Linksys BEFSR81 - EtherFast Cable/DSL Router Manuale utente

With Built-In 8-Port 10/100 Switch

for Sharing High-Speed

Internet Access

EtherFast®Cable/DSL

Router

o you find Internet sharing software to be nothing

but a hassle? Can’t find a simple and inexpensive

way to share your one Internet IP address over your

entire network? If so, then the Linksys Instant Broadband

Cable/DSL Router is exactly what you’re looking for.

The Instant Broadband EtherFast®Cable/DSL Router from

Linksys offers the perfect solution for connecting up to 253

of your PCs to a high-speed broadband Internet connection

and a 10/100 Fast Ethernet backbone. Configurable as a

DHCP server for your network, the EtherFast®Cable/DSL

Router acts as the only externally recognized Internet gate-

way on your local area network (LAN). The Router can also

be configured via SNMP to filter internal users’ access to

the Internet and serve as a NAT firewall against unwanted

outside intruders on the Internet.

The Cable/DSL Router features advanced functions such as

dynamic and static port routing, DMZ hosting,filtering and

forwarding, and Quality of Service capabilities. All of these

functions can be easily configured through your networked

PC’s web browser.

• Provides Port Security, Packet Filtering, and Filters

Internal User’s Access

• Identifies Up to Four Ports for High or Low Port-Based

Prioritization

• QoS Capabilities Based on IEEE 802.1p and IP TOS/DS

Greatly Reduces the Chance of Data Loss Based on

Weighted Round-Robin (WRR)

• Dramatically Speed Up Your Gaming and Multimedia

Connections With the Internal Switch

• Full Wirespeed LayerTwo Switching on All LAN Ports

• 1K MAC Address Table Means Both Auto Address

Learning and Aging

• Configurable Through A Networked PC's Web Browser

• Acts as a DHCP Server For Your Network

• Administrators Can Block Specific Internal Users'

Internet Access with Filtering

• Supports WinSock 2.0 and Windows 2000 Smart

Applications

• Free Technical Support—24 Hours a Day, 7 Days a Week

in North America Only

• 1-Year Limited Warranty

• Build a Broadband Network in Your Home or

Small Office

• Provides Port Security, Packet Filtering,

and Filters Internal User’s Access

• QoS Capabilities Reduce the Chance of Data

Loss and Allow for Port-Based Prioritization

• Access the Internet Over Your Entire Network

With Just One IP Address

• NAT Firewall Protects Your PCs From

Unwanted Outside Intruders on the Internet

• Remote Administration Over the Internet

• Free Technical Support—24 Hours a Day,

7 Days a Week in North America Only

• 1-Year Limited Warranty

IInnssttaannttBBrrooaaddbbaanndd™™CCaabbllee//DDSSLLRRoouutteerr

((BBEEFFSSRR8811))

With a Built-In 8-Port 10/100 Switch for

Sharing High-Speed Internet Access

Features

Benefits

with QoS

Specifications

Model Number: BEFSR81

Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1p

Protocol: CSMA/CD

Ports: LAN: Eight 10/100 RJ-45 Ports

WAN: One 10BaseT Port

Cabling Type: 10BaseT: UTP Category 3 or Better

100BaseTX: UTP Category 5 or Better

Topology: Star

Speed: LAN: 10Mbps (10BaseT Ethernet) or

100Mbps (100BaseTX Fast Ethernet)

WAN: 10Mbps (10BaseT Ethernet)

LEDs: Power

LAN: QoS, Link/Act, Full/Col, 100

WAN: Diag,Act, Link

Environmental

Dimensions: 7.31" x 6.16" x 1.88" (186mm x 154mm x 48mm)

Unit Weight: 17.8 oz. (0.5 Kg)

Power: External, 5V DC, 3A

Certifications: FCC Class B,

CE Mark Commercial

Operating Temp: 0ºC to 40ºC (32ºF to 104ºF)

Storage Temp: -20ºC to 70ºC (-4ºF to 158ºF)

Operating Humidity: 10% to 85% Non-Condensing

Storage Humidity: 5% to 90% Non-Condensing

Package Contents

Instant Broadband

EtherFast®Cable/DSL Router

• One Instant Broadband™ Cable/DSL Router

• One AC Adapter and Power Cord

• One User Guide and Registration Card

Model Number: BEFSR81

Linksys

17401 Armstrong Ave.

Irvine, CA 92614 USA

Information (800) 546-5797

Technical Support (800) 326-7114

(949) 261-1288

Fax (949) 261-8868

World Wide Web http://www.linksys.com

Email [email protected]

[email protected]

China

Tech Support (10) 6432 1920

Sales (10) 6432 1923

Fax (10) 6437 6891

Philippines

Telephone (632) 638-5580

Fax (632) 635-6772

Japan

Telephone (03) 5259-5139

Fax (03) 5259-5117

Singapore

Telephone 552-8998

Fax 552-1024

Thailand

Telephone 717-0770

Fax 717-0738

United Kingdom

Tech Support 0870 7393939

Sales 01245 352403

Fax 0870 7393938

01023
