Lightolier Lytespan MHT4RS Manuale utente

2 5/16"

(59mm)

ø 3 1/2"

(89mm)

Lightolier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 •(508) 679-8131 •Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Lytespan®Track Lighting System MHT4RS

Page 1 of 2 Metal Halide T-4 Reflector Spot

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Ordering Information

Catalog No. Finishes Lamps For Use With Luminaires

MHT4RS Anodized T-4 Single Ended Ceramic Metal Halide 8304 and 8314

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Features

1. Spot Reflector: Aluminum, faceted, specular, anodized and sealed.

Finish

Specular Anodized and Sealed.

Labels

UL, cUL

10’223 1.6’1.6’

15’99 2.4’2.4’

20’56 3.1’3.1’

25’38 3.9’3.9’

Lightolier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 •(508) 679-8131 •Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Job Information Type:

AIMING ANGLE: 0° Horizontal Aiming 30° Horizontal Aiming 30° Vertical Aiming 45° Vertical Aiming

DFC L W DC FC L W DC FC L W DC FC L W

Beam Spread CBCP Rated

(To 50% CBCP) Life (Hrs.)

8’4.6’227 1.7’1.5’

12’6.9’101 2.5’2.2’

16’9.2’57 3.4’2.9’

20’11.5’36 4.2’3.6’

6’10.4’78 3.8’1.9’

9’15.6’34 5.8’2.8’

12’20.8’19 7.7’3.8’

15’26.0’12 9.8’4.7’

5’5.0’316 1.6’1.1’

7’7.0’161 2.2’1.6’

9’9.0’98 2.9’2.0’

11’11.0’65 3.5’2.4’

20W T4 CMH 22,347 7,500

9° X 9° 9,000

Lytespan®Track Lighting System MHT4RS

Page 2 of 2 Metal Halide T-4 Reflector Spot

AIMING ANGLE: 0°30°Horizontal 30°Vertical 45°Vertical

LBeam Length DDistance

WBeam Width AAiming Angle

CDistance to center beam FC Footcandles

Land Ware the outer points where the candle power drops

to 50% of the maximum. FC are the initial footcandles at the

center of the beam.

Lamp data shown is typical. Consult lamp manufacturers for

availability and performance.

10’362 1.9’1.8’

15’161 2.9’2.8’

20’90 3.9’3.8’

25’58 4.8’4.8’

DFC L W DC FC L W DC FC L W DC FC L W

Beam Spread CBCP Rated

(To 50% CBCP) Life (Hrs.)

8’4.6’367 2.1’1.8’

12’6.9’163 3.1’2.7’

16’9.2’92 4.1’3.6’

20’11.5’58 5.2’4.4’

6’10.4’128 4.8’2.3’

9’15.6’56 7.1’3.5’

12’20.8’31 9.5’4.6’

15’26.0’20 11.9’5.6’

5’5.0’512 1.8’1.4’

7’7.0’261 2.7’1.9’

9’9.0’158 3.5’2.5’

11’11.0’106 4.3’3.0’

39W T4 CMH 36,169 9,000

11°X 11°10,000

15’236 3.4’3.4’

20’133 4.6’4.5’

25’85 5.7’5.7’

30’59 6.8’6.8’

DFC L W DC FC L W DC FC L W DC FC L W

Beam Spread CBCP Rated

(To 50% CBCP) Life (Hrs.)

10’5.8’346 3.1’2.6’

15’8.7’154 4.6’3.9’

20’11.5’86 6.1’5.3’

25’14.4’55 7.6’6.6’

5’8.7’266 4.7’2.3’

8’13.9’104 7.6’3.6’

11’19.1’55 10.4’5.0’

14’24.2’34 13.3’6.4’

8’8.0’294 3.7’2.6’

12’12.0’131 5.5’3.9’

16’16.0’73 7.4’5.2’

20’20.0’47 9.2’6.4’

70W T4 CMH 53,205 6,000

13°X 13°9,000
