Linksys WPG11 Manuale utente

Wireless Presentation

Gateway

• Interoperable with Industry-Proven IEEE 802.11b (DSSS)

2.4GHz-Compliant Equipment

•Client Software Included

• Display Resolutions up to 1024 x 768

•Up to 11 Mbps High-Speed Transfer Rate

•Line of Sight Wireless Connectivity

• Low Interference and High Susceptibility Guarantee

Reliable Performance

• Equipped with One Standard VGA Port for Compatibily with

VirtuallyAny Presentation Projector

• Easy and Quick Setup

• Free Technical Support—24 Hours a Day,

7 Days a Week for NorthAmerica Only

• 1-Year Limited Warranty

Instant Wireless™

Wireless Presentation Gateway

Model number: WPG11

Free From Cables - Air Your Presentation

Features

Benefits

IItt’’ssAAlllliinntthhee

PPrreesseennttaattiioonn!!

• Give More Dynamic Presentations With the

Benefits of Wireless Connectivity.

• A Browser-Based Interface and Easy to Use

Client Software Take the Stress Out of Giving

Presentations.

• Fully Compatible with IEEE 802.11b Standard.

• Supports a High Data Rate of Up to 11Mbps.

• Compatible with Virtually All Presentation

Projectors.

• Allow Presentations from Multiple PCs or

Laptops

• Experience Interactive Communication During

Presentations

Instant Wireless

™

Series

hether you’re giving presentations in the confer-

ence room or the board room, the Wireless

Presentation Gateway brings you the convenience

and flexibility of wireless networking! With a single key-

stroke,any PC with aWi-Fi adapter in the vicinity can quick-

ly and easily take turns displaying their own presentation

materialsonaprojectorscreenormonitor,creatingagraph-

ic dialogue. The Presentation Gateway allows convenient,

interactive communication during meetings, seminars, and

presentations.

he Wireless Presentation Gateway can be placed

within your conference room or anywhere near the

projector or monitor. Its high-powered antenna means that

you're ready to present from anywhere within line of sight,

eliminating the need for cumbersome cables. So you've got

the flexibility and performance you need to make great pre-

sentations combined with the ease of wireless networking

as only Linksys can provide.

Package ContentsSpecifications

Model No. WPG11

Standards IEEE 802.11b

Protocol: CSMA/CD

Output Power +15dBm (32mW)

Ports:

Wireless Two 2.4GHz DSSS with dual removable

antennas

Graphic standard 15-pin VGA connector

800x600 SVGA, 1024x768 XGA

Antenna Dual removable diversity system antennas

Channels 11 Channels (US, Canada)

13 Channels (Europe)

14 Channels (Japan)

Operating Range Up to 100 meters / 328 feet indoors

Security IEEE standard 64/128 bit WEP Encryption

LEDs Power,WLANAct,WLAN Link

Environmental

Dimensions 7.3” x 6.5” x 1.9”(186 mm x 165 mm x 48 mm)

Unit Weight 16 oz. (0.46 kg)

Power External, 5V AC 2.5A

Certifications FCC Class B, CE Mark

Operating Temp. 32°F to 131°F (0°C to 55°C)

Storage Temp. 14°F to 149°F (-10°C to 65°C)

Operating Humidity 10% to 90% Non-Condensing

Storage Humidity 10% to 90% Non-Condensing

Instant Wireless™

Wireless Presentation Gateway

• One Instant Wireless™ Wireless

Presentation Gateway

• One Power Adapter

• Registration Card

• One Setup CD-ROM with User Guide

included

• One Quick Installation

• Windows 98, Millennium, 2000, or XP PC

with:

- 200 MHz Pentium CPU

- 64 MB RAM

- CD-ROM drive

• 802.11b-compliant Wireless Adapter

System Requirements

DS-WPG11-051002A KL

Linksys

17401 Armstrong Ave.

Irvine, CA 92614 USA

Sales Information (800) 546-5797

World Wide Web* http://www.linksys.com

China (10) 6432 1923

Japan (03) 5259-5139

Philippines (632) 638 5580

Singapore 552-8998

Thailand 717-0770

United Kingdom 01245 352403

*Visit our website for the most current contact information.
