All safety messages will be preceded by the safety alert symbol and the hazard
signal word WARNING or CAUTION. These words mean:
5
IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
This product is not to be used for special purposes such as the storage of medicine or test materials
y
or for use on ships, etc.
Unplug the power plug before cleaning or repairing the refrigerator.
y
When you replace the light bulb in the refrigerator, unplug the refrigerator or turn off the power.
y
Do not modify or extend the power cord.
y
Do not use a dryer to dry the interior. Do not light a candle to remove interior odors.
y
For your safety, this appliance must be properly grounded. Have the wall outlet and the circuit
y
checked by a qualified electrician to make sure the outlet is properly grounded.
Do not use an outlet that can be turned off with a switch. Do not use an extension cord. It is the
y
user’s responsibility to replace a standard 2-prong wall outlet with a standard 3-prong wall outlet.
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
y
Do not use an adapter plug and plug the power plug into a multi-outlet extension cord.
y
Disconnect the power cord immediately if you hear a noise, smell a strange odor or detect smoke
y
coming from the appliance.
Turn the power off if water or dust penetrates into the refrigerator. Call a service agent.
y
Do not disassemble or modify the refrigerator.
y
Do not put hands, feet, or metal objects below or behind the refrigerator.
y
Do not operate the refrigerator or touch the power cord with wet hands.
y
In refrigerators with automatic icemakers, avoid contact with the moving parts of the ejector
y
mechanism or with the heating element that releases the cubes. Do not place fingers or hands on the
automatic ice-making mechanism while the refrigerator is plugged in.
When dispensing ice from the dispenser, do not use crystal ceramics.
y
Do not touch the cold surfaces in the freezer compartment with wet or damp hands, when your
y
refrigerator is in operation.
Do not put glass containers, glass bottles or soda in the freezer.
y
This appliance is not intended for use by persons (including children) with reduced physical, sensory
y
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning the use of the appliance by a person responsible for their safety.
Do not refreeze frozen food that has thawed completely. Doing so may result in a serious health
y
issue.
If you are throwing away your old refrigerator, make sure the CFC coolant is removed for proper
y
disposal by a qualified servicer. If you release CFC coolant, you may be fined or imprisoned in
accordance with the relevant environmental law.
Junked or abandoned refrigerators are dangerous, even if they are sitting for only a few days. When
y
disposing the refrigerator, remove the packing materials from the door or take off the doors but leave
the shelves in place so that children may not easily climb inside.
If connected to a circuit protected by fuses, use time delay fuse.
y
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety
precautions should be followed, including the following:
6IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
CAUTION
Installation
The refrigerator must be properly installed in accordance with the Installer Instructions that were
y
taped to the front of the refrigerator.
Be careful when you unpack and install the refrigerator. Immediately dispose of plastic and other
y
packing materials out of reach of children.
The appliance must be positioned for easy access to a power source.
y
Use
Close the door carefully when children are around.
y
Keep fingers out of pinch point areas; clearances between the doors and cabinets are
y
necessarily small. Be careful closing doors when children are nearby.
If you store food improperly, be aware that it may fall and cause injury.
y
Do not use aerosols near the refrigerator.
y
Do not store articles on the top of the appliance.
y
Maintenance
Do not use strong detergents like wax or thinners for cleaning. Clean with a soft cloth.
y
Wipe foreign objects (such as dust and water) off the prongs of the power plug and contact
y
areas regularly.
Do not store, disassemble or repair the refrigerator by yourself.
y
Remove any dust or foreign matter from the power plug pins.
y
Do not use a wet or damp cloth when cleaning the plug.
y
If the refrigerator is disconnected from the power supply, you should wait for at least five
y
minutes before plugging it back in.
If you notice a chemical or burning plastic smell or see smoke, unplug the refrigerator
y
immediately and contact your LG Electronics Service Center.
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety
precautions should be followed, including the following:
SAVE THESE INSTRUCTIONS
7
COMPONENTS
ENGLISH
COMPONENTS
Use this page to become more familiar with the parts and features of your refrigerator.
Page references are included for your convenience.
*The appearance and specifications of the actual product may differ depending on the model.
Refrigerat r Exteri r
Button
Handle
Opens and closes
the door.
Filtered Water and
Ice Dispenser
Dispenses purified water and ice.
LED Display
Displays the refrigerator and
freezer temperature, the water
filter condition and the dispenser
status.
Control Panel
Sets the refrigerator and freezer
temperatures, the water filter
condition and the dispenser mode.
Refrigerator
Preserves food.
Freezer
Preserves frozen food.
Ez Handle
Easily opens the freezer
door.
LED Light
LED lights up when
the freezer door is
opened.
8COMPONENTS
ENGLISH
Refrigerat r Interi r
Door-In-Door Case
The convenience of a “soft cool”
storage area and easy access to
items stored in this area.
Adjustable Refrigerator Shelf
The shelves in your refrigerator are
adjustable to meet your individual
storage needs.
Cheese & Butter Bin
Cheese & Butter and
Condiment bins are
specially designed
for food that can be
stored at a warmer
temperature. This makes
spreading butter and
slicing cheese easier.
Condiment Bin
lide‘N’Serve
Allows you to store food
items at a different
temperature than the
regular refrigerator area.
Water filter
Purifies water.
NOTE
The filter should be replaced every
6 months. Please refer to the “Replacing
the filter” section in this
manual for details.
* This function may
not be available,
depending on the
model.
Indoor Ice Bin
Ice cubes are
automatically produced.
Crisper
Controls humidity and
helps vegetables and
fruit to stay crisp.
Ice Storage Bin
For additional ice storage.
Fixed Door Bin
Used to preserve
chilled food or drinks.
Durabase® and Durabase® Divider
The Durabase is a storage space
recommended for the preservation of large
food items. The Durabase Divider is used
to organize the Durabase area into sections.
It can be adjusted from side to side to
accommodate items of different sizes.
LED interior lamps
The interior lamps light up the
inside of the refrigerator.
9
INSTALLATION
ENGLISH
INSTALLATION
Installati n Overview
Please read the following installation instructions first after purchasing this product or transporting
it to another location.
1 Unpacking your
refrigerator
2 Choosing the proper
location
3 Disassembling/Assembling
4 Connecting the water
supply and water line
5 Leveling and Door
Alignment
NOTE
Connect to potable water supply only.
10 INSTALLATION
ENGLISH
Specificati ns
The appearance and specifications listed in this manual may vary due to constant product
improvements.
Dimensions
35 3/4" (W) X 36 1/4" (D) X 70 1/4" (H), 48 1/8" (D w/ door open)
908 mm (W) X 921 mm (D) X 1782 mm (H), 1221 mm (D w/ door open)
Net weight 348 lb. (158 kg)
Refrigerator storage capacity
20.3 cu. ft.
Freezer storage capacity 9.7 cu. ft.
Altri manuali per LMX30995
2
Questo manuale è adatto per i seguenti modelli
4
Indice
Altri manuali LG Frigorifero
LG
LG GR-M392CSQB Manuale utente
LG
LG GB-B4452PZ Manuale utente
LG
LG GR-B620YC Manuale utente
LG
LG GC-B409SLQK Manuale utente
LG
LG LMNS14420V Manuale utente
LG
LG LMX31985ST Manuale utente
LG
LG LRFXS2503 Series Manuale utente
LG
LG GC-B303SPHL Manuale utente
LG
LG LS23C4000V Manuale utente
LG
LG 3828JS8034T Manuale utente
