Lightspeed Redcat media Manuale utente
User Manual
Classroom Audio System
CH APWR CH B
2
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use the apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding-type
plug has two blades and a third grounding
prong. The wide blade or the third prong
is provided for your safety. If the provided
plug does not fit into your outlet, consult
an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked
on or pinched particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
3
IMPORTANT SAFETY INSTRUCTIONS CONT’D
11. Only use attachments/ accessories
specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket
or table specified by the manufacturer, or
sold with the apparatus. When a cart is
used, use caution when moving the cart/
apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning
storms or when unused for long periods
of time.
14. Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
15. When the mains plug or appliance coupler
is used as the disconnect device, it shall
remain readily operable.
16. Please keep the unit in a good ventilation
environment.
4
TABLE OF CONTENTS
SECTION 1: 7 System Components and Unpacking
Overview 9 Optional Components
12 Front Panel Indicators
13 Top Panel Controls
14 Side Panel Controls and Connections
16 Rear Panel Controls and Connections
18 REDMIKE Controls and Connections
22 Cradle Charger Controls and Connections
SECTION 2: 24 Step 1. Determine Set-up Location
Set-up & Use 25 1A. To Set-Up on Table Top
27 1B. To Set-Up Mounted on a Wall
30 1C. Wall Mounting Locations
31 Step 2. Audio Integration
35 Step 3. Connecting the Power Supply
5
TABLE OF CONTENTS CONT’D
SECTION 2: 36 4. Charging the REDMIKE
Set-up & Use Cont’d 38 Operating the REDMIKE
41 Output to Assistive Listening Device (ALD)
43 Using REDMIKE as Wireless Audio Link
SECTION 3: 46 Optional REDMIKE VC Controls and Connections
Optional Accessories 49 REDMIKE VC: Charging
49 REDMIKE VC: Intial Set-up
52 REDMIKE Share: Controls and Connections
52 REDMIKE Share: Charging
53 REDMIKE Share: Initial Set-up
54 Initial Set-up: Optional IRMC Media Connector
56 Optional IRMC Media Connector Audio Integration
58 Optional Accessories
6
TABLE OF CONTENTS CONT’D
SECTION 4: 59 Common Problems and Solutions
Troubleshooting 62 Tips to Obtain Optimum Audio Performance
Output to Assistive Listening Device (ALD)
Using the REDMIKE to Amplify External Audio Equipment
SECTION 5: 63 Five-Year Limited Warranty
Warranty, Safety & 65 Safety Warnings and Certifications
Specifications 69 System Specifications
7
SECTION 1:
OVERVIEW
SYSTEM COMPONENTS AND UNPACKING
The standard configuration of the REDCAT® will contain:
REDCAT® Infrared
Receiver/Amplifier
with Table Stand and
Power Supply
CH APWR CH B
8
SYSTEM COMPONENTS AND UNPACKING CONT’D
Charging
Cradle and
Power Supply
REDMIKE®
Classroom
Microphone
The standard configuration of the REDCAT will contain:
9
OPTIONAL COMPONENTS
REDMIKE® VC
Volume Control
Microphone
REDMIKE® Share
Handheld Mic &
Charger Cable
Optional equipment which may be part of your REDCAT system:
10
Standard Components
RC2 REDCAT all-in-one receiver/amplifier/speaker with power supply
24V-1.75-NA Power supply for REDCAT
RMT2 REDMIKE classroom microphone with lavaliere cord and rechargeable
AA battery
NH2A27 Lightspeed AA rechargeable sensing battery
(for REDMIKE)
AC-RMLC2 Lavaliere cord for REDMIKE
BC-RMCC REDMIKE cradle charger
5V-1.0-NA Cradle charger power supply
STANDARD COMPONENTS
