70582

PCI 32 bit P&P

1P (ECP/EPP 32FIFO)

www.lindy.com

PAGE 2

u

Description

The 70582 32Bit PCI bus Plug & Play 1P I/O card is equipped with one

ECP/EPP/SPP/BPP IEEE 1284 CENTRONICS Parallel Interface. It includes

one 25 pin female connector for peripherals’ units with IEEE 1284 CENTRONICS

Parallel Interface.

u

Hardware Specification

Parallel Port:

Parallel Chipset: SUN1888, Hardware FIFO are 32Byte FIFO

Compatible chips: with ACC3203, ST-78C36, and HT6535.

IEEE standard: ECP/EPP/SPP/BPP (PS-II) Interface

Max. Speed: Up to 2MB/Sec

u

Hardware Installation

½

Turn off the power of your computer

½

Plug the 70582 Parallel Adapter into the PCI bus of your computer

½

Connect the peripheral Printer, Modem, Scanner…etc. to this adapter

½

Turn on the power of your computer

PCI device listing display (for example…)

!

!

Bus No Device No Func No Vendor ID Device ID Device Class IRQ

0 7 1 8086 7010 IDE Controller 14

0 13 0 1409 7268 Simple COMM.

Controller 10

When Vendor ID, Device ID, Device Class or IRQ aren’t displayed or an error

occurs, please change the PCI slot.

After correct hardware installation you can start installing the software from the

driver CD.

!!!!!!!

!!!!!!

!

PAGE 3

u

Pin Assignments

Parallel 25 Pin female connector pin assignments:

Parallel 25 Pin female connector:

Pin Signal Pin Signal Pin Signal

1 STROBE 10 ACKNOWLEDGE 19 GROUND

2 DATA 0 11 BUSY 20 GROUND

3 DATA 1 12 PAPER EMPTY 21 GROUND

4 DATA 2 13 SELECT 22 GROUND

5 DATA 3 14 AUTO FEED 23 GROUND

6 DATA 4 15 ERROR 24 GROUND

7 DATA 5 16 INIT 25 GROUND

8 DATA 6 17 SELECT INPUT 26 GROUND

9 DATA 7 18 GROUND

u

Technical Specification

Compatibility: PCI 32Bit card for 486/586/Pentium/Pentium-II/

P-III/C5/K6

Operating system: WIN9.x/ME/NT/2000/XP, LINUX, DOS

Chips: 1 x SUN1888

Connections: Connector parallel 1 x DB 25 f

PCB: 2 Layer / 120 x 63 mm

This device complies with Part 15 of the FCC

Rules. Operation is subject to the following two

conditions: (1) this device may not cause

harmful interference, and (2) this device must

accept any interference received, including
