Lindy 70586 Manuale utente
70586
PCI 32 bit P&P
2S (16C650 32FIFO)
1P (ECP/EPP 32FIFO)
www.lindy.com
ž PAGE − 2
u
Description
The 70586 32Bit PCI bus Plug & Play 2S/1P I/O card is equipped with two
High-Speed RS-232.V24 Standard Serial Interfaces and one
ECP/EPP/SPP/BPP IEEE 1284 CENTRONICS Parallel Interface. The serial
ports include 32 Byte FIFO with a speed up to 921Kb/Sec. 70586 has two 9 pin
male connectors for attaching peripherals´ units with Serial RS-232 Standard
Interface and one 25 pin female connector for peripherals' units with IEEE 1284
CENTRONICS Parallel Interface.
u
Hardware Specification
Serial Port:
UART Chipset: SUN1889, Hardware FIFO is 32Byte FIFO
Compatible chips: with 16C650, 16C550, and 16C450.
IEEE standard: RS-232 Interface
Driver Chipset: TI-75232, speed up to 100Kb/Sec, length 300-500M.
Max. Speed: Up to 921Kb/Sec (HYPER Terminal program)
Parallel Port:
Parallel Chipset: SUN1689, Hardware FIFO is 32Byte FIFO
Compatible chips: with ACC3203, ST-78C36, and HT6535.
IEEE standard: ECP/EPP/SPP/BPP (PS-II) Interface
Max. Speed: Up to 2MB/Sec
u
Hardware Installation
½
Turn off the power of your computer
( Plug the 70586 Serial adapter into the PCI bus of your computer
( Connect the peripheral Printer, Modem, Scanner…etc.) to this adapter
( Turn on the power of your computer
PCI device listing display (for example…)
Bus No Device No Func No Vendor ID Device ID Device Class IRQ
0 7 1 8086 7010 IDE Controller 14
0 13 0 1409 7168 Simple COMM.
Controller
10
žPAGE −3
When Vendor ID, Device ID, Device Class or IRQ aren’t displayed or an error occurs,
please change the PCI slot.
After correct hardware installation you can start installing the software from the driver
CD.
u
Pin Assignments
Parallel 25 Pin female connector pin assignments:
Parallel 25 Pin female connector :
Pin Signal Pin Signal Pin Signal
1 STROBE 10 ACKNOWLEDGE 19 GROUND
2 DATA 0 11 BUSY 20 GROUND
3 DATA 1 12 PAPER EMPTY 21 GROUND
4 DATA 2 13 SELECT 22 GROUND
5 DATA 3 14 AUTO FEED 23 GROUND
6 DATA 4 15 ERROR 24 GROUND
7 DATA 5 16 INIT 25 GROUND
8 DATA 6 17 SELECT INPUT 26 GROUND
9 DATA 7 18 GROUND
Serial 9 Pin male connector pin assignments:
Serial 9 Pin male connector :
Pin Signal Pin Signal Pin Signal Pin Signal
1 CD 4 DTR 6 DSR 8 CTS
2 RD 5 GROUND 7 RTS 9 RI
3 TD
u
Technical Specification
Compatibility: PCI 32Bit card for 486/586/Pentium/Pentium-II/
P-III/C5/K6
Operating system: WIN 9.x/ME/NT/2000/XP, LINUX, DOS
Chips: 1 x SUN1889, 1 x SUN1689
Connections: 2 x DB 9 m connector serial
1xDB25Bfconnectorparallel
PCB: 2 Layer / 120 x 76 mm
žPAGE −4
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operations.
