Linksys BEFSR11 - EtherFast Cable/DSL Router Manuale utente

EtherFast®

Cable/DSL Router

o you find sharing Internet access to be nothing but a

hassle? Can’t find a simple and inexpensive way to

share your one Internet IP address over your entire

network? If so, then the EtherFast®Cable/DSL Router is

exactly what you’re looking for.

The EtherFast®Cable/DSL Router provides the perfect solu-

tion for connecting up to 253 users to a high-speed broad-

band Internet connection. The Cable/DSL Router’s design

also serves as the ideal device for a single-PC environment.

Configurable as a DHCP server for your existing network,

this Cable/DSL Router acts as the only externally recognized

Internet gateway on your local area network (LAN), serving

as a firewall against unwanted outside intruders.The Router

can also be configured to block specific users’ access to the

Internet.

Butthefeaturesdon’tstopthere. TheCable/DSLRouterfea-

tures advanced Internet functions such as dynamic and

static port routing, remote administration, DMZ hosting, fil-

tering and forwarding. All of these functions can be easily

configured through your networked PC’s Web browser.

• Connects to a Broadband Modem and an Ethernet

Backbone

• Use Just One IP Address to Access the Internet Over

Your Entire Network

• Creates a Firewall to Protect Your PCs From Unwanted

Outside Intruders

• ConfigurableThroughYourNetworkedPC'sWebBrowser

• Supports IPSec Pass-Thru

• Capable of RemoteAdministration Via the Internet

• AbletoActasaDHCP ServerforYourExistingNetwork

• Compatible with virtually All Standard Internet

Applications

• Able to Block Specific Internal Users' InternetAccess

• Free Technical Support—24 Hours a Day,

7 Days aWeek for NorthAmerica Only

• 1-Year Limited Warranty

• Build a Broadband Network in Your Home

or Small Office

• Access the Internet Over Your Entire

Network with Just One IP Address

• Create a Firewall with NAT to Protect Your

PCs From Outside Intruders

• Dramatically Speed Up Your Gaming and

Multimedia Connections with Built-in

Internal Switch

• Free Technical Support—24 Hours a Day,

7 Days a Week for North America Only

• 1-Year Limited Warranty

IInnssttaannttBBrrooaaddbbaanndd™™11--PPoorrttCCaabbllee//DDSSLL

RRoouutteerr((BBEEFFSSRR1111))

Share Broadband Internet Access

With Your Entire Network

Features

Benefits

Share Your Broadband

Internet Connection

Specifications

Model Number BEFSR11

Standards: IEEE 802.3, IEEE 802.3u

Protocol: CSMA/CD

Ports: WAN: One 10BaseT Uplink Port

LAN: One 10/100 RJ-45 Port

Cabling Type: 10BaseT: UTP Category 3 or Better

100BaseTX: UTP Category 5 or Better

Topology: Star

Speed: WAN: 10Mbps (10BaseT Ethernet)

LAN: 10Mbps (10BaseT Ethernet) or

100Mbps (100BaseTX Fast Ethernet)

LEDs: Power

WAN: Diag,Act, Link

LAN: 10/100, Full/Col, Link/Act

Environmental

Dimensions: 7.31" x 6.16" x 1.88" (186mm x 154mm x 48mm)

Unit Weight: 12.6 oz. (0.35 kg)

Power: External, 7.5V DC, 0.7 A

Certifications: FCC Class B,

CE Mark Commercial

Operating Temp: 0ºC to 40ºC (32ºF to 104ºF)

Storage Temp: -20ºC to 70ºC (-4ºF to 158ºF)

Operating Humidity: 10% to 85% Non-Condensing

Storage Humidity: 5% to 90% Non-Condensing

Package Contents

Instant Broadband™

EtherFast®Cable/DSL Router

• One Instant Broadband™ EtherFast®

Cable/DSL Router

• One AC Power Adapter

• One User Guide and Registration Card

Model Number: BEFSR11

01023

Linksys

17401 Armstrong Ave.

Irvine, CA 92614 USA

Information (800) 546-5797

Technical Support (800) 326-7114

(949) 261-1288

Fax (949) 261-8868

World Wide Web http://www.linksys.com

Email [email protected]

[email protected]

China

Tech Support (10) 6432 1920

Sales (10) 6432 1923

Fax (10) 6437 6891

Japan

Telephone (03) 5259-5139

Fax (03) 5259-5117

Philippines

Telephone (632) 638 5580

Fax (632) 635 6772

Singapore

Telephone 552-8998

Fax 552-1024

Thailand

Telephone 717-0770

Fax 717-0738

United Kingdom

Tech Support 0870 7393939

Sales 01245 352403

Fax 0870 7393938
