Lindy 70584 Manuale utente
70584
PCI 32 bit P&P
1S (16C650 32FIFO)
www.lindy.com
PAGE 2
u
Description
The 70584 32Bit PCI bus Plug & Play 1S I/O card is equipped with one
High-Speed RS-232.V24 Standard Serial Interface. The serial port includes 32
Byte FIFO with a speed up to 921Kb/Sec. 70584 includes one 9 pin male
connector for attaching the peripheral’s unit.
u
Hardware Specification
Serial Port:
UART Chipset: SUN1889, Hardware FIFO are 32Byte FIFO
Compatible chips: with 16C650, 16C550 and 16C450.
IEEE standard: RS-232 Interface
Driver Chipset: TI-75232, speed up to 100Kb/Sec, length 300-500M.
Max. Speed: Up to 921Kb/Sec (HYPER Terminal program)
!
u
Hardware Installation
½
Turn off the power of your computer
½
Plug the 70584 Serial Adapter to the PCI bus of your computer
½
Connect the peripheral (Printer, Modem, Scanner…etc.) to this adapter
½
Turn on the power of your computer
PCI device listing display (for example…)
Bus No Device No Func No Vendor ID Device ID Device Class IRQ
0 7 1 8086 7010 IDE Controller 14
0 13 0 1409 7168 Simple COMM.
Controller 10
When Vendor ID, Device ID, Device Class or IRQ aren’t displayed or an error
occurs, please change the PCI slot.
After correct hardware installation you can start installing the software from the
driver CD.
PAGE 3
u
Pin Assignments
Serial 9 Pin male connector pin assignments:
Serial 9 Pin male connector:
Pin Signal Pin Signal Pin Signal Pin Signal
1 CD 4 DTR 6 DSR 8 CTS
2 RD 5 GROUND 7 RTS 9 RI
3 TD
u
Technical Specification
Compatibility: PCI 32Bit card for 486/586/Pentium/Pentium-II/
P-III/C5/K6
Operating system: WIN 9.x/ME/NT/2000/XP, LINUX, DOS
Chips: 1 x SUN1889
Connections: 1 x DB 9 m connector serial
PCB: 2 Layer / 120 x 51 mm
PAGE 4
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operations.
